| Komerční kód: | AGS 905/WP - Prof Oven combi 10 x GN2/1 |
| Kód 12NC: | 856390501000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Profesionální trouby , mikrovlnky , varné desky , konvektomaty |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 011 0 WHR69831 |
C00420811
483286002626 |
Foot ,with sleeve | Na dotaz | Zadat poptávku | |
| 040 1 WHR69831 |
C00420812
483286002627 |
Hinge ,cpl lower | Na dotaz | Zadat poptávku | |
| 040 2 WHR69831 |
C00420813
483286002628 |
Hinge ,door top | Na dotaz | Zadat poptávku | |
| 040 3 WHR69831 |
C00420814
483286002629 |
Hinge ,door top | Na dotaz | Zadat poptávku | |
| 110 0 WHR69831 |
C00420588
483286002378 |
Handle PORTA XT-M2005.072-3 | Na dotaz | Zadat poptávku | |
| 110 1 WHR69831 |
C00581952
483286008725 |
Lock for handle | Na dotaz | Zadat poptávku | |
| 130 0 WHR69831 |
C00420591
483286002382 |
Lock MECCANISMO PER APRIRE CHIUDERE | Na dotaz | Zadat poptávku | |
| 141 0 WHR69831 |
C00420815
483286002631 |
Glass ,internal door | Na dotaz | Zadat poptávku | |
| 141 1 WHR69831 |
C00420816
483286002632 |
Glass ,neutral door | Na dotaz | Zadat poptávku | |
| 191 0 WHR69831 |
C00420817
483286002633 |
Gasket | Na dotaz | Zadat poptávku | |
| 191 1 WHR69831 |
C00420818
483286002634 |
Gasket ,oven door | Na dotaz | Zadat poptávku | |
| 191 2 WHR69831 |
C00420819
483286002635 |
Rubber ,strap horizontal | Na dotaz | Zadat poptávku | |
| 191 3 WHR69831 |
C00420820
483286002636 |
Rubber ,strap vertical | Na dotaz | Zadat poptávku | |
| 192 0 WHR69831 |
C00420821
483286002637 |
Gasket ,external | Na dotaz | Zadat poptávku | |
| 192 1 WHR69831 |
C00420822
483286002638 |
Gasket ,internal door | Na dotaz | Zadat poptávku | |
| 331 0 WHR69831 |
C00420595
483286002386 |
Knob ,cycles selection | Na dotaz | Zadat poptávku | |
| 331 2 WHR69831 |
C00420647
483286002444 |
Knob ,050 | Na dotaz | Zadat poptávku | |
| 351 1 WHR69831 |
C00581902
483286008203 |
Pilot lamp green | Na dotaz | Zadat poptávku | |
| 404 1 WHR69831 |
C00420604
483286002396 |
Holder ,brass pipe | Na dotaz | Zadat poptávku | |
| 411 0 WHR69831 |
C00420687
483286002488 |
Transformer ,single phase 100VA 230V | Na dotaz | Zadat poptávku | |
| 421 0 WHR69831 |
C00420606
483286002398 |
Filter ,interfer. +cable connect | Na dotaz | Zadat poptávku | |
| 421 1 WHR69831 |
C00420685
483286002486 |
Filter ,RFI G479240 | Na dotaz | Zadat poptávku | |
| 421 2 WHR69831 |
C00581941
483286008712 |
Filter R.F.I. 250V 50-60 Hz | Na dotaz | Zadat poptávku | |
| 440 0 WHR69831 |
C00373263
483286008681 |
Motor 3-phase 230/400V 50/60 Hz | Na dotaz | Zadat poptávku | |
| 440 1 WHR69831 |
C00501109
483286008697 |
Gasket steamtight f.engine shaft | Na dotaz | Zadat poptávku | |
| 440 2 WHR69831 |
C00501110
483286008698 |
Flange for engine shaft 17 diam. | Na dotaz | Zadat poptávku | |
| 440 3 WHR69831 |
C00501111
483286008699 |
Lock flange f. enginge shaft | Na dotaz | Zadat poptávku | |
| 442 0 WHR69831 |
C00373262
483286008695 |
Motor fan 220V AC | Na dotaz | Zadat poptávku | |
| 443 0 WHR69831 |
C00421106
483286002963 |
Fan | Na dotaz | Zadat poptávku | |
| 451 0 WHR69831 |
C00420695
483286002497 |
Heating element ,3 phase 11000W 230V | Na dotaz | Zadat poptávku | |
| 474 0 WHR69831 |
C00420607
483286002399 |
Nozzle ,0,7mm for steam condens. | Na dotaz | Zadat poptávku | |
| 474 1 WHR69831 |
C00420666
483286002465 |
Nozzle ,WATER FOR HUMIDITY 0,40MM | Na dotaz | Zadat poptávku | |
| 474 2 WHR69831 |
C00420667
483286002466 |
Nozzle ,water for humidity 0,50mm | Na dotaz | Zadat poptávku | |
| 474 3 WHR69831 |
C00420608
483286002401 |
Nozzle ,1/4 M DIAM 7 | Na dotaz | Zadat poptávku | |
| 483 0 WHR69831 |
C00420684
483286002485 |
Connector ,pipe Y type | Na dotaz | Zadat poptávku | |
| 491 0 WHR69831 |
C00420723
483286002528 |
Terminal Board ,compl. | Na dotaz | Zadat poptávku | |
| 491 1 WHR69831 |
C00420638
483286002434 |
Relay ,electro | Na dotaz | Zadat poptávku | |
| 491 2 WHR69831 |
C00420613
483286002406 |
Spring ,extension for electrom. | Na dotaz | Zadat poptávku | |
| 500 4 WHR69831 |
C00420678
483286002478 |
Control board ,combi electronic | Na dotaz | Zadat poptávku | |
| 500 5 WHR69831 |
C00420340
483286002099 |
elektronika | Na dotaz | Zadat poptávku | |
| 500 6 WHR69831 |
C00420657
483286002455 |
Probe ,electronic keyboard | Na dotaz | Zadat poptávku | |
| 522 0 WHR69831 |
C00420824
483286002641 |
Microswitch ,with button | Na dotaz | Zadat poptávku | |
| 522 2 WHR69831 |
C00581934
483286008703 |
Valve water filling solenoid | Na dotaz | Zadat poptávku | |
| 522 3 WHR69831 |
C00420306
483286002062 |
ELEKTROVENTIL | Na dotaz | Zadat poptávku | |
| 522 4 WHR69831 |
C00420779
483286002591 |
Support ,water inlet | Na dotaz | Zadat poptávku | |
| 563 0 WHR69831 |
C00581935
483286008704 |
Thermostat condensation 30-90 #C | Na dotaz | Zadat poptávku | |
| 564 0 WHR69831 |
C00581907
483286008208 |
Thermostat safety | Na dotaz | Zadat poptávku | |
| 622 1 WHR69831 |
C00420679
483286002479 |
Switch ,6 positions 16A 600V | Na dotaz | Zadat poptávku | |
| 623 0 WHR69831 |
C00420668
483286002467 |
Contactor ,25A AC1 50-60 Hz | Na dotaz | Zadat poptávku | |
| 623 1 WHR69831 |
C00420802
483286002616 |
Contactor ,36A | Na dotaz | Zadat poptávku | |
| 651 0 WHR69831 |
C00581925
483286008688 |
Lamp,halogen 35W 12V | Na dotaz | Zadat poptávku | |
| 653 0 WHR69831 |
C00420629
483286002424 |
Plate ,door lighting | Na dotaz | Zadat poptávku | |
| 656 0 WHR69831 |
C00581924
483286008687 |
Holder lamp and cables 400mm | Na dotaz | Zadat poptávku | |
| 691 0 WHR69831 |
C00420653
483286002451 |
sonda | 3 232 Kč
€ 142.10 |
||
| 691 1 WHR69831 |
C00420662
483286002461 |
SUPPORT ,core probe | Na dotaz | Zadat poptávku | |
| 691 2 WHR69831 |
C00420663
483286002462 |
Tube ,for core probe location | Na dotaz | Zadat poptávku | |
| 691 3 WHR69831 |
C00420661
483286002459 |
Probe ,core temperature PT1000 | Na dotaz | Zadat poptávku | |
| 703 0 WHR69831 |
C00420803
483286002617 |
Contact ,10A | Na dotaz | Zadat poptávku | |
| 781 0 WHR69831 |
C00420825
483286002642 |
Pipe ,water drainage | Na dotaz | Zadat poptávku | |
| 900 0 WHR69831 |
C00420730
483286002536 |
Flange ,fix drain pipe | Na dotaz | Zadat poptávku | |
| 900 1 WHR69831 |
C00420826
483286002643 |
Lever ,to block the rack roll | Na dotaz | Zadat poptávku | |
| 900 3 WHR69831 |
C00420681
483286002482 |
Connector ,1/4x1/8 of brass | Na dotaz | Zadat poptávku | |
| 900 4 WHR69831 |
C00420683
483286002484 |
Nipple ,1/2x3/4 of brass | Na dotaz | Zadat poptávku | |
| 904 0 WHR69831 |
C00581912
483286008217 |
Hinge bushing | Na dotaz | Zadat poptávku | |
| 921 0 WHR69831 |
C00421105
483286002962 |
Bicone | Na dotaz | Zadat poptávku | |
| 921 1 WHR69831 |
C00420827
483286002644 |
Wheel ,for roll in rack | Na dotaz | Zadat poptávku | |
| 972 0 WHR69831 |
C00420665
483286002464 |
Fuse ,1A 5x20 AC 250V | Na dotaz | Zadat poptávku | |
| 972 1 WHR69831 |
C00581948
483286008719 |
Holder fuse | Na dotaz | Zadat poptávku | |
| 972 2 WHR69831 |
C00581917
483286008225 |
Fuse 2A | Na dotaz | Zadat poptávku | |
| 972 3 WHR69831 |
C00420686
483286002487 |
Fuse ,6,3A rapid 5x20 | Na dotaz | Zadat poptávku | |
