WHIRLPOOL AKG 644/NB/02
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AKG 644/NB/02 |
| Kód 12NC/I.C. kód: | 853564438070 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Vestavné trouby a varné desky |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 022 1 WHR55982 |
C00403214
481244011702 |
Side panel ,B600 left/right | Na dotaz | Zadat poptávku | |
| 040 0 WHR55982 |
C00621902
481241719492 |
Hinge ,oven door | Na dotaz | Zadat poptávku | |
| 040 1 WHR55982 |
C00621904
481241758404 |
Hinge support | Na dotaz | Zadat poptávku | |
| 040 2 WHR55982 |
C00329728
481241719297 |
Hinge support oven door | Na dotaz | Zadat poptávku | |
| 100 0 WHR55982 |
C00377647
481241610559 |
Door ,outer | Na dotaz | Zadat poptávku | |
| 110 0 WHR55982 |
C00404897
481246269002 |
Handle ,black WP Giove 461 | Na dotaz | Zadat poptávku | |
| 110 1 WHR55982 |
C00405394
481249878713 |
Support ,door handle | Na dotaz | Zadat poptávku | |
| 121 0 WHR55982 |
C00402578
481241610555 |
Door ,inner | Na dotaz | Zadat poptávku | |
| 143 0 WHR55982 |
C00377748
481245059879 |
Oven glass ,inner | Na dotaz | Zadat poptávku | |
| 191 0 WHR55982 |
C00405167
481246818392 |
Gasket ,B600 | Na dotaz | Zadat poptávku | |
| 200 1 WHR55982 |
C00114088
481240418621 |
BRACKET RETAINER | Na dotaz | Zadat poptávku | |
| 245 0 WHR55982 |
C00621707
481245819392 |
Grid ,oven | Na dotaz | Zadat poptávku | |
| 247 0 WHR55982 |
C00335320
481241838093 |
Tray oven | Na dotaz | Zadat poptávku | |
| 248 0 WHR55982 |
C00405979
481253578097 |
Rotary spit ,B500 | Na dotaz | Zadat poptávku | |
| 248 1 WHR55982 |
C00402187
481240478922 |
Support ,spit | Na dotaz | Zadat poptávku | |
| 256 0 WHR55982 |
C00621711
481246689009 |
Protector ,knobs | Na dotaz | Zadat poptávku | |
| 256 1 WHR55982 |
C00621894
481240449859 |
drzak | Na dotaz | Zadat poptávku | |
| 261 0 WHR55982 |
C00621933
481245819393 |
Grid ,oven shelve right | Na dotaz | Zadat poptávku | |
| 261 1 WHR55982 |
C00621934
481245858528 |
Grid ,oven shelf left B600 | Na dotaz | Zadat poptávku | |
| 261 2 WHR55982 |
C00328960
481240418118 |
Bracket | Na dotaz | Zadat poptávku | |
| 301 0 WHR55982 |
C00404151
481245350385 |
Support ,control panel | Na dotaz | Zadat poptávku | |
| 320 0 WHR55982 |
C00404153
481245350387 |
Control panel ,+ holder | Na dotaz | Zadat poptávku | |
| 320 1 WHR55982 |
C00401895
481240418623 |
Bracket ,control panel B600 | Na dotaz | Zadat poptávku | |
| 334 0 WHR55982 |
C00487131
481241128851 |
Knob black | Na dotaz | Zadat poptávku | |
| 334 3 WHR55982 |
C00487132
481241128852 |
Knob gas, black | Na dotaz | Zadat poptávku | |
| 351 0 WHR55982 |
C00311750
481213428063 |
Pilot lamp yellow | Na dotaz | Zadat poptávku | |
| 351 1 WHR55982 |
C00326832
481213448284 |
Pilot lamp green | Na dotaz | Zadat poptávku | |
| 401 0 WHR55982 |
C00328827
481236158359 |
Motor spit | Na dotaz | Zadat poptávku | |
| 441 0 WHR55982 |
C00344884
481236118641 |
Motor fan | Na dotaz | Zadat poptávku | |
| 452 0 WHR55982 |
C00292692
481225928959 |
UPPER ELEMENT OVEN/GRILL 230V 1900W WP | Na dotaz | Zadat poptávku | |
| 455 0 WHR55982 |
C00621803
481225948207 |
Burner ,oven B500/B600 | Na dotaz | Zadat poptávku | |
| 455 1 WHR55982 |
C00400809
481225948208 |
Burner ,casing B600G | Na dotaz | Zadat poptávku | |
| 474 0 WHR55982 |
C00254192
481231039213 |
VSTŘIKOVAČE D.1,15 | Na dotaz | Zadat poptávku | |
| 483 0 WHR55982 |
C00402076
481240449861 |
Support ,chimney B600GAS | Na dotaz | Zadat poptávku | |
| 491 0 WHR55982 |
C00401346
481232128503 |
Terminal block ,+cable PA244N 1 | Na dotaz | Zadat poptávku | |
| 503 0 WHR55982 |
C00377455
481221478907 |
Timer | Na dotaz | Zadat poptávku | |
| 554 0 WHR55982 |
C00377530
481228208691 |
Thermostat ,B500GE 1V | Na dotaz | Zadat poptávku | |
| 564 0 WHR55982 |
C00319446
481228248286 |
termostat | Na dotaz | Zadat poptávku | |
| 591 0 WHR55982 |
C00400769
481225268089 |
Spark plug ,B5/600G L=850 | Na dotaz | Zadat poptávku | |
| 592 0 WHR55982 |
C00621797
481213838054 |
Thermo couple ,L=1200 m8X1 7S9 | Na dotaz | Zadat poptávku | |
| 595 0 WHR55982 |
C00399901
481214528042 |
Generator ,ignition 2B | Na dotaz | Zadat poptávku | |
| 622 0 WHR55982 |
C00318223
481227618399 |
Switch oven selector | Na dotaz | Zadat poptávku | |
| 651 0 WHR55982 |
C00400777
481225528025 |
Oven lamp 25W | Na dotaz | Zadat poptávku | |
| 656 0 WHR55982 |
C00328847
481238118279 |
Lens green | Na dotaz | Zadat poptávku | |
| 656 1 WHR55982 |
C00311674
481221778107 |
Lens lens (yellow) | Na dotaz | Zadat poptávku | |
| 703 4 WHR55982 |
C00405898
481253049342 |
Holder ,jet B500/B600G | Na dotaz | Zadat poptávku | |
| 703 5 WHR55982 |
C00405899
481253049343 |
Tube ,oven burner B600 | Na dotaz | Zadat poptávku | |
| 703 6 WHR55982 |
C00254197
481253049344 |
RAMPA B600G | Na dotaz | Zadat poptávku | |
| 703 7 WHR55982 |
C00401894
481240418622 |
Bracket ,0495SABAF | Na dotaz | Zadat poptávku | |
| 742 0 WHR55982 |
C00254028
481213638007 |
DEFLEKTORODVADĚČ VZDUCHU B500/B600 STAMP | Na dotaz | Zadat poptávku | |
| 743 0 WHR55982 |
C00399873
481213638008 |
Air conveyor ,B500/600 | Na dotaz | Zadat poptávku | |
| 743 1 WHR55982 |
C00399874
481213638009 |
Air conveyor ,inner B600/500 | Na dotaz | Zadat poptávku | |
| 781 1 WHR55982 |
C00403715
481244528078 |
Chimney ,exhaust. smokes B600gas | Na dotaz | Zadat poptávku | |
| 902 0 WHR55982 |
C00328449
481231039214 |
Mounting kit 4screws+bushings drawer | Na dotaz | Zadat poptávku | |
| 914 0 WHR55982 |
C00405436
481250218796 |
Nut ,nozzle holder | Na dotaz | Zadat poptávku | |
| 993 0 WHR55982 |
C00340032
481231048233 |
Handle for lifting oven | Na dotaz | Zadat poptávku | |
