| Komerční kód: | AMD 034 |
| Kód 12NC: | 853003401000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 004 3 WHR22000 |
C00395016
480150100249 |
Clamp A | Na dotaz | Zadat poptávku | |
| 004 5 WHR22000 |
C00395017
480150100251 |
Clamp | Na dotaz | Zadat poptávku | |
| 021 0 WHR22000 |
C00403501
481244048565 |
Grille Fan wheel | Na dotaz | Zadat poptávku | |
| 021 1 WHR22000 |
C00403502
481244048566 |
Cover front | Na dotaz | Zadat poptávku | |
| 033 0 WHR22000 |
C00395018
480150100252 |
Cover top | Na dotaz | Zadat poptávku | |
| 033 2 WHR22000 |
C00395019
480150100253 |
Panel right | Na dotaz | Zadat poptávku | |
| 033 3 WHR22000 |
C00395020
480150100254 |
Base | Na dotaz | Zadat poptávku | |
| 033 4 WHR22000 |
C00395021
480150100255 |
Grille rear | Na dotaz | Zadat poptávku | |
| 033 5 WHR22000 |
C00395022
480150100256 |
Panel Insulation | Na dotaz | Zadat poptávku | |
| 033 8 WHR22000 |
C00404847
481246229431 |
Cover plate Electronic box | Na dotaz | Zadat poptávku | |
| 034 0 WHR22000 |
C00401904
481240418646 |
Motor Support | Na dotaz | Zadat poptávku | |
| 303 0 WHR22000 |
C00395023
480150100257 |
Plate mounting | Na dotaz | Zadat poptávku | |
| 320 0 WHR22000 |
C00395024
480150100258 |
Cabinet | Na dotaz | Zadat poptávku | |
| 320 1 WHR22000 |
C00395025
480150100259 |
Panel front | Na dotaz | Zadat poptávku | |
| 320 2 WHR22000 |
C00395026
480150100261 |
Chassis | Na dotaz | Zadat poptávku | |
| 321 0 WHR22000 |
C00395062
480150100312 |
Plate protect. | Na dotaz | Zadat poptávku | |
| 350 1 WHR22000 |
C00376984
480150100123 |
Panel Display board | Na dotaz | Zadat poptávku | |
| 350 2 WHR22000 |
C00394924
480150100125 |
Cover Display board | Na dotaz | Zadat poptávku | |
| 402 0 WHR22000 |
C00395028
480150100263 |
Compressor | Na dotaz | Zadat poptávku | |
| 412 0 WHR22000 |
C00394983
480150100205 |
Transformer | Na dotaz | Zadat poptávku | |
| 420 0 WHR22000 |
C00380229
480150100264 |
Capacitor Compressor | Na dotaz | Zadat poptávku | |
| 420 1 WHR22000 |
C00395029
480150100265 |
Terminal Board | Na dotaz | Zadat poptávku | |
| 420 2 WHR22000 |
C00395030
480150100266 |
Bracket Motor | Na dotaz | Zadat poptávku | |
| 420 3 WHR22000 |
C00377001
480150100267 |
Terminal Board 2U | Na dotaz | Zadat poptávku | |
| 420 4 WHR22000 |
C00377002
480150100268 |
Terminal Board 5P3 | Na dotaz | Zadat poptávku | |
| 420 5 WHR22000 |
C00394927
480150100131 |
Holder Capacitor | Na dotaz | Zadat poptávku | |
| 440 0 WHR22000 |
C00377590
481236138149 |
Motor venkovního ventilátoru | 5 340 Kč
€ 234.70 |
||
| 440 1 WHR22000 |
C00395031
480150100269 |
Motor Ventilator | Na dotaz | Zadat poptávku | |
| 443 0 WHR22000 |
C00405537
481251518036 |
vrtule | 2 238 Kč
€ 98.40 |
||
| 443 1 WHR22000 |
C00401730
481236138152 |
Motor | Na dotaz | Zadat poptávku | |
| 443 4 WHR22000 |
C00377003
480150100271 |
Fan wheel Indoor | Na dotaz | Zadat poptávku | |
| 491 1 WHR22000 |
C00395032
480150100272 |
Capacitor Motor Ventilator | Na dotaz | Zadat poptávku | |
| 491 2 WHR22000 |
C00377004
480150100273 |
Terminal Board AC | Na dotaz | Zadat poptávku | |
| 521 1 WHR22000 |
C00377005
480150100274 |
Control board | Na dotaz | Zadat poptávku | |
| 521 2 WHR22000 |
C00395033
480150100275 |
Electronic box | Na dotaz | Zadat poptávku | |
| 521 3 WHR22000 |
C00395034
480150100276 |
Power unit | Na dotaz | Zadat poptávku | |
| 521 4 WHR22000 |
C00394933
480150100142 |
Clamp | Na dotaz | Zadat poptávku | |
| 521 5 WHR22000 |
C00401044
481229028029 |
Clamp | Na dotaz | Zadat poptávku | |
| 521 6 WHR22000 |
C00394989
480150100217 |
Clamp | Na dotaz | Zadat poptávku | |
| 521 7 WHR22000 |
C00399959
481221058094 |
senzor tepolty | 245 Kč
€ 10.80 |
||
| 521 8 WHR22000 |
C00395035
480150100277 |
Sensor Outdoor | Na dotaz | Zadat poptávku | |
| 522 0 WHR22000 |
C00395036
480150100278 |
Support Clamp | Na dotaz | Zadat poptávku | |
| 526 0 WHR22000 |
C00377006
480150100279 |
Electric plate | Na dotaz | Zadat poptávku | |
| 526 5 WHR22000 |
C00395037
480150100281 |
Cover Electronic box | Na dotaz | Zadat poptávku | |
| 701 1 WHR22000 |
C00395008
480150100241 |
Cap | Na dotaz | Zadat poptávku | |
| 701 2 WHR22000 |
C00395007
480150100239 |
Cap | Na dotaz | Zadat poptávku | |
| 740 0 WHR22000 |
C00395038
480150100282 |
Condenser | Na dotaz | Zadat poptávku | |
| 741 0 WHR22000 |
C00395039
480150100283 |
Batten | Na dotaz | Zadat poptávku | |
| 741 1 WHR22000 |
C00395040
480150100284 |
Batten | Na dotaz | Zadat poptávku | |
| 741 2 WHR22000 |
C00385844
481252048018 |
Axis sheath | Na dotaz | Zadat poptávku | |
| 741 3 WHR22000 |
C00395041
480150100285 |
Deflector | Na dotaz | Zadat poptávku | |
| 741 4 WHR22000 |
C00395042
480150100286 |
Deflector | Na dotaz | Zadat poptávku | |
| 741 5 WHR22000 |
C00395043
480150100287 |
Batten | Na dotaz | Zadat poptávku | |
| 745 0 WHR22000 |
C00395044
480150100288 |
Evaporator | Na dotaz | Zadat poptávku | |
| 751 0 WHR22000 |
C00395045
480150100289 |
Drain strip | Na dotaz | Zadat poptávku | |
| 751 1 WHR22000 |
C00395046
480150100291 |
Grille Drain strip | Na dotaz | Zadat poptávku | |
| 764 0 WHR22000 |
C00386709
480150100292 |
Air clean filt. | Na dotaz | Zadat poptávku | |
| 781 0 WHR22000 |
C00395047
480150100293 |
Pipe | Na dotaz | Zadat poptávku | |
| 781 1 WHR22000 |
C00395048
480150100294 |
Valve 3-way | Na dotaz | Zadat poptávku | |
| 781 2 WHR22000 |
C00395049
480150100295 |
Valve 2-way | Na dotaz | Zadat poptávku | |
| 781 5 WHR22000 |
C00395050
480150100296 |
Capillary tube | Na dotaz | Zadat poptávku | |
| 782 0 WHR22000 |
C00377871
481253008019 |
Drainpipe | Na dotaz | Zadat poptávku | |
| 782 1 WHR22000 |
C00395051
480150100297 |
Valve 4-way | Na dotaz | Zadat poptávku | |
| 921 1 WHR22000 |
C00386059
480150100234 |
Ložisko | Na dotaz | Zadat poptávku | |
| 962 0 WHR22000 |
C00395055
480150100302 |
Cover Display board | Na dotaz | Zadat poptávku | |
| 965 1 WHR22000 |
C00395054
480150100301 |
Display PCB | Na dotaz | Zadat poptávku | |
| 993 0 WHR22000 |
C00377008
480150100309 |
Dálkové ovládání | Na dotaz | Zadat poptávku | |
