| Komerční kód: | AMB 969 ECO SPLIT |
| Kód 12NC: | 852896910000 |
| I.C. kód: | 852896910002 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
| Další podobné modely: | 852896910000 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 004 3 WHR93269 |
C00401962
481240449589 |
Clamp A | Na dotaz | Zadat poptávku | |
| 004 4 WHR93269 |
C00500943
481256018072 |
Cover | Na dotaz | Zadat poptávku | |
| 004 5 WHR93269 |
C00401963
481240449591 |
Clamp B | Na dotaz | Zadat poptávku | |
| 004 6 WHR93269 |
C00394853
480150100039 |
Support | Na dotaz | Zadat poptávku | |
| 021 0 WHR93269 |
C00394854
480150100041 |
Grille front | Na dotaz | Zadat poptávku | |
| 021 1 WHR93269 |
C00394855
480150100042 |
Cover front | Na dotaz | Zadat poptávku | |
| 033 0 WHR93269 |
C00394856
480150100043 |
Cover top | Na dotaz | Zadat poptávku | |
| 033 2 WHR93269 |
C00394857
480150100044 |
Panel right | Na dotaz | Zadat poptávku | |
| 033 3 WHR93269 |
C00395440
480150100759 |
Base | Na dotaz | Zadat poptávku | |
| 033 4 WHR93269 |
C00394859
480150100046 |
Grille rear | Na dotaz | Zadat poptávku | |
| 033 5 WHR93269 |
C00394860
480150100047 |
Panel insulatin | Na dotaz | Zadat poptávku | |
| 033 7 WHR93269 |
C00394861
480150100048 |
Grille left | Na dotaz | Zadat poptávku | |
| 033 8 WHR93269 |
C00583725
481244048306 |
Cover | Na dotaz | Zadat poptávku | |
| 034 0 WHR93269 |
C00394862
480150100049 |
Support Motor | Na dotaz | Zadat poptávku | |
| 110 0 WHR93269 |
C00394863
480150100051 |
Handle left | Na dotaz | Zadat poptávku | |
| 110 1 WHR93269 |
C00584226
481249858202 |
Handle | Na dotaz | Zadat poptávku | |
| 303 0 WHR93269 |
C00395441
480150100761 |
Plate mounting | Na dotaz | Zadat poptávku | |
| 320 0 WHR93269 |
C00403361
481244048391 |
Cabinet | Na dotaz | Zadat poptávku | |
| 320 1 WHR93269 |
C00403359
481244048388 |
Cover front | Na dotaz | Zadat poptávku | |
| 320 2 WHR93269 |
C00500895
481246418118 |
Chassis | Na dotaz | Zadat poptávku | |
| 321 0 WHR93269 |
C00394864
480150100052 |
Cover protect. | Na dotaz | Zadat poptávku | |
| 321 1 WHR93269 |
C00403927
481245238231 |
Panel | Na dotaz | Zadat poptávku | |
| 350 0 WHR93269 |
C00395442
480150100762 |
Window Display | Na dotaz | Zadat poptávku | |
| 402 0 WHR93269 |
C00395443
480150100763 |
Compressor | Na dotaz | Zadat poptávku | |
| 412 0 WHR93269 |
C00394866
480150100054 |
Transformer | Na dotaz | Zadat poptávku | |
| 420 0 WHR93269 |
C00394888
480150100079 |
Capacitor Compressor | Na dotaz | Zadat poptávku | |
| 420 1 WHR93269 |
C00394826
480150100009 |
Terminal Board 5PU | Na dotaz | Zadat poptávku | |
| 420 2 WHR93269 |
C00584258
481252648125 |
Ring. | Na dotaz | Zadat poptávku | |
| 420 3 WHR93269 |
C00394835
480150100019 |
Terminal Board 3PS | Na dotaz | Zadat poptávku | |
| 420 4 WHR93269 |
C00583081
481221838261 |
Ring,adjusting | Na dotaz | Zadat poptávku | |
| 420 5 WHR93269 |
C00394870
480150100058 |
Terminal Board 2U | Na dotaz | Zadat poptávku | |
| 440 0 WHR93269 |
C00394868
480150100056 |
Motor fan Outdoor | Na dotaz | Zadat poptávku | |
| 440 1 WHR93269 |
C00394869
480150100057 |
Motor fan Indoor | Na dotaz | Zadat poptávku | |
| 443 0 WHR93269 |
C00395444
480150100764 |
Fan wheel Outdoor | Na dotaz | Zadat poptávku | |
| 443 1 WHR93269 |
C00394825
480150100008 |
Motor | Na dotaz | Zadat poptávku | |
| 443 4 WHR93269 |
C00621253
481236118353 |
VENTILATOR VONK.JEDNOTKY N | Na dotaz | Zadat poptávku | |
| 443 9 WHR93269 |
C00584261
481253029103 |
Set screw fan. | Na dotaz | Zadat poptávku | |
| 491 1 WHR93269 |
C00394822
480150100005 |
Capacitor Ventilator | Na dotaz | Zadat poptávku | |
| 491 2 WHR93269 |
C00394871
480150100059 |
Terminal Board 5P4 | Na dotaz | Zadat poptávku | |
| 521 1 WHR93269 |
C00394876
480150100065 |
Control board | Na dotaz | Zadat poptávku | |
| 521 2 WHR93269 |
C00394872
480150100061 |
Electronic box | Na dotaz | Zadat poptávku | |
| 521 3 WHR93269 |
C00394873
480150100062 |
Power unit | Na dotaz | Zadat poptávku | |
| 521 4 WHR93269 |
C00394831
480150100015 |
Clamp cable upper | Na dotaz | Zadat poptávku | |
| 521 5 WHR93269 |
C00394830
480150100014 |
Clamp cable lower | Na dotaz | Zadat poptávku | |
| 521 6 WHR93269 |
C00394852
480150100038 |
Clamp cable | Na dotaz | Zadat poptávku | |
| 521 7 WHR93269 |
C00394832
480150100016 |
Sensor Indoor | Na dotaz | Zadat poptávku | |
| 521 8 WHR93269 |
C00394875
480150100064 |
Sensor Outdoor | Na dotaz | Zadat poptávku | |
| 522 0 WHR93269 |
C00401270
481231618031 |
Clamp fixation | Na dotaz | Zadat poptávku | |
| 526 0 WHR93269 |
C00394877
480150100066 |
Electric plate | Na dotaz | Zadat poptávku | |
| 526 5 WHR93269 |
C00394878
480150100067 |
Cover Electronic box | Na dotaz | Zadat poptávku | |
| 701 1 WHR93269 |
C00583658
481240418377 |
Clamp. | Na dotaz | Zadat poptávku | |
| 701 2 WHR93269 |
C00583664
481240418425 |
Clamp. | Na dotaz | Zadat poptávku | |
| 740 0 WHR93269 |
C00394879
480150100068 |
Condenser | Na dotaz | Zadat poptávku | |
| 741 0 WHR93269 |
C00500801
481240488045 |
Batten | Na dotaz | Zadat poptávku | |
| 741 1 WHR93269 |
C00500800
481240488044 |
Batten | Na dotaz | Zadat poptávku | |
| 741 2 WHR93269 |
C00620391
481240448817 |
drzak vrtule ventil. | 42 Kč
€ 1.80 |
||
| 741 3 WHR93269 |
C00584220
481246678432 |
Deflector. | Na dotaz | Zadat poptávku | |
| 741 4 WHR93269 |
C00584219
481246678431 |
Deflector. | Na dotaz | Zadat poptávku | |
| 741 5 WHR93269 |
C00583679
481240488043 |
Batten left | Na dotaz | Zadat poptávku | |
| 745 0 WHR93269 |
C00395445
480150100765 |
Evaporator | Na dotaz | Zadat poptávku | |
| 751 0 WHR93269 |
C00404946
481246418182 |
miska na konden.kli | 1 166 Kč
€ 51.30 |
||
| 764 0 WHR93269 |
C00405175
481248028103 |
Air clean filt. left side | Na dotaz | Zadat poptávku | |
| 764 1 WHR93269 |
C00405174
481248028102 |
Air clean filt. right side | Na dotaz | Zadat poptávku | |
| 781 0 WHR93269 |
C00500772
481236068575 |
Pipe assembly | Na dotaz | Zadat poptávku | |
| 781 1 WHR93269 |
C00481269
481236058377 |
ventil | 2 580 Kč
€ 113.40 |
||
| 781 2 WHR93269 |
C00130965
481236058379 |
FIXING BRACKET GR300-1 | Na dotaz | Zadat poptávku | |
| 781 3 WHR93269 |
C00395446
480150100766 |
Coil Valve | Na dotaz | Zadat poptávku | |
| 781 5 WHR93269 |
C00395447
480150100767 |
Capillary tube | Na dotaz | Zadat poptávku | |
| 781 9 WHR93269 |
C00395448
480150100768 |
Support Valve | Na dotaz | Zadat poptávku | |
| 782 0 WHR93269 |
C00583637
481236068698 |
Hose,draining | Na dotaz | Zadat poptávku | |
| 782 1 WHR93269 |
C00481270
481236058378 |
Valve | Na dotaz | Zadat poptávku | |
| 921 1 WHR93269 |
C00621258
481252008033 |
LOZISKO GULICKOVE | Na dotaz | Zadat poptávku | |
| 965 0 WHR93269 |
C00394839
480150100024 |
Cover Display board | Na dotaz | Zadat poptávku | |
| 965 1 WHR93269 |
C00394884
480150100074 |
Display board | 665 Kč
€ 29.20 |
||
| 993 0 WHR93269 |
C00633194
481269028033 |
DIALKOVY OVLADAC | Na dotaz | Zadat poptávku | |
