WHIRLPOOL AMD 097/AL PORTABLE AIR COND. WP
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AMD 097/AL PORTABLE AIR COND. WP |
| Kód 12NC/I.C. kód: | 853009701050 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 01 WHR46772 |
C00403112
481244008048 |
Grid air outlet | Na dotaz | Zadat poptávku | |
| 02 WHR46772 |
C00403202
481244011666 |
Holder air outlet | Na dotaz | Zadat poptávku | |
| 03 WHR46772 |
C00401883
481240418591 |
Cover electrical box | Na dotaz | Zadat poptávku | |
| 04 WHR46772 |
C00400626
481221818041 |
Control board assembly PCB | Na dotaz | Zadat poptávku | |
| 05 WHR46772 |
C00621174
481212158143 |
KONDENZATOR | Na dotaz | Zadat poptávku | |
| 06 WHR46772 |
C00500739
481214838009 |
Transformer fan | Na dotaz | Zadat poptávku | |
| 07 WHR46772 |
C00401694
481236118613 |
Motor upper | Na dotaz | Zadat poptávku | |
| 08 WHR46772 |
C00401695
481236118614 |
Motor upper fixing board | Na dotaz | Zadat poptávku | |
| 09 WHR46772 |
C00403605
481244138026 |
Air guide | Na dotaz | Zadat poptávku | |
| 10 WHR46772 |
C00583199
481236118475 |
Ventilator | Na dotaz | Zadat poptávku | |
| 11 WHR46772 |
C00403606
481244138027 |
Air guide holder | Na dotaz | Zadat poptávku | |
| 12 WHR46772 |
C00400802
481225928946 |
Heating element | Na dotaz | Zadat poptávku | |
| 13 WHR46772 |
C00405471
481251138372 |
Evaporator holder | Na dotaz | Zadat poptávku | |
| 14 WHR46772 |
C00405470
481251138371 |
Evaporator assembly | Na dotaz | Zadat poptávku | |
| 15 WHR46772 |
C00402060
481240449815 |
Support evaporator left | Na dotaz | Zadat poptávku | |
| 16 WHR46772 |
C00402061
481240449816 |
Support evaporator right | Na dotaz | Zadat poptávku | |
| 17 WHR46772 |
C00402161
481240478881 |
redukce hadice | Na dotaz | Zadat poptávku | |
| 18 WHR46772 |
C00377607
481240478882 |
hadice klimat. | Na dotaz | Zadat poptávku | |
| 19 WHR46772 |
C00402162
481240478883 |
ventilátor adaptér | Na dotaz | Zadat poptávku | |
| 20 WHR46772 |
C00402163
481240478884 |
Ventilator grill | Na dotaz | Zadat poptávku | |
| 21 WHR46772 |
C00410136
482000007034 |
Nut | Na dotaz | Zadat poptávku | |
| 22 WHR46772 |
C00402164
481240478885 |
Ventilator deflector | Na dotaz | Zadat poptávku | |
| 23 WHR46772 |
C00402165
481240478886 |
Gasket | Na dotaz | Zadat poptávku | |
| 24 WHR46772 |
C00410137
482000007035 |
Bolt | Na dotaz | Zadat poptávku | |
| 25 WHR46772 |
C00402166
481240478887 |
Ventilator pipe frame | Na dotaz | Zadat poptávku | |
| 26 WHR46772 |
C00402167
481240478888 |
Ventilator pipe frame | Na dotaz | Zadat poptávku | |
| 27 WHR46772 |
C00402168
481240478889 |
Ventilator pipe frame | Na dotaz | Zadat poptávku | |
| 28 WHR46772 |
C00583411
481248058342 |
Air clean filt.. | Na dotaz | Zadat poptávku | |
| 29 WHR46772 |
C00402169
481240478891 |
kryt | Na dotaz | Zadat poptávku | |
| 30 WHR46772 |
C00402170
481240478892 |
kryt | Na dotaz | Zadat poptávku | |
| 31 WHR46772 |
C00402171
481240478893 |
Clamp ventilator | Na dotaz | Zadat poptávku | |
| 32 WHR46772 |
C00403203
481244011667 |
Housing rear | Na dotaz | Zadat poptávku | |
| 33 WHR46772 |
C00402172
481240478894 |
Cover air channel | Na dotaz | Zadat poptávku | |
| 34 WHR46772 |
C00403610
481244148015 |
Air guide | Na dotaz | Zadat poptávku | |
| 35 WHR46772 |
C00401767
481236158493 |
Motor lower | Na dotaz | Zadat poptávku | |
| 36 WHR46772 |
C00401696
481236118615 |
Fan | Na dotaz | Zadat poptávku | |
| 37 WHR46772 |
C00403611
481244148016 |
Air guide front panel | Na dotaz | Zadat poptávku | |
| 38 WHR46772 |
C00403612
481244148017 |
kondenzator | Na dotaz | Zadat poptávku | |
| 39 WHR46772 |
C00403613
481244148018 |
Condenser frame | Na dotaz | Zadat poptávku | |
| 40 WHR46772 |
C00402173
481240478895 |
Pipe | Na dotaz | Zadat poptávku | |
| 41 WHR46772 |
C00402174
481240478896 |
Pipe discharge | Na dotaz | Zadat poptávku | |
| 42 WHR46772 |
C00583580
481228048626 |
Capacitor fan motor | Na dotaz | Zadat poptávku | |
| 43 WHR46772 |
C00402062
481240449817 |
Support traverse | Na dotaz | Zadat poptávku | |
| 44 WHR46772 |
C00399761
481212158169 |
Capacitor fan | Na dotaz | Zadat poptávku | |
| 45 WHR46772 |
C00620382
481236138114 |
Motor | Na dotaz | Zadat poptávku | |
| 46 WHR46772 |
C00400714
481221848163 |
Control panel | Na dotaz | Zadat poptávku | |
| 47 WHR46772 |
C00400715
481221848164 |
Control panel | Na dotaz | Zadat poptávku | |
| 48 WHR46772 |
C00400716
481221848165 |
Display board | Na dotaz | Zadat poptávku | |
| 49 WHR46772 |
C00377878
481269028047 |
ovladec dalkovy | Na dotaz | Zadat poptávku | |
| 50 WHR46772 |
C00403204
481244011668 |
Housing front | Na dotaz | Zadat poptávku | |
| 51 WHR46772 |
C00402175
481240478897 |
Clamp left | Na dotaz | Zadat poptávku | |
| 52 WHR46772 |
C00402176
481240478898 |
Clamp right | Na dotaz | Zadat poptávku | |
| 53 WHR46772 |
C00495077
481240448974 |
Support front | Na dotaz | Zadat poptávku | |
| 54 WHR46772 |
C00583458
481252888116 |
Roller / feet. | Na dotaz | Zadat poptávku | |
| 55 WHR46772 |
C00405138
481246688982 |
Gasket | Na dotaz | Zadat poptávku | |
| 56 WHR46772 |
C00405139
481246688983 |
Spring gasket | Na dotaz | Zadat poptávku | |
| 57 WHR46772 |
C00405140
481246688984 |
Compressor bolt | Na dotaz | Zadat poptávku | |
| 58 WHR46772 |
C00404973
481246418241 |
Frame base | Na dotaz | Zadat poptávku | |
| 59 WHR46772 |
C00402177
481240478899 |
Clamp | Na dotaz | Zadat poptávku | |
| 60 WHR46772 |
C00401596
481236068896 |
Pipe water discharge | Na dotaz | Zadat poptávku | |
| 61 WHR46772 |
C00401597
481236068897 |
Rubber blanket water outlet | Na dotaz | Zadat poptávku | |
| 62 WHR46772 |
C00405141
481246688985 |
Gasket nut | Na dotaz | Zadat poptávku | |
| 63 WHR46772 |
C00400889
481227158195 |
Switch holder | Na dotaz | Zadat poptávku | |
| 64 WHR46772 |
C00400890
481227158196 |
Switch start-up | Na dotaz | Zadat poptávku | |
| 65 WHR46772 |
C00400891
481227158197 |
Switch alarm | Na dotaz | Zadat poptávku | |
| 66 WHR46772 |
C00401368
481236018583 |
Compressor assembly | Na dotaz | Zadat poptávku | |
| 67 WHR46772 |
C00401369
481236018584 |
Protector | Na dotaz | Zadat poptávku | |
| 68 WHR46772 |
C00404061
481245310389 |
Panel waterworks assembly | Na dotaz | Zadat poptávku | |
| 69 WHR46772 |
C00401598
481236068898 |
Pipe suction | Na dotaz | Zadat poptávku | |
| 70 WHR46772 |
C00401370
481236018585 |
Capillary tube | Na dotaz | Zadat poptávku | |
| 71 WHR46772 |
C00401002
481228210314 |
Sensor | Na dotaz | Zadat poptávku | |
| 72 WHR46772 |
C00401371
481236018586 |
Motor induction | Na dotaz | Zadat poptávku | |
| 73 WHR46772 |
C00401372
481236018587 |
support water pump | Na dotaz | Zadat poptávku | |
| 74 WHR46772 |
C00401373
481236018588 |
Flywheel water pump assembly | Na dotaz | Zadat poptávku | |
| 75 WHR46772 |
C00401693
481236118612 |
Nut | Na dotaz | Zadat poptávku | |
| 76 WHR46772 |
C00401692
481236118611 |
Cover flywheel | Na dotaz | Zadat poptávku | |
| 999 WHR46772 |
C00638660 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
