| Komerční kód: | AMB 893 |
| Kód 12NC: | 852889310000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 021 1 WHR94852 |
C00584257
481252518012 |
Guide | Na dotaz | Zadat poptávku | |
| 033 0 WHR94852 |
C00749017
481244048341 |
Cabinet part | Na dotaz | Zadat poptávku | |
| 033 1 WHR94852 |
C00620302
481244138003 |
Cabinet | Na dotaz | Zadat poptávku | |
| 033 2 WHR94852 |
C00583724
481244048305 |
Housing. | Na dotaz | Zadat poptávku | |
| 033 3 WHR94852 |
C00496251
481244010604 |
Small plate,sid | Na dotaz | Zadat poptávku | |
| 033 4 WHR94852 |
C00583725
481244048306 |
Cover | Na dotaz | Zadat poptávku | |
| 033 5 WHR94852 |
C00748965
481246418109 |
Chassis | Na dotaz | Zadat poptávku | |
| 034 0 WHR94852 |
C00496254
481244048342 |
Cabinet | Na dotaz | Zadat poptávku | |
| 301 0 WHR94852 |
C00748966
481245310087 |
Display board | Na dotaz | Zadat poptávku | |
| 303 0 WHR94852 |
C00748967
481244229117 |
Bracket | Na dotaz | Zadat poptávku | |
| 320 0 WHR94852 |
C00748968
481245228187 |
Front panel | Na dotaz | Zadat poptávku | |
| 320 1 WHR94852 |
C00748970
481244029357 |
Chassis | Na dotaz | Zadat poptávku | |
| 320 2 WHR94852 |
C00748971
481248128165 |
Grill air inlet | Na dotaz | Zadat poptávku | |
| 402 0 WHR94852 |
C00527357
481236038845 |
Compressor 2JS438D3FB02 | Na dotaz | Zadat poptávku | |
| 440 0 WHR94852 |
C00633192
481236138065 |
ventilator klim. | Na dotaz | Zadat poptávku | |
| 443 0 WHR94852 |
C00748974
481236138053 |
Motor indoor fan | Na dotaz | Zadat poptávku | |
| 443 1 WHR94852 |
C00527451
481236118354 |
Ventilator | Na dotaz | Zadat poptávku | |
| 443 2 WHR94852 |
C00748976
481251548054 |
Fan indoor | Na dotaz | Zadat poptávku | |
| 491 0 WHR94852 |
C00505492
481221458214 |
kondenzator | 4 254 Kč
€ 187.00 |
||
| 521 0 WHR94852 |
C00500748
481221778151 |
Electr.device | Na dotaz | Zadat poptávku | |
| 521 1 WHR94852 |
C00500750
481221848067 |
Electr.device | Na dotaz | Zadat poptávku | |
| 521 2 WHR94852 |
C00748977
481246228223 |
Plate l. installation | Na dotaz | Zadat poptávku | |
| 572 2 WHR94852 |
C00620293
481236058318 |
Valve ,3 way | Na dotaz | Zadat poptávku | |
| 572 3 WHR94852 |
C00620464
481253038049 |
Valve | Na dotaz | Zadat poptávku | |
| 572 5 WHR94852 |
C00749018
481253029258 |
Pipe,exhaust | Na dotaz | Zadat poptávku | |
| 572 6 WHR94852 |
C00748981
481253029257 |
Suction pipe | Na dotaz | Zadat poptávku | |
| 572 7 WHR94852 |
C00749019
481236068531 |
Capillary tube | Na dotaz | Zadat poptávku | |
| 740 0 WHR94852 |
C00749020
481251148326 |
Condenser | Na dotaz | Zadat poptávku | |
| 741 0 WHR94852 |
C00748984
481246228225 |
Link | Na dotaz | Zadat poptávku | |
| 741 1 WHR94852 |
C00748985
481244029358 |
Panel horziontal | Na dotaz | Zadat poptávku | |
| 741 2 WHR94852 |
C00748986
481246228224 |
Panel vertical | Na dotaz | Zadat poptávku | |
| 741 3 WHR94852 |
C00748987
481240488063 |
Tray leak | Na dotaz | Zadat poptávku | |
| 741 4 WHR94852 |
C00748988
481240438609 |
Batten | Na dotaz | Zadat poptávku | |
| 741 5 WHR94852 |
C00496418
481236138054 |
Motor adjust | Na dotaz | Zadat poptávku | |
| 741 7 WHR94852 |
C00748989
481240448769 |
Rubber | Na dotaz | Zadat poptávku | |
| 745 1 WHR94852 |
C00748990
481251138237 |
Evaporator | Na dotaz | Zadat poptávku | |
| 765 0 WHR94852 |
C00499850
481248128164 |
Filter | Na dotaz | Zadat poptávku | |
| 781 0 WHR94852 |
C00748991
481253018029 |
Hose drain | Na dotaz | Zadat poptávku | |
| 900 0 WHR94852 |
C00811021
481240418381 |
CONTROL PANEL WHITE | Na dotaz | Zadat poptávku | |
| 900 2 WHR94852 |
C00748993
481240418163 |
Clamp | Na dotaz | Zadat poptávku | |
| 900 3 WHR94852 |
C00748994
481246228221 |
Plate Fastener | Na dotaz | Zadat poptávku | |
| 904 0 WHR94852 |
C00748995
481222608005 |
Cover | Na dotaz | Zadat poptávku | |
| 921 0 WHR94852 |
C00748996
481246228219 |
Cover motor | Na dotaz | Zadat poptávku | |
| 921 1 WHR94852 |
C00748997
481245228186 |
Plate r.installation | Na dotaz | Zadat poptávku | |
| 921 2 WHR94852 |
C00748998
481246228222 |
Bearing KIT | Na dotaz | Zadat poptávku | |
| 921 3 WHR94852 |
C00748999
481252008028 |
Bearing small | Na dotaz | Zadat poptávku | |
| 993 0 WHR94852 |
C00495875
481269028032 |
Remote control | Na dotaz | Zadat poptávku | |
| 999 WHR94852 |
C00763839 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
