WHIRLPOOL AFB 815 FREEZING INTEGRETABLE WP
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AFB 815 FREEZING INTEGRETABLE WP |
| Kód 12NC: | 850481501030 |
| I.C. kód: | 850481501031 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Vestavné mrazáky |
| Další podobné modely: | 850481501035 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 040 0 WHR77652 |
C00576467
481941719091 |
Hinge upper.. | Na dotaz | Zadat poptávku | |
| 040 1 WHR77652 |
C00576469
481941719092 |
Hinge upper.. | Na dotaz | Zadat poptávku | |
| 040 2 WHR77652 |
C00576471
481941719094 |
Hinge lower.. | Na dotaz | Zadat poptávku | |
| 040 4 WHR77652 |
C00576470
481941719093 |
Hinge lower.. | Na dotaz | Zadat poptávku | |
| 045 6 WHR77652 |
C00484396
481941718655 |
Bearing hinge | Na dotaz | Zadat poptávku | |
| 045 8 WHR77652 |
C00311311
481953598188 |
Osa závěsu dveří vestavné lednice Whirlpool | 229 Kč
€ 9.40 |
||
| 070 0 WHR77652 |
C00576476
481944228539 |
Pedestal.. | Na dotaz | Zadat poptávku | |
| 070 5 WHR77652 |
C00576464
481940449973 |
Bracket.. | Na dotaz | Zadat poptávku | |
| 101 0 WHR77652 |
C00576479
481944229946 |
Door,freezer.. | Na dotaz | Zadat poptávku | |
| 105 0 WHR77652 |
C00480556
481940478788 |
Support upper left | Na dotaz | Zadat poptávku | |
| 105 1 WHR77652 |
C00480555
481940478787 |
Support upper right | Na dotaz | Zadat poptávku | |
| 105 2 WHR77652 |
C00480554
481940478786 |
Support lower left | Na dotaz | Zadat poptávku | |
| 105 3 WHR77652 |
C00480553
481940478785 |
Support lower right | Na dotaz | Zadat poptávku | |
| 105 4 WHR77652 |
C00492649
481953268108 |
Stop door upper | Na dotaz | Zadat poptávku | |
| 105 5 WHR77652 |
C00557596
481953268107 |
STOP,DOOR LOWER.. | Na dotaz | Zadat poptávku | |
| 105 6 WHR77652 |
C00492645
481953258131 |
Spacer | Na dotaz | Zadat poptávku | |
| 156 0 WHR77652 |
C00333002
481941848116 |
NÁDOBKA NA LED | Na dotaz | Zadat poptávku | |
| 170 1 WHR77652 |
C00576377
481246079002 |
Trim ornamental side.. | Na dotaz | Zadat poptávku | |
| 170 3 WHR77652 |
C00576508
481946089229 |
Trim top.. | Na dotaz | Zadat poptávku | |
| 170 4 WHR77652 |
C00576509
481946089231 |
Trim lower.. | Na dotaz | Zadat poptávku | |
| 170 5 WHR77652 |
C00486672
481946058943 |
Trim crisper cooling | Na dotaz | Zadat poptávku | |
| 170 7 WHR77652 |
C00576507
481946078534 |
Trim side.. | Na dotaz | Zadat poptávku | |
| 191 1 WHR77652 |
C00381251
481946818131 |
Magnetic seal | Na dotaz | Zadat poptávku | |
| 204 4 WHR77652 |
C00557463
481941879753 |
zasuvka mrazaku | Na dotaz | Zadat poptávku | |
| 231 1 WHR77652 |
C00333126
481946688956 |
PLATE THERMOSTAT SENSOR | Na dotaz | Zadat poptávku | |
| 231 2 WHR77652 |
C00343341
481946689101 |
Clamp sensor | Na dotaz | Zadat poptávku | |
| 233 0 WHR77652 |
C00339653
481940479375 |
Holder ,EvaporatorEvaporator | Na dotaz | Zadat poptávku | |
| 233 1 WHR77652 |
C00339620
481940479374 |
drzak vyparniku | Na dotaz | Zadat poptávku | |
| 233 9 WHR77652 |
C00339621
481940479376 |
Holder evaporator | Na dotaz | Zadat poptávku | |
| 241 0 WHR77652 |
C00499264
481945819567 |
Koš mrazničky drátěný - horní | Na dotaz | Zadat poptávku | |
| 241 1 WHR77652 |
C00344495
481945819568 |
Koš mrazničky drátěný - spodní | Na dotaz | Zadat poptávku | |
| 241 3 WHR77652 |
C00499167
481944228498 |
kryt kos.pravy | Na dotaz | Zadat poptávku | |
| 241 4 WHR77652 |
C00576493
481944278379 |
celo kose mrazaku | Na dotaz | Zadat poptávku | |
| 252 0 WHR77652 |
C00576512
481946278553 |
Cabinet.. | Na dotaz | Zadat poptávku | |
| 252 1 WHR77652 |
C00576513
481946278554 |
Cap.. | Na dotaz | Zadat poptávku | |
| 263 0 WHR77652 |
C00340172
481946238886 |
kolejnice kose | Na dotaz | Zadat poptávku | |
| 301 0 WHR77652 |
C00492386
481945229124 |
Panel | Na dotaz | Zadat poptávku | |
| 321 0 WHR77652 |
C00490409
481938118057 |
Lens | Na dotaz | Zadat poptávku | |
| 321 1 WHR77652 |
C00576462
481938118056 |
Lens.. | Na dotaz | Zadat poptávku | |
| 335 0 WHR77652 |
C00574607
481941128757 |
GOMB?K TERMOSTATU AFG065 PLAST. N | Na dotaz | Zadat poptávku | |
| 335 3 WHR77652 |
C00576480
481944268079 |
CASING.. | Na dotaz | Zadat poptávku | |
| 351 2 WHR77652 |
C00498802
481913448192 |
Pilot lamp | Na dotaz | Zadat poptávku | |
| 402 0 WHR77652 |
C00555877
481936058757 |
NAHRADENE 481936038704 N | Na dotaz | Zadat poptávku | |
| 491 0 WHR77652 |
C00333099
481946279805 |
Cover,conn.bloc | Na dotaz | Zadat poptávku | |
| 561 2 WHR77652 |
C00332852
481929068367 |
Connectionblock ,ZanusZanussi | Na dotaz | Zadat poptávku | |
| 566 2 WHR77652 |
C00498836
481927128833 |
termostat A04-0153 | Na dotaz | Zadat poptávku | |
| 614 1 WHR77652 |
C00327494
481228068337 |
Monoblock | Na dotaz | Zadat poptávku | |
| 620 0 WHR77652 |
C00498860
481927718128 |
signalka | Na dotaz | Zadat poptávku | |
| 620 1 WHR77652 |
C00335705
481927718127 |
signalka | Na dotaz | Zadat poptávku | |
| 740 0 WHR77652 |
C00499539
481951148532 |
Condenser | Na dotaz | Zadat poptávku | |
| 740 4 WHR77652 |
C00328255
481244048012 |
Holder condenser | Na dotaz | Zadat poptávku | |
| 745 0 WHR77652 |
C00576424
481251138153 |
vyparnik | Na dotaz | Zadat poptávku | |
| 764 2 WHR77652 |
C00266743
481948028144 |
Filtr chladničky - patrona Náhrada C00495431 |
Na dotaz | Zadat poptávku | |
| 781 0 WHR77652 |
C00342193
481953228145 |
Defroster plug | Na dotaz | Zadat poptávku | |
| 781 1 WHR77652 |
C00499108
481941849577 |
ODTOKOVY ZLIABOK N | Na dotaz | Zadat poptávku | |
| 993 9 WHR77652 |
C00484288
481931039813 |
Accessories (not shown) | Na dotaz | Zadat poptávku | |
| 999 WHR77652 |
C00705119 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
