| Komerční kód: | ARG 774 wh REFRIGERATORS WP |
| Kód 12NC/I.C. kód: | 853477401000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Volně stojící lednice s mrazákem |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 0110 WHR51390 |
C00330451
481246218246 |
Foot | Na dotaz | Zadat poptávku | |
| 0112 WHR51390 |
C00336238
481246218185 |
Small plate | Na dotaz | Zadat poptávku | |
| 0120 WHR51390 |
C00336795
481252878048 |
Roller | Na dotaz | Zadat poptávku | |
| 0240 WHR51390 |
C00344521
481246418082 |
Base | Na dotaz | Zadat poptávku | |
| 0400 WHR51390 |
C00583842
481241778019 |
Hinge upper. | Na dotaz | Zadat poptávku | |
| 0401 WHR51390 |
C00336360
481241778021 |
Shim hinge | Na dotaz | Zadat poptávku | |
| 0402 WHR51390 |
C00492120
481253538084 |
Shim | Na dotaz | Zadat poptávku | |
| 0403 WHR51390 |
C00339789
481241719092 |
Hinge middle | Na dotaz | Zadat poptávku | |
| 0404 WHR51390 |
C00342472
481246228054 |
Cover hinge | Na dotaz | Zadat poptávku | |
| 0405 WHR51390 |
C00339800
481241718854 |
Hinge lower | Na dotaz | Zadat poptávku | |
| 0406 WHR51390 |
C00583931
481246228276 |
Shim. | Na dotaz | Zadat poptávku | |
| 0407 WHR51390 |
C00339846
481241719094 |
Hinge | Na dotaz | Zadat poptávku | |
| 0409 WHR51390 |
C00339737
481241719093 |
Hinge,middleleft version | Na dotaz | Zadat poptávku | |
| 0473 WHR51390 |
C00336455
481253548009 |
Shaft | Na dotaz | Zadat poptávku | |
| 0700 WHR51390 |
C00574926
481246228416 |
Plinth /WH. | Na dotaz | Zadat poptávku | |
| 1010 WHR51390 |
C00584468
481241618556 |
Door freezer. | Na dotaz | Zadat poptávku | |
| 1020 WHR51390 |
C00584599
481244229165 |
Flap evap.door. | Na dotaz | Zadat poptávku | |
| 1021 WHR51390 |
C00490087
481246218247 |
Flap | Na dotaz | Zadat poptávku | |
| 1040 WHR51390 |
C00484845
481241619167 |
Door refriger. | Na dotaz | Zadat poptávku | |
| 1050 WHR51390 |
C00344080
481253288011 |
Bushing | Na dotaz | Zadat poptávku | |
| 1051 WHR51390 |
C00336004
481253288012 |
zaslepka | Na dotaz | Zadat poptávku | |
| 1052 WHR51390 |
C00344061
481246228181 |
Bushing white | Na dotaz | Zadat poptávku | |
| 1053 WHR51390 |
C00498375
481246228179 |
Bushing right,white. | Na dotaz | Zadat poptávku | |
| 1110 WHR51390 |
C00621465
481249818228 |
Handle. | Na dotaz | Zadat poptávku | |
| 1111 WHR51390 |
C00621464
481249818225 |
Insert handle/right. | Na dotaz | Zadat poptávku | |
| 1112 WHR51390 |
C00490178
481249818226 |
Insert handle/left | Na dotaz | Zadat poptávku | |
| 1113 WHR51390 |
C00342486
481246818234 |
Cover handle | Na dotaz | Zadat poptávku | |
| 1117 WHR51390 |
C00584667
481245918217 |
Nameplate. | Na dotaz | Zadat poptávku | |
| 1530 WHR51390 |
C00495593
481241879762 |
rack freezer | Na dotaz | Zadat poptávku | |
| 1531 WHR51390 |
C00339318
481246228534 |
police | Na dotaz | Zadat poptávku | |
| 1536 WHR51390 |
C00490096
481246228404 |
Separator | Na dotaz | Zadat poptávku | |
| 1540 WHR51390 |
C00491687
481241848491 |
Holder bottles | Na dotaz | Zadat poptávku | |
| 1542 WHR51390 |
C00584768
481246428029 |
Shelf. | Na dotaz | Zadat poptávku | |
| 1543 WHR51390 |
C00584739
481246228417 |
Shelf. | Na dotaz | Zadat poptávku | |
| 1551 WHR51390 |
C00584684
481246088256 |
Door dairy egg carrier. | Na dotaz | Zadat poptávku | |
| 1560 WHR51390 |
C00489022
481241828343 |
miska na led | Na dotaz | Zadat poptávku | |
| 1562 WHR51390 |
C00584737
481246228414 |
Separator. | Na dotaz | Zadat poptávku | |
| 1563 WHR51390 |
C00500821
481241828033 |
zasobnik na led | Na dotaz | Zadat poptávku | |
| 1564 WHR51390 |
C00495592
481241728082 |
viko zasobniku na led | Na dotaz | Zadat poptávku | |
| 1565 WHR51390 |
C00584738
481246228415 |
Bottle shelf. | Na dotaz | Zadat poptávku | |
| 1910 WHR51390 |
C00584795
481246818233 |
Magnetic seal refr. refr.. | Na dotaz | Zadat poptávku | |
| 1911 WHR51390 |
C00529782
481246818232 |
Magnetic seal freezing | Na dotaz | Zadat poptávku | |
| 2030 WHR51390 |
C00338714
481232518003 |
Insulation ,rear | Na dotaz | Zadat poptávku | |
| 2031 WHR51390 |
C00527316
481232518004 |
Insulation front | Na dotaz | Zadat poptávku | |
| 2420 WHR51390 |
C00342288
481241879647 |
zasuvka na zeleninu | Na dotaz | Zadat poptávku | |
| 2423 WHR51390 |
C00336788
481240448673 |
Roller vegetables drawer | Na dotaz | Zadat poptávku | |
| 2441 WHR51390 |
C00584740
481246228418 |
shelf. | Na dotaz | Zadat poptávku | |
| 2442 WHR51390 |
C00485992
481246228419 |
Glass shelf | Na dotaz | Zadat poptávku | |
| 2443 WHR51390 |
C00584600
481244229166 |
Cover crisper. | Na dotaz | Zadat poptávku | |
| 2460 WHR51390 |
C00335356
481241828029 |
Tray ,freezer | Na dotaz | Zadat poptávku | |
| 2461 WHR51390 |
C00574560
481246429166 |
Shelf freezing. | Na dotaz | Zadat poptávku | |
| 2610 WHR51390 |
C00336930
481246818014 |
Rail right | Na dotaz | Zadat poptávku | |
| 2611 WHR51390 |
C00336932
481246218183 |
Rail left | Na dotaz | Zadat poptávku | |
| 2630 WHR51390 |
C00336264
481246218184 |
Slide | Na dotaz | Zadat poptávku | |
| 2631 WHR51390 |
C00335790
481240448671 |
drzak | Na dotaz | Zadat poptávku | |
| 3010 WHR51390 |
C00489776
481245310066 |
Reflector | Na dotaz | Zadat poptávku | |
| 3014 WHR51390 |
C00343722
481246428028 |
Control panel | Na dotaz | Zadat poptávku | |
| 3560 WHR51390 |
C00487161
481241218028 |
Knob ,damper | Na dotaz | Zadat poptávku | |
| 4020 WHR51390 |
C00576145
481236138058 |
Compressor FGS 100 HA 220-240V/50Hz | Na dotaz | Zadat poptávku | |
| 4021 WHR51390 |
C00335359
481241879646 |
Tray | Na dotaz | Zadat poptávku | |
| 4023 WHR51390 |
C00331559
481246699005 |
Base compressor | Na dotaz | Zadat poptávku | |
| 4024 WHR51390 |
C00574987
481253538085 |
Clip. | Na dotaz | Zadat poptávku | |
| 4400 WHR51390 |
C00574714
481236138051 |
MOTOR VENTILATORA 220V/60HZ | Na dotaz | Zadat poptávku | |
| 4401 WHR51390 |
C00315086
481246638021 |
Damper fan | Na dotaz | Zadat poptávku | |
| 4430 WHR51390 |
C00315305
481236118282 |
Fan | Na dotaz | Zadat poptávku | |
| 4431 WHR51390 |
C00335783
481246048881 |
Support Ventilator | Na dotaz | Zadat poptávku | |
| 4510 WHR51390 |
C00320266
481225948141 |
ELEMENT DEFROST | Na dotaz | Zadat poptávku | |
| 4800 WHR51390 |
C00343501
481201978807 |
Connect.cable | Na dotaz | Zadat poptávku | |
| 4910 WHR51390 |
C00498415
481246279703 |
Cover Relay. | Na dotaz | Zadat poptávku | |
| 5000 WHR51390 |
C00311580
481221838159 |
modul chl. | Na dotaz | Zadat poptávku | |
| 5001 WHR51390 |
C00342539
481244028945 |
Cover Control board | Na dotaz | Zadat poptávku | |
| 5660 WHR51390 |
C00319312
481228238041 |
Thermostat | Na dotaz | Zadat poptávku | |
| 5661 WHR51390 |
C00339546
481246048885 |
Holder Thermostat | Na dotaz | Zadat poptávku | |
| 5662 WHR51390 |
C00314686
481228238042 |
termostat | Na dotaz | Zadat poptávku | |
| 6140 WHR51390 |
C00495590
481228028012 |
Relay + overload | Na dotaz | Zadat poptávku | |
| 6510 WHR51390 |
C00341807
481213428061 |
Lamp220V | Na dotaz | Zadat poptávku | |
| 6520 WHR51390 |
C00339579
481225528011 |
Holder lamp | Na dotaz | Zadat poptávku | |
| 6521 WHR51390 |
C00342197
481246228056 |
Deflector | Na dotaz | Zadat poptávku | |
| 6523 WHR51390 |
C00342514
481246098006 |
Cover f. lamp | Na dotaz | Zadat poptávku | |
| 6527 WHR51390 |
C00342198
481246228057 |
Deflector | Na dotaz | Zadat poptávku | |
| 6550 WHR51390 |
C00557948
481227138442 |
Interface board | Na dotaz | Zadat poptávku | |
| 6910 WHR51390 |
C00336525
481228268021 |
Sensor kit | Na dotaz | Zadat poptávku | |
| 7400 WHR51390 |
C00583969
481251148216 |
Condenser. | Na dotaz | Zadat poptávku | |
| 7401 WHR51390 |
C00330489
481246228394 |
Holder Condenser | Na dotaz | Zadat poptávku | |
| 7402 WHR51390 |
C00343291
481240418112 |
Clip Condenserr | Na dotaz | Zadat poptávku | |
| 7430 WHR51390 |
C00498501
481248028035 |
difuzor | Na dotaz | Zadat poptávku | |
| 7431 WHR51390 |
C00335877
481246048884 |
Support | Na dotaz | Zadat poptávku | |
| 7434 WHR51390 |
C00584373
481215818003 |
Cover air diffuser. | Na dotaz | Zadat poptávku | |
| 7450 WHR51390 |
C00341099
481251138149 |
Evaporator | Na dotaz | Zadat poptávku | |
| 7451 WHR51390 |
C00339197
481244228963 |
Housing Evaporator | Na dotaz | Zadat poptávku | |
| 7452 WHR51390 |
C00583803
481232588007 |
Insulation. | Na dotaz | Zadat poptávku | |
| 7453 WHR51390 |
C00583801
481232518005 |
Cover rubber. | Na dotaz | Zadat poptávku | |
| 7454 WHR51390 |
C00335834
481253598061 |
Support Evaporator | Na dotaz | Zadat poptávku | |
| 7601 WHR51390 |
C00319191
481246048883 |
Support Air clean filt. | Na dotaz | Zadat poptávku | |
| 7602 WHR51390 |
C00344625
481249038001 |
Air clean filt. | Na dotaz | Zadat poptávku | |
| 7640 WHR51390 |
C00345711
481248028051 |
Dryer | Na dotaz | Zadat poptávku | |
| 7651 WHR51390 |
C00342327
481244069029 |
Cover,front | Na dotaz | Zadat poptávku | |
| 7652 WHR51390 |
C00584577
481244069199 |
Separator evap./back | Na dotaz | Zadat poptávku | |
| 7653 WHR51390 |
C00343377
481246048882 |
Clamp Cover | Na dotaz | Zadat poptávku | |
| 7654 WHR51390 |
C00342450
481225528004 |
Cover lamp | Na dotaz | Zadat poptávku | |
| 7810 WHR51390 |
C00337398
481217088005 |
Tube | Na dotaz | Zadat poptávku | |
| 9000 WHR51390 |
C00332711
481253538083 |
Pin | Na dotaz | Zadat poptávku | |
| 9002 WHR51390 |
C00343300
481253578042 |
Clip | Na dotaz | Zadat poptávku | |
| 9100 WHR51390 |
C00336665
481256018026 |
Screw | Na dotaz | Zadat poptávku | |
| 9101 WHR51390 |
C00584835
481252388005 |
Screw. | Na dotaz | Zadat poptávku | |
| 9103 WHR51390 |
C00336570
481256018025 |
Screw M5x10mm | Na dotaz | Zadat poptávku | |
| 9105 WHR51390 |
C00492140
481256018024 |
Screw | Na dotaz | Zadat poptávku | |
| 9107 WHR51390 |
C00336667
481256018022 |
Screw | Na dotaz | Zadat poptávku | |
| 9108 WHR51390 |
C00336668
481256018023 |
Screw | Na dotaz | Zadat poptávku | |
| 9650 WHR51390 |
C00342336
481244229065 |
Cover white | Na dotaz | Zadat poptávku | |
| 9653 WHR51390 |
C00330243
481246048886 |
Cover | Na dotaz | Zadat poptávku | |
| 999 WHR51390 |
C00648660 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
