WHIRLPOOL ADP 252 WH
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | ADP 252 WH |
| Kód 12NC: | 851125243510 |
| I.C. kód: | 851125243514 |
| Značka: | WHIRLPOOL |
| Typ produktu: | |
| Další podobné modely: | 851125215513, 851125215514, 851125243510, 851125243511, 851125243512, 851125243513, 851125215510, 851125215511, 851125215512 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 001 1 WHR110216 |
C00344183
481240448659 |
Bracket foot left | Na dotaz | Zadat poptávku | |
| 001 2 WHR110216 |
C00497582
481240448661 |
Bracket foot right | Na dotaz | Zadat poptávku | |
| 001 3 WHR110216 |
C00344184
481240448729 |
BRACKET FOOT | Na dotaz | Zadat poptávku | |
| 004 0 WHR110216 |
C00341211
481244010498 |
DRIP TRAY ASSY | Na dotaz | Zadat poptávku | |
| 011 0 WHR110216 |
C00340776
481250518374 |
noha nastavitelna | 192 Kč
€ 8.40 |
||
| 022 0 WHR110216 |
C00328112
481244019575 |
Side panel left wh | Na dotaz | Zadat poptávku | |
| 022 1 WHR110216 |
C00328113
481244019576 |
Side panel right wh | Na dotaz | Zadat poptávku | |
| 024 0 WHR110216 |
C00580761
481244010618 |
Panel, rear | Na dotaz | Zadat poptávku | |
| 030 0 WHR110216 |
C00497954
481244019992 |
HORNA DOSKA | Na dotaz | Zadat poptávku | |
| 040 1 WHR110216 |
C00314536
481241718836 |
Závěs dveří myčky - pravý | 854 Kč
€ 37.50 |
||
| 040 2 WHR110216 |
C00314668
481241718835 |
Závěs dveří myčky - levý | 868 Kč
€ 38.20 |
||
| 040 3 WHR110216 |
C00337091
481241718949 |
Protector f. Door | Na dotaz | Zadat poptávku | |
| 044 0 WHR110216 |
C00317030
481249238375 |
pruzina | 584 Kč
€ 25.70 |
||
| 047 0 WHR110216 |
C00314731
481240448734 |
HINGE PULLEY pulley | Na dotaz | Zadat poptávku | |
| 047 1 WHR110216 |
C00311799
481240448735 |
Lanko dveří - brzdící pro myčky Whirlpool, Whirlpool Ikea | 114 Kč
€ 5.00 |
||
| 047 2 WHR110216 |
C00314216
481240468032 |
Držák pružiny levý | 187 Kč
€ 8.20 |
||
| 047 3 WHR110216 |
C00314218
481240468033 |
Držák pružina pravý | 187 Kč
€ 8.20 |
||
| 050 0 WHR110216 |
C00498013
481244088957 |
SOKEL PLAST N | Na dotaz | Zadat poptávku | |
| 053 0 WHR110216 |
C00497942
481244019573 |
Plinth | Na dotaz | Zadat poptávku | |
| 061 0 WHR110216 |
C00343093
481246688484 |
Counter weight | Na dotaz | Zadat poptávku | |
| 103 0 WHR110216 |
C00338983
481244019993 |
Door outer | Na dotaz | Zadat poptávku | |
| 120 0 WHR110216 |
C00339014
481244019565 |
Door inner | Na dotaz | Zadat poptávku | |
| 120 1 WHR110216 |
C00497949
481244019933 |
SOKEL N | Na dotaz | Zadat poptávku | |
| 130 0 WHR110216 |
C00320042
481241758375 |
TILT LOCK | Na dotaz | Zadat poptávku | |
| 131 0 WHR110216 |
C00339493
481240118453 |
Hook lock | Na dotaz | Zadat poptávku | |
| 191 0 WHR110216 |
C00340458
481246668589 |
tesneni dveri obvod. | 892 Kč
€ 39.20 |
||
| 192 0 WHR110216 |
C00340405
481246668641 |
GASKET, DOOR LOWER | Na dotaz | Zadat poptávku | |
| 200 0 WHR110216 |
C00497804
481241818229 |
CONTAINER | Na dotaz | Zadat poptávku | |
| 241 0 WHR110216 |
C00529530
481245819023 |
Basket upper upper | Na dotaz | Zadat poptávku | |
| 241 1 WHR110216 |
C00342238
481245819017 |
CUP HOLDER | Na dotaz | Zadat poptávku | |
| 241 3 WHR110216 |
C00337184
481252888081 |
Wheel basket upper | Na dotaz | Zadat poptávku | |
| 241 4 WHR110216 |
C00344448
481245819022 |
Koš myčky horní | 3 001 Kč
€ 131.90 |
||
| 242 0 WHR110216 |
C00498273
481245818963 |
Basket lower lower | Na dotaz | Zadat poptávku | |
| 242 1 WHR110216 |
C00337187
481252888079 |
Kolečko spodního koše myčky | 141 Kč
€ 6.20 |
||
| 243 0 WHR110216 |
C00342221
481245818966 |
kosik na pribory | 1 052 Kč
€ 46.20 |
||
| 243 2 WHR110216 |
C00497589
481240448731 |
Grip cutlery basket | Na dotaz | Zadat poptávku | |
| 261 0 WHR110216 |
C00313273
481246238075 |
Lišta nerez | Na dotaz | Zadat poptávku | |
| 261 1 WHR110216 |
C00312891
481246279745 |
CAP RAIL rail | Na dotaz | Zadat poptávku | |
| 261 2 WHR110216 |
C00311326
481246279746 |
Doraz koše C-typ | 44 Kč
€ 1.90 |
||
| 301 0 WHR110216 |
C00741585
481245370929 |
Control panel ADP 25 | Na dotaz | Zadat poptávku | |
| 303 0 WHR110216 |
C00340213
481246058361 |
Grip | Na dotaz | Zadat poptávku | |
| 331 0 WHR110216 |
C00497695
481241359047 |
GOMBIK | Na dotaz | Zadat poptávku | |
| 332 0 WHR110216 |
C00337008
481241028722 |
Push button cap on/off | Na dotaz | Zadat poptávku | |
| 332 1 WHR110216 |
C00337010
481241028723 |
Push button cap funktion | Na dotaz | Zadat poptávku | |
| 351 1 WHR110216 |
C00497543
481238128057 |
KONTROLKA ZELENA | Na dotaz | Zadat poptávku | |
| 400 0 WHR110216 |
C00557967
481236158174 |
CERPADLO CIRKULACNE LOP. N | Na dotaz | Zadat poptávku | |
| 400 1 WHR110216 |
C00332776
481284678001 |
Cap fixation | Na dotaz | Zadat poptávku | |
| 400 2 WHR110216 |
C00344167
481240118489 |
Bracket Motor | Na dotaz | Zadat poptávku | |
| 400 3 WHR110216 |
C00328878
481240118491 |
Damper circulation pump | Na dotaz | Zadat poptávku | |
| 400 4 WHR110216 |
C00497563
481240148577 |
Bracket | Na dotaz | Zadat poptávku | |
| 420 0 WHR110216 |
C00497242
481212118194 |
Capacitor | Na dotaz | Zadat poptávku | |
| 421 0 WHR110216 |
C00317390
481212118241 |
Interf.filter | Na dotaz | Zadat poptávku | |
| 430 0 WHR110216 |
C00580729
481236018495 |
PUMP,DRAINING. | Na dotaz | Zadat poptávku | |
| 432 0 WHR110216 |
C00337047
481236018521 |
PUMP,DRAINING | Na dotaz | Zadat poptávku | |
| 432 1 WHR110216 |
C00340454
481246688549 |
Gasket Drain pump | Na dotaz | Zadat poptávku | |
| 432 2 WHR110216 |
C00498451
481246658013 |
drzak | 218 Kč
€ 9.60 |
||
| 450 0 WHR110216 |
C00311759
481225928684 |
Heating element 2040W 220V - 303554 | Na dotaz | Zadat poptávku | |
| 450 4 WHR110216 |
C00339261
481253029015 |
Hose Pump - Heater | Na dotaz | Zadat poptávku | |
| 480 0 WHR110216 |
C00741583
481221478847 |
Cable harness | Na dotaz | Zadat poptávku | |
| 480 3 WHR110216 |
C00339641
481243518096 |
Holder cable | Na dotaz | Zadat poptávku | |
| 490 0 WHR110216 |
C00527301
481232118112 |
Cable,mains Africa | Na dotaz | Zadat poptávku | |
| 490 1 WHR110216 |
C00493148
481232118184 |
Cable mains | Na dotaz | Zadat poptávku | |
| 491 0 WHR110216 |
C00335989
481232128413 |
Strain relief | Na dotaz | Zadat poptávku | |
| 500 0 WHR110216 |
C00320096
481228218498 |
programator mycky | 4 933 Kč
€ 216.80 |
||
| 505 0 WHR110216 |
C00482337
481221478851 |
Control board E1 15-pin | Na dotaz | Zadat poptávku | |
| 505 0 WHR110216 |
C00741584
481232058128 |
Control board | Na dotaz | Zadat poptávku | |
| 571 0 WHR110216 |
C00314693
481228128428 |
ventil | 1 704 Kč
€ 74.90 |
||
| 575 0 WHR110216 |
C00327512
481228128408 |
Valve magnet regener. | Na dotaz | Zadat poptávku | |
| 583 0 WHR110216 |
C00337561
481227128451 |
PRESSOSTAT | Na dotaz | Zadat poptávku | |
| 620 1 WHR110216 |
C00498096
481245210513 |
DRZIAK | Na dotaz | Zadat poptávku | |
| 621 0 WHR110216 |
C00327427
481227628372 |
spinac sitovy | 1 056 Kč
€ 46.40 |
||
| 631 1 WHR110216 |
C00327229
481227128452 |
Mikrospínač plováku | 969 Kč
€ 42.60 |
||
| 631 5 WHR110216 |
C00312449
481227118016 |
senzor prutokomeru | 637 Kč
€ 28.00 |
||
| 633 0 WHR110216 |
C00319107
481227138402 |
MICROSWITCH DOORdoor | Na dotaz | Zadat poptávku | |
| 680 0 WHR110216 |
C00343597
481241868211 |
COMBIDOSAGE | Na dotaz | Zadat poptávku | |
| 680 1 WHR110216 |
C00340415
481246668639 |
Gasket until 2003 | Na dotaz | Zadat poptávku | |
| 680 2 WHR110216 |
C00327263
481227158168 |
Cívka násypky 481241868314 | 957 Kč
€ 42.10 |
||
| 681 0 WHR110216 |
C00338356
481246668642 |
Lid rinse aid | Na dotaz | Zadat poptávku | |
| 681 1 WHR110216 |
C00337963
481246668643 |
Těnění zátky leštidla myčky Whirlpool, Ignis ADL 931 | 253 Kč
€ 11.10 |
||
| 682 0 WHR110216 |
C00498476
481246688559 |
Gasket flap RMG | Na dotaz | Zadat poptávku | |
| 692 0 WHR110216 |
C00340975
481228268026 |
senzor NTC | 658 Kč
€ 28.90 |
||
| 701 0 WHR110216 |
C00332417
481253029032 |
hadice napousteci | Na dotaz | Zadat poptávku | |
| 701 1 WHR110216 |
C00339588
481240478398 |
HOLDER HOSE LOWER PART | Na dotaz | Zadat poptávku | |
| 701 2 WHR110216 |
C00339586
481240478399 |
Holder hose upper part | Na dotaz | Zadat poptávku | |
| 701 3 WHR110216 |
C00345764
481248058104 |
filtr - sitko | 209 Kč
€ 9.20 |
||
| 710 0 WHR110216 |
C00341709
481241868206 |
zasobnik soli | Na dotaz | Zadat poptávku | |
| 710 2 WHR110216 |
C00336833
481246668644 |
Ring Water softener | Na dotaz | Zadat poptávku | |
| 710 3 WHR110216 |
C00340411
481246668645 |
Gasket Water softener | Na dotaz | Zadat poptávku | |
| 710 4 WHR110216 |
C00339560
481240478401 |
Holder Pressure switch | Na dotaz | Zadat poptávku | |
| 710 6 WHR110216 |
C00330916
481246668646 |
Gasket Regeneration valve | Na dotaz | Zadat poptávku | |
| 710 7 WHR110216 |
C00337298
481228128407 |
Valve Holder | Na dotaz | Zadat poptávku | |
| 714 0 WHR110216 |
C00320202
481241868209 |
Uzávěr zásobníku soli myčky | 256 Kč
€ 11.30 |
||
| 716 0 WHR110216 |
C00485010
481241868277 |
REG.DOSAGE | Na dotaz | Zadat poptávku | |
| 716 1 WHR110216 |
C00319785
481246668647 |
Těsnění bloku úupravy vody | 274 Kč
€ 12.00 |
||
| 716 2 WHR110216 |
C00498687
481284678002 |
Lock | Na dotaz | Zadat poptávku | |
| 721 1 WHR110216 |
C00336156
481236068078 |
Rameno mycí spodní | Na dotaz | Zadat poptávku | |
| 721 5 WHR110216 |
C00497868
481243518097 |
Clamp | Na dotaz | Zadat poptávku | |
| 722 0 WHR110216 |
C00320118
481236068079 |
SPRAY ARM UPPER | Na dotaz | Zadat poptávku | |
| 722 1 WHR110216 |
C00318156
481236068244 |
Nátrubek | 910 Kč
€ 40.00 |
||
| 722 4 WHR110216 |
C00336151
481236068245 |
podlozka ramene hor. | 205 Kč
€ 9.00 |
||
| 722 5 WHR110216 |
C00336163
481236068246 |
Spray arm central part | Na dotaz | Zadat poptávku | |
| 722 6 WHR110216 |
C00497509
481236068247 |
Spray arm fixing nut | Na dotaz | Zadat poptávku | |
| 722 7 WHR110216 |
C00497510
481236068248 |
SPRAY ARM | Na dotaz | Zadat poptávku | |
| 726 0 WHR110216 |
C00498618
481253028893 |
TRUBICA | Na dotaz | Zadat poptávku | |
| 726 1 WHR110216 |
C00337401
481253029016 |
TUBE | Na dotaz | Zadat poptávku | |
| 726 2 WHR110216 |
C00498623
481253029017 |
Tube | Na dotaz | Zadat poptávku | |
| 726 3 WHR110216 |
C00330879
481246628126 |
Těsnění | 228 Kč
€ 10.00 |
||
| 726 4 WHR110216 |
C00330917
481246668648 |
Holder spray arm hose | Na dotaz | Zadat poptávku | |
| 726 5 WHR110216 |
C00330918
481246668649 |
klapka | Na dotaz | Zadat poptávku | |
| 726 6 WHR110216 |
C00498462
481246668651 |
Hose | Na dotaz | Zadat poptávku | |
| 751 0 WHR110216 |
C00337215
481241818361 |
Water collector | Na dotaz | Zadat poptávku | |
| 751 1 WHR110216 |
C00497812
481241818298 |
Water collector Vortex breaker | Na dotaz | Zadat poptávku | |
| 751 2 WHR110216 |
C00482900
481241818398 |
WATER COLLECTOR | Na dotaz | Zadat poptávku | |
| 755 0 WHR110216 |
C00339361
481253029018 |
Hose heater - sump | Na dotaz | Zadat poptávku | |
| 756 0 WHR110216 |
C00327226
481227118017 |
Plovák + mikrospínač | 549 Kč
€ 24.10 |
||
| 756 1 WHR110216 |
C00332738
481254828035 |
Tray leak | Na dotaz | Zadat poptávku | |
| 761 0 WHR110216 |
C00320133
481248058095 |
Sieve fine | Na dotaz | Zadat poptávku | |
| 761 1 WHR110216 |
C00340934
481248058126 |
Filter support group | Na dotaz | Zadat poptávku | |
| 761 2 WHR110216 |
C00497814
481241818301 |
Guide water | Na dotaz | Zadat poptávku | |
| 764 0 WHR110216 |
C00340957
481248058103 |
FILTER | Na dotaz | Zadat poptávku | |
| 781 0 WHR110216 |
C00339375
481253029019 |
Hose draining | Na dotaz | Zadat poptávku | |
| 783 1 WHR110216 |
C00339257
481253058121 |
Hadice myčky Whirlpool, Ignis | 618 Kč
€ 27.20 |
||
| 783 4 WHR110216 |
C00498649
481253058122 |
Hose water inlet-regunit | Na dotaz | Zadat poptávku | |
| 783 6 WHR110216 |
C00339251
481253058152 |
Hose regunit-softener | Na dotaz | Zadat poptávku | |
| 783 7 WHR110216 |
C00498656
481253058153 |
HADICA | Na dotaz | Zadat poptávku | |
| 783 8 WHR110216 |
C00339464
481253058154 |
HOSE | Na dotaz | Zadat poptávku | |
| 783 9 WHR110216 |
C00339466
481253058151 |
HOSE | Na dotaz | Zadat poptávku | |
| 784 0 WHR110216 |
C00339426
481253058135 |
HOSE | Na dotaz | Zadat poptávku | |
| 784 2 WHR110216 |
C00493812
481253058155 |
HOSE | Na dotaz | Zadat poptávku | |
| 791 0 WHR110216 |
C00498665
481253268093 |
TESNENIE GUM/PLOCHE | Na dotaz | Zadat poptávku | |
| 901 2 WHR110216 |
C00335980
481240118577 |
STRAP | Na dotaz | Zadat poptávku | |
| 901 3 WHR110216 |
C00335939
481240118493 |
Strap sump | Na dotaz | Zadat poptávku | |
| 901 4 WHR110216 |
C00328879
481240118494 |
Strap 47 | Na dotaz | Zadat poptávku | |
| 901 5 WHR110216 |
C00317962
481240118495 |
Strap 40 | Na dotaz | Zadat poptávku | |
| 901 7 WHR110216 |
C00335948
481240118497 |
Strap 9,1 | Na dotaz | Zadat poptávku | |
| 901 8 WHR110216 |
C00335951
481240118498 |
Strap 8,6 | Na dotaz | Zadat poptávku | |
| 902 6 WHR110216 |
C00328945
481240148578 |
popruh | 156 Kč
€ 6.90 |
||
| 910 1 WHR110216 |
C00332074
481250218473 |
Screw PT 4x18 | Na dotaz | Zadat poptávku | |
| 910 2 WHR110216 |
C00332067
481250218456 |
Screw 4x18 | Na dotaz | Zadat poptávku | |
| 910 4 WHR110216 |
C00332068
481250218457 |
sroub | 210 Kč
€ 9.20 |
||
| 910 5 WHR110216 |
C00332069
481250218458 |
Screw 4x16 | Na dotaz | Zadat poptávku | |
| 911 2 WHR110216 |
C00498558
481250218459 |
Screw | Na dotaz | Zadat poptávku | |
| 911 3 WHR110216 |
C00332084
481250218536 |
Screw M4X8 | Na dotaz | Zadat poptávku | |
| 911 4 WHR110216 |
C00336676
481250218462 |
SCREW | Na dotaz | Zadat poptávku | |
| 911 5 WHR110216 |
C00332070
481250218463 |
Screw 3,9x19 | Na dotaz | Zadat poptávku | |
| 911 6 WHR110216 |
C00332071
481250218464 |
SCREW | Na dotaz | Zadat poptávku | |
| 911 7 WHR110216 |
C00336637
481250218471 |
Screw 3,9x9,5 | Na dotaz | Zadat poptávku | |
| 911 7 WHR110216 |
C00498559
481250218465 |
Screw 3,9x10 | Na dotaz | Zadat poptávku | |
| 911 8 WHR110216 |
C00332072
481250218466 |
SCREW | Na dotaz | Zadat poptávku | |
| 911 9 WHR110216 |
C00498560
481250218467 |
Screw 5x20 | Na dotaz | Zadat poptávku | |
| 912 3 WHR110216 |
C00498564
481250218586 |
Screw | Na dotaz | Zadat poptávku | |
| 915 3 WHR110216 |
C00332073
481250218472 |
Screw M5x8 | Na dotaz | Zadat poptávku | |
| 915 4 WHR110216 |
C00332777
481284678003 |
Cap screw wh | Na dotaz | Zadat poptávku | |
| 915 5 WHR110216 |
C00328963
481240418146 |
Screw 5x22 | Na dotaz | Zadat poptávku | |
| 921 3 WHR110216 |
C00332335
481252648073 |
podlozka | 200 Kč
€ 8.80 |
||
| 952 0 WHR110216 |
C00332754
481263058097 |
Těsnění divertoru | 339 Kč
€ 14.90 |
||
| 952 1 WHR110216 |
C00498682
481263058098 |
O-Ring | Na dotaz | Zadat poptávku | |
| 952 2 WHR110216 |
C00337968
481263058099 |
tesneni | 145 Kč
€ 6.40 |
||
| 964 0 WHR110216 |
C00338700
481202298002 |
Insulation pad | Na dotaz | Zadat poptávku | |
| 993 0 WHR110216 |
C00316831
481953029028 |
Koleno výtokové hadice | 95 Kč
€ 4.20 |
||
| 993 5 WHR110216 |
C00335151
482253280216 |
SALT FUNNEL | Na dotaz | Zadat poptávku | |
