| Komerční kód: | AHO119 |
| Kód 12NC: | 850221901000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Profesionální trouby , mikrovlnky , varné desky , konvektomaty |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 713-005-00 WHR46231 |
C00417541
482000021364 |
Foot | Na dotaz | Zadat poptávku | |
| 715-011-00 WHR46231 |
C00417659
482000021519 |
Dispencer water | Na dotaz | Zadat poptávku | |
| 717-009-00 WHR46231 |
C00417582
482000021432 |
Gas cock | Na dotaz | Zadat poptávku | |
| 717-094-00 WHR46231 |
C00417660
482000021520 |
Nozzle 00,80 LPG | Na dotaz | Zadat poptávku | |
| 719-012-00 WHR46231 |
C00417661
482000021521 |
Connection | Na dotaz | Zadat poptávku | |
| 725-013-00 WHR46231 |
C00417662
482000021522 |
Connection Y | Na dotaz | Zadat poptávku | |
| 727-008-00 WHR46231 |
C00417663
482000021523 |
Magnet | Na dotaz | Zadat poptávku | |
| 733-011-00 WHR46231 |
C00417664
482000021524 |
Pipe 37x25 L.=0.53 mt | Na dotaz | Zadat poptávku | |
| 733-012-00 WHR46231 |
C00417665
482000021525 |
Pipe 28.5x18 L.=0.07 mt | Na dotaz | Zadat poptávku | |
| 733-016-00 WHR46231 |
C00417666
482000021526 |
Pipe 10x17 L=0.95 mt | Na dotaz | Zadat poptávku | |
| 733-017-00 WHR46231 |
C00417667
482000021527 |
Pipe 4x10 L=0.22 mt | Na dotaz | Zadat poptávku | |
| 761-005-00 WHR46231 |
C00417668
482000021528 |
Knob | Na dotaz | Zadat poptávku | |
| 761-006-00 WHR46231 |
C00417547
482000021370 |
Knob | Na dotaz | Zadat poptávku | |
| 761-011-00 WHR46231 |
C00417613
482000021463 |
Indication disc rear gas tab | Na dotaz | Zadat poptávku | |
| 761-029-00 WHR46231 |
C00417669
482000021529 |
Indication disc | Na dotaz | Zadat poptávku | |
| 764-006-00 WHR46231 |
C00417616
482000021466 |
Ring | Na dotaz | Zadat poptávku | |
| 764-007-00 WHR46231 |
C00417549
482000021372 |
Gasket control panel | Na dotaz | Zadat poptávku | |
| 765-023-00 WHR46231 |
C00417550
482000021373 |
Cover protect. piezoelectric | Na dotaz | Zadat poptávku | |
| 765-024-00 WHR46231 |
C00417617
482000021467 |
Gasket silicon | Na dotaz | Zadat poptávku | |
| 765-025-00 WHR46231 |
C00417670
482000021530 |
Gasket silicone | Na dotaz | Zadat poptávku | |
| 765-029-00 WHR46231 |
C00417551
482000021374 |
Damper | Na dotaz | Zadat poptávku | |
| 774-010-00 WHR46231 |
C00417671
482000021531 |
Cable clamp | Na dotaz | Zadat poptávku | |
| 774-024-00 WHR46231 |
C00417552
482000021375 |
Terminal strip | Na dotaz | Zadat poptávku | |
| 774-042-00 WHR46231 |
C00417672
482000021532 |
Relay | Na dotaz | Zadat poptávku | |
| 774-043-00 WHR46231 |
C00417673
482000021533 |
Pedestal Relay | Na dotaz | Zadat poptávku | |
| 776-009-00 WHR46231 |
C00417674
482000021534 |
Pressure regul. | Na dotaz | Zadat poptávku | |
| 776-014-00 WHR46231 |
C00417675
482000021535 |
Pilot lamp green | Na dotaz | Zadat poptávku | |
| 776-022-00 WHR46231 |
C00417676
482000021536 |
Inlet valve | Na dotaz | Zadat poptávku | |
| 776-024-00 WHR46231 |
C00417677
482000021537 |
Selector switch 4 pos. | Na dotaz | Zadat poptávku | |
| 804-031-00 WHR46231 |
C00417678
482000021538 |
Extension piece water valve | Na dotaz | Zadat poptávku | |
| 812-386-00 WHR46231 |
C00417553
482000021376 |
Door | Na dotaz | Zadat poptávku | |
| 812-654-00 WHR46231 |
C00417679
482000021539 |
Plate bottom | Na dotaz | Zadat poptávku | |
| 814-141-00 WHR46231 |
C00417555
482000021378 |
Hinge left | Na dotaz | Zadat poptávku | |
| 814-142-00 WHR46231 |
C00417556
482000021379 |
Hinge right | Na dotaz | Zadat poptávku | |
| 840-067-00 WHR46231 |
C00417680
482000021540 |
Control panel | Na dotaz | Zadat poptávku | |
| 872-044-00 WHR46231 |
C00417559
482000021382 |
Ring protecting piezoelectric | Na dotaz | Zadat poptávku | |
| 876-178-00 WHR46231 |
C00417681
482000021541 |
Pipe dispenser | Na dotaz | Zadat poptávku | |
| 878-025-00 WHR46231 |
C00417682
482000021542 |
Drainpipe | Na dotaz | Zadat poptávku | |
| 878-026-00 WHR46231 |
C00417683
482000021543 |
Pipe pressure switch | Na dotaz | Zadat poptávku | |
| 982-005-00 WHR46231 |
C00417561
482000021384 |
Door handle assemby | Na dotaz | Zadat poptávku | |
| AVA015ZR10 WHR46231 |
C00422750
483286010418 |
Tap cock | Na dotaz | Zadat poptávku | |
| AVA017ZR10 WHR46231 |
C00422723
483286010388 |
Handle | Na dotaz | Zadat poptávku | |
| DGI175N30D WHR46231 |
C00417684
482000021544 |
Nozzle 0175 LPG | Na dotaz | Zadat poptávku | |
| DGI260N30D WHR46231 |
C00417685
482000021545 |
Nozzle 0260 NG | Na dotaz | Zadat poptávku | |
| M02100 WHR46231 |
C00497226
483286009198 |
Spinac | 1 073 Kč
€ 47.20 |
||
| X11900 WHR46231 |
C00417626
482000021476 |
Nut | Na dotaz | Zadat poptávku | |
| X12000 WHR46231 |
C00417627
482000021477 |
Pipe | Na dotaz | Zadat poptávku | |
| X12400 WHR46231 |
C00417628
482000021478 |
Nut pilot | Na dotaz | Zadat poptávku | |
| X12500 WHR46231 |
C00417629
482000021479 |
Pipe pilot | Na dotaz | Zadat poptávku | |
| X13500 WHR46231 |
C00495139
483286009215 |
Spark plug | Na dotaz | Zadat poptávku | |
| X14100 WHR46231 |
C00501151
483286009294 |
TERMOPOISTKA PREDNA | Na dotaz | Zadat poptávku | |
| X14600 WHR46231 |
C00501137
483286009205 |
GENERATOR | Na dotaz | Zadat poptávku | |
| X16100 WHR46231 |
C00417632
482000021482 |
Injector holder | Na dotaz | Zadat poptávku | |
| X16300 WHR46231 |
C00417633
482000021483 |
Nut | Na dotaz | Zadat poptávku | |
| X16400 WHR46231 |
C00417634
482000021484 |
Gasket Aluminium | Na dotaz | Zadat poptávku | |
| X19906 WHR46231 |
C00501145
483286009257 |
Nozzle oven pilot LPG | Na dotaz | Zadat poptávku | |
| X23900 WHR46231 |
C00495157
483286009304 |
Burner | Na dotaz | Zadat poptávku | |
| X41000 WHR46231 |
C00524883
483286009303 |
Cable H.T L=1000 | Na dotaz | Zadat poptávku | |
| X59200 WHR46231 |
C00512854
483286009191 |
Terminal Board | Na dotaz | Zadat poptávku | |
| 999 WHR46233 |
C00638356 | Gastable WHP | Na dotaz | Zadat poptávku | |
