| Komerční kód: | AMD 032 |
| Kód 12NC: | 853003201000 |
| I.C. kód: | 853003201001 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
| Další podobné modely: | 853003201000 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 0046 WHR22051 |
C00385869
480150100107 |
Support | Na dotaz | Zadat poptávku | |
| 0210 WHR22051 |
C00395541
480150100877 |
Grid air | Na dotaz | Zadat poptávku | |
| 0211 WHR22051 |
C00395542
480150100878 |
Panel front | Na dotaz | Zadat poptávku | |
| 0212 WHR22051 |
C00405012
481246448263 |
Clamp Cabinet | Na dotaz | Zadat poptávku | |
| 0330 WHR22051 |
C00385871
480150100111 |
Cover top | Na dotaz | Zadat poptávku | |
| 0332 WHR22051 |
C00395549
480150100888 |
Panel side | Na dotaz | Zadat poptávku | |
| 0333 WHR22051 |
C00395543
480150100881 |
Base | Na dotaz | Zadat poptávku | |
| 0334 WHR22051 |
C00376983
480150100114 |
Grille rear | Na dotaz | Zadat poptávku | |
| 0335 WHR22051 |
C00394917
480150100115 |
Panel Insulation | Na dotaz | Zadat poptávku | |
| 0337 WHR22051 |
C00404848
481246229432 |
Profiled seal | Na dotaz | Zadat poptávku | |
| 0338 WHR22051 |
C00395550
480150100889 |
Cover | Na dotaz | Zadat poptávku | |
| 0340 WHR22051 |
C00385868
480150100117 |
Bracket Motor | Na dotaz | Zadat poptávku | |
| 3030 WHR22051 |
C00402193
481240478948 |
Bracket | Na dotaz | Zadat poptávku | |
| 3200 WHR22051 |
C00395052
480150100298 |
Cabinet | Na dotaz | Zadat poptávku | |
| 3201 WHR22051 |
C00395053
480150100299 |
Panel front | Na dotaz | Zadat poptávku | |
| 3202 WHR22051 |
C00394921
480150100121 |
Chassis | Na dotaz | Zadat poptávku | |
| 3210 WHR22051 |
C00394922
480150100122 |
Plate protect. | Na dotaz | Zadat poptávku | |
| 3500 WHR22051 |
C00395457
480150100778 |
Display | Na dotaz | Zadat poptávku | |
| 3501 WHR22051 |
C00395054
480150100301 |
Display PCB | Na dotaz | Zadat poptávku | |
| 3502 WHR22051 |
C00395055
480150100302 |
Cover Display board | Na dotaz | Zadat poptávku | |
| 3503 WHR22051 |
C00395056
480150100303 |
Batten Display board | Na dotaz | Zadat poptávku | |
| 4020 WHR22051 |
C00395544
480150100882 |
Compressor | Na dotaz | Zadat poptávku | |
| 4120 WHR22051 |
C00399897
481214288179 |
Transformer | Na dotaz | Zadat poptávku | |
| 4200 WHR22051 |
C00394926
480150100128 |
Capacitor | Na dotaz | Zadat poptávku | |
| 4201 WHR22051 |
C00376986
480150100129 |
Capacitor | Na dotaz | Zadat poptávku | |
| 4202 WHR22051 |
C00394927
480150100131 |
Holder Capacitor | Na dotaz | Zadat poptávku | |
| 4400 WHR22051 |
C00376987
480150100132 |
motor vent. | 3 905 Kč
€ 171.60 |
||
| 4420 WHR22051 |
C00376988
480150100133 |
Motor Ventilator | Na dotaz | Zadat poptávku | |
| 4430 WHR22051 |
C00395545
480150100883 |
Fan wheel Outdoor | Na dotaz | Zadat poptávku | |
| 4431 WHR22051 |
C00376989
480150100135 |
Motorek | 495 Kč
€ 21.80 |
||
| 4434 WHR22051 |
C00377848
481251518037 |
Fan wheel Indoor | Na dotaz | Zadat poptávku | |
| 5210 WHR22051 |
C00394960
480150100178 |
Terminal Board | Na dotaz | Zadat poptávku | |
| 5211 WHR22051 |
C00394961
480150100179 |
Support Clamp | Na dotaz | Zadat poptávku | |
| 5212 WHR22051 |
C00401107
481229088134 |
Electronic box | Na dotaz | Zadat poptávku | |
| 5213 WHR22051 |
C00376995
480150100181 |
Control board | Na dotaz | Zadat poptávku | |
| 5214 WHR22051 |
C00401044
481229028029 |
Clamp | Na dotaz | Zadat poptávku | |
| 5216 WHR22051 |
C00394933
480150100142 |
Clamp | Na dotaz | Zadat poptávku | |
| 5218 WHR22051 |
C00394952
480150100169 |
Sensor Outdoor | Na dotaz | Zadat poptávku | |
| 5219 WHR22051 |
C00394935
480150100145 |
Clamp | Na dotaz | Zadat poptávku | |
| 5220 WHR22051 |
C00401110
481229088137 |
connector 3PS | Na dotaz | Zadat poptávku | |
| 5221 WHR22051 |
C00376991
480150100147 |
Power unit | Na dotaz | Zadat poptávku | |
| 5224 WHR22051 |
C00394990
480150100218 |
Clamp | Na dotaz | Zadat poptávku | |
| 5226 WHR22051 |
C00401045
481229028031 |
Clamp | Na dotaz | Zadat poptávku | |
| 5260 WHR22051 |
C00376992
480150100148 |
Electric plate | Na dotaz | Zadat poptávku | |
| 7400 WHR22051 |
C00394962
480150100182 |
Condenser | Na dotaz | Zadat poptávku | |
| 7430 WHR22051 |
C00395061
480150100311 |
Batten | Na dotaz | Zadat poptávku | |
| 7431 WHR22051 |
C00394938
480150100152 |
Deflector | Na dotaz | Zadat poptávku | |
| 7432 WHR22051 |
C00394939
480150100153 |
Drain strip | Na dotaz | Zadat poptávku | |
| 7433 WHR22051 |
C00394940
480150100154 |
Drain strip | Na dotaz | Zadat poptávku | |
| 7434 WHR22051 |
C00402219
481240488127 |
Rail Lever | Na dotaz | Zadat poptávku | |
| 7450 WHR22051 |
C00395546
480150100884 |
Evaporator | Na dotaz | Zadat poptávku | |
| 7510 WHR22051 |
C00394942
480150100156 |
Drain strip | Na dotaz | Zadat poptávku | |
| 7640 WHR22051 |
C00395551
480150100891 |
Air clean filt. | Na dotaz | Zadat poptávku | |
| 7810 WHR22051 |
C00377578
481236058637 |
Valve 2-way | Na dotaz | Zadat poptávku | |
| 7811 WHR22051 |
C00394954
480150100172 |
Coil Valve | Na dotaz | Zadat poptávku | |
| 7812 WHR22051 |
C00395547
480150100885 |
Valve 4-WAY | Na dotaz | Zadat poptávku | |
| 7815 WHR22051 |
C00395548
480150100886 |
Capillary tube | Na dotaz | Zadat poptávku | |
| 7819 WHR22051 |
C00377024
480150100887 |
Support Valve | Na dotaz | Zadat poptávku | |
| 7820 WHR22051 |
C00377580
481236058645 |
Valve 3-way | Na dotaz | Zadat poptávku | |
| 7830 WHR22051 |
C00406000
481254828066 |
Pipe assy | Na dotaz | Zadat poptávku | |
| 7831 WHR22051 |
C00377871
481253008019 |
Drainpipe | Na dotaz | Zadat poptávku | |
| 7832 WHR22051 |
C00409042
482000004978 |
Outlet stud drain condensat n.s. | Na dotaz | Zadat poptávku | |
| 7833 WHR22051 |
C00417528
482000021345 |
Gasket Outlet stud n.shown | Na dotaz | Zadat poptávku | |
| 9211 WHR22051 |
C00377868
481252048017 |
Bearing | Na dotaz | Zadat poptávku | |
| 9930 WHR22051 |
C00377008
480150100309 |
Dálkové ovládání | Na dotaz | Zadat poptávku | |
