WHIRLPOOL ADN 514/1 oven combi dir+el 11xGN1/1
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | ADN 514/1 oven combi dir+el 11xGN1/1 |
| Kód 12NC: | 854451401010 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Profesionální trouby , mikrovlnky , varné desky , konvektomaty |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| AZ362-00 WHR43476 |
C00406947
482000000453 |
Door glass INTERNAL | Na dotaz | Zadat poptávku | |
| AZ372-13 WHR43476 |
C00406948
482000000454 |
Profile door | Na dotaz | Zadat poptávku | |
| C1418-12 WHR43476 |
C00424115
483286012027 |
Nozzle d0,7mm | Na dotaz | Zadat poptávku | |
| C1707-00 WHR43476 |
C00422797
483286010472 |
Reductor ,water flow | Na dotaz | Zadat poptávku | |
| C1710-13 WHR43476 |
C00420604
483286002396 |
Holder ,brass pipe | Na dotaz | Zadat poptávku | |
| C1715-00 WHR43476 |
C00420666
483286002465 |
Nozzle ,WATER FOR HUMIDITY 0,40MM | Na dotaz | Zadat poptávku | |
| C1719-00 WHR43476 |
C00421386
483286003276 |
Nozzle ,D=0,6 mm | Na dotaz | Zadat poptávku | |
| C2027-00 WHR43476 |
C00501109
483286008697 |
Gasket steamtight f.engine shaft | Na dotaz | Zadat poptávku | |
| C2028-00 WHR43476 |
C00501110
483286008698 |
Flange for engine shaft 17 diam. | Na dotaz | Zadat poptávku | |
| C2029-00 WHR43476 |
C00501111
483286008699 |
Lock flange f. enginge shaft | Na dotaz | Zadat poptávku | |
| C2088-00 WHR43476 |
C00581934
483286008703 |
Valve water filling solenoid | Na dotaz | Zadat poptávku | |
| C2125-00 WHR43476 |
C00422462
483286010093 |
Filter draining | Na dotaz | Zadat poptávku | |
| C2198-00 WHR43476 |
C00581907
483286008208 |
Thermostat safety | Na dotaz | Zadat poptávku | |
| C2277-00 WHR43476 |
C00421105
483286002962 |
Bicone | Na dotaz | Zadat poptávku | |
| C2290-00 WHR43476 |
C00420662
483286002461 |
SUPPORT ,core probe | Na dotaz | Zadat poptávku | |
| C2291-00 WHR43476 |
C00420663
483286002462 |
Tube ,for core probe location | Na dotaz | Zadat poptávku | |
| C2325-00 WHR43476 |
C00420698
483286002501 |
Foot | Na dotaz | Zadat poptávku | |
| C2900-00 WHR43476 |
C00423251
483286010996 |
Motor | Na dotaz | Zadat poptávku | |
| C5410-00 WHR43476 |
C00581902
483286008203 |
Pilot lamp green | Na dotaz | Zadat poptávku | |
| C5420-00 WHR43476 |
C00581928
483286008692 |
Button reset gas alarm | Na dotaz | Zadat poptávku | |
| C5918-00 WHR43476 |
C00420795
483286002608 |
Cap ,for hole boiler gas | Na dotaz | Zadat poptávku | |
| C5919-00 WHR43476 |
C00420794
483286002607 |
Gasket ,for cap boiler gas | Na dotaz | Zadat poptávku | |
| C5920-00 WHR43476 |
C00420793
483286002606 |
Glass ,for gas boiler checking | Na dotaz | Zadat poptávku | |
| C5940-00 WHR43476 |
C00420752
483286002561 |
Gasket ,for burner flange | Na dotaz | Zadat poptávku | |
| C5950-00 WHR43476 |
C00420749
483286002557 |
Fan | Na dotaz | Zadat poptávku | |
| C5956-00 WHR43476 |
C00420750
483286002558 |
Control board ,for fan | Na dotaz | Zadat poptávku | |
| C5960-00 WHR43476 |
C00420759
483286002568 |
Valve ,gas solenoid | Na dotaz | Zadat poptávku | |
| C5965-12 WHR43476 |
C00408307
482000003327 |
Electronic box | Na dotaz | Zadat poptávku | |
| C5966-00 WHR43476 |
C00420764
483286002574 |
Cap ,for central connector | Na dotaz | Zadat poptávku | |
| C5971-00 WHR43476 |
C00423245
483286010989 |
Pipe ,venturi+gasket | Na dotaz | Zadat poptávku | |
| C5975-00 WHR43476 |
C00420762
483286002572 |
Gasket ,for valve | Na dotaz | Zadat poptávku | |
| C5980-00 WHR43476 |
C00420747
483286002555 |
Flange ,curved | Na dotaz | Zadat poptávku | |
| C6073C-00 WHR43476 |
C00423248
483286010993 |
Glass ,lamp | Na dotaz | Zadat poptávku | |
| C6073D-00 WHR43476 |
C00423249
483286010994 |
Frame ,lamp holder | Na dotaz | Zadat poptávku | |
| C6073F-00 WHR43476 |
C00423250
483286010995 |
Gasket ,bulb socket | Na dotaz | Zadat poptávku | |
| C7412-00 WHR43476 |
C00420773
483286002584 |
Gasket ,for burner | Na dotaz | Zadat poptávku | |
| C7431-00 WHR43476 |
C00420789
483286002602 |
Bracket ,to fix venturi | Na dotaz | Zadat poptávku | |
| C7432-00 WHR43476 |
C00420785
483286002597 |
Tube ,air regulation | Na dotaz | Zadat poptávku | |
| C7564-00 WHR43476 |
C00422795
483286010469 |
Lock ,HANDLE | Na dotaz | Zadat poptávku | |
| C8118-00CR WHR43476 |
C00422788
483286010461 |
Rukojeť konvektomatu | 21 344 Kč
€ 938.20 |
||
| C8138-00 WHR43476 |
C00420653
483286002451 |
sonda | 3 232 Kč
€ 142.10 |
||
| C8162-00 WHR43476 |
C00420679
483286002479 |
Switch ,6 positions 16A 600V | Na dotaz | Zadat poptávku | |
| C8165-00 WHR43476 |
C00420340
483286002099 |
elektronika | Na dotaz | Zadat poptávku | |
| C8248-00 WHR43476 |
C00420657
483286002455 |
Probe ,electronic keyboard | Na dotaz | Zadat poptávku | |
| C8250-22 WHR43476 |
C00420661
483286002459 |
Probe ,core temperature PT1000 | Na dotaz | Zadat poptávku | |
| C8293-00 WHR43476 |
C00424106
483286012017 |
Knob | Na dotaz | Zadat poptávku | |
| C8294-00 WHR43476 |
C00408308
482000003328 |
Knob | Na dotaz | Zadat poptávku | |
| C8304-00 WHR43476 |
C00406949
482000000455 |
Bushing DOOR | Na dotaz | Zadat poptávku | |
| C8310-00 WHR43476 |
C00424105
483286012016 |
Sensor magnetic | Na dotaz | Zadat poptávku | |
| C8311-00 WHR43476 |
C00406945
482000000451 |
Plate UPPER DOOR | Na dotaz | Zadat poptávku | |
| C9014-00K WHR43476 |
C00406955
482000000461 |
Fan | Na dotaz | Zadat poptávku | |
| C9021-00 WHR43476 |
C00424117
483286012029 |
Hinge upper | Na dotaz | Zadat poptávku | |
| C9022-00 WHR43476 |
C00424111
483286012023 |
Hinge lower | Na dotaz | Zadat poptávku | |
| C9023-00 WHR43476 |
C00422792
483286010466 |
Handle ,venting | Na dotaz | Zadat poptávku | |
| C9029-00 WHR43476 |
C00406944
482000000450 |
Gasket | Na dotaz | Zadat poptávku | |
| C9032-00 WHR43476 |
C00422793
483286010467 |
Gasket | Na dotaz | Zadat poptávku | |
| C9034-00 WHR43476 |
C00406951
482000000457 |
Pin | Na dotaz | Zadat poptávku | |
| C9037-00 WHR43476 |
C00406952
482000000458 |
Holder | Na dotaz | Zadat poptávku | |
| C9039-00 WHR43476 |
C00424110
483286012022 |
Spring | Na dotaz | Zadat poptávku | |
| C9045-00 WHR43476 |
C00423196
483286010935 |
Gasket ,ext, door | Na dotaz | Zadat poptávku | |
| C9063-00 WHR43476 |
C00423199
483286010938 |
Gasket | Na dotaz | Zadat poptávku | |
| C9073-00 WHR43476 |
C00406946
482000000452 |
Door glass EXTERNAL | Na dotaz | Zadat poptávku | |
| C9084-12 WHR43476 |
C00406953
482000000459 |
Pipe WATER INLET | Na dotaz | Zadat poptávku | |
| C9085-00 WHR43476 |
C00406954
482000000460 |
Drainpipe | Na dotaz | Zadat poptávku | |
| C9160-00 WHR43476 |
C00406950
482000000456 |
Hinge DOOR GLAS | Na dotaz | Zadat poptávku | |
| C9309-00 WHR43476 |
C00409047
482000004986 |
Spark plug | Na dotaz | Zadat poptávku | |
| FX0068-12 WHR43476 |
C00373262
483286008695 |
Motor fan 220V AC | Na dotaz | Zadat poptávku | |
| HR-040 WHR43476 |
C00420682
483286002483 |
Nipple ,T type 1/8 of brass | Na dotaz | Zadat poptávku | |
| IM-030 WHR43476 |
C00420650
483286002447 |
Cable clamp | Na dotaz | Zadat poptávku | |
| IR-121 WHR43476 |
C00422480
483286010113 |
Cable holder | Na dotaz | Zadat poptávku | |
| LA-052 WHR43476 |
C00422472
483286010104 |
Cable holder | Na dotaz | Zadat poptávku | |
| LA-062 WHR43476 |
C00422473
483286010105 |
Nut | Na dotaz | Zadat poptávku | |
| LC-050 WHR43476 |
C00424113
483286012025 |
Holder lamp | Na dotaz | Zadat poptávku | |
| LC-051 WHR43476 |
C00424114
483286012026 |
Lamp,halogen 230V 40 | Na dotaz | Zadat poptávku | |
| LC-310 WHR43476 |
C00420619
483286002413 |
Contactor ,mini 10A 230V 50-60Hz | Na dotaz | Zadat poptávku | |
| LC-312 WHR43476 |
C00420691
483286002493 |
Filter ,RFI BG x79240 | Na dotaz | Zadat poptávku | |
| LC-315 WHR43476 |
C00421191
483286003058 |
Contactor ,auxiliary | Na dotaz | Zadat poptávku | |
| LC-317 WHR43476 |
C00581941
483286008712 |
Filter R.F.I. 250V 50-60 Hz | Na dotaz | Zadat poptávku | |
| LC-411 WHR43476 |
C00424312
483286012291 |
Terminal Board 6-12 | Na dotaz | Zadat poptávku | |
| LC-416 WHR43476 |
C00420665
483286002464 |
Fuse ,1A 5x20 AC 250V | Na dotaz | Zadat poptávku | |
| LC-420 WHR43476 |
C00581948
483286008719 |
Holder fuse | Na dotaz | Zadat poptávku | |
| LC-422 WHR43476 |
C00581917
483286008225 |
Fuse 2A | Na dotaz | Zadat poptávku | |
| LC-426 WHR43476 |
C00424112
483286012024 |
Fuse 60 MA 5x20 | Na dotaz | Zadat poptávku | |
| LC-442 WHR43476 |
C00422794
483286010468 |
Transformer ,230/12V | Na dotaz | Zadat poptávku | |
| LC-445 WHR43476 |
C00420748
483286002556 |
Transformer ,1F 60VA 230/12V | Na dotaz | Zadat poptávku | |
| MC-802 WHR43476 |
C00422481
483286010114 |
Regulator encoder | Na dotaz | Zadat poptávku | |
| PTUN-016-0 WHR43476 |
C00423247
483286010992 |
Nozzle | Na dotaz | Zadat poptávku | |
