IGNIS ARL 979/A+
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | ARL 979/A+ |
| Kód 12NC: | 853997901000 |
| Značka: | IGNIS |
| Typ produktu: | Vestavné lednice |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 00 WHR116678 |
C00387088
482000093233 |
Led light | Na dotaz | Zadat poptávku | |
| 00 WHR116678 |
C00495531
482000093230 |
Knoflík termostatu | 236 Kč
€ 10.40 |
||
| 00 WHR116678 |
C00495532
482000093231 |
Kryt termostatu | 1 259 Kč
€ 55.30 |
||
| 00 WHR116678 |
C00495533
482000093232 |
Cover LED, from wk 46/2015 | Na dotaz | Zadat poptávku | |
| 009 WHR116678 |
C00511415
488000511415 |
DOOR GASKET | Na dotaz | Zadat poptávku | |
| 02 WHR116678 |
C00335042
482000016149 |
Trim upper part | Na dotaz | Zadat poptávku | |
| 03 WHR116678 |
C00334994
482000014867 |
Hinge upper | Na dotaz | Zadat poptávku | |
| 07 WHR116678 |
C00327774
481241829978 |
zásobník | 287 Kč
€ 12.60 |
||
| 08 WHR116678 |
C00334995
482000014868 |
Door | Na dotaz | Zadat poptávku | |
| 10 WHR116678 |
C00414453
482000015146 |
Police na lahve do dveří | 1 023 Kč
€ 45.00 |
||
| 11 WHR116678 |
C00319534
481245088552 |
Crisper cover | Na dotaz | Zadat poptávku | |
| 12 WHR116678 |
C00334998
482000014871 |
Shelf | Na dotaz | Zadat poptávku | |
| 13 WHR116678 |
C00414454
482000015147 |
Rack upper, grey | Na dotaz | Zadat poptávku | |
| 14 WHR116678 |
C00313908
481221538027 |
Knoflík termostatu | 233 Kč
€ 10.20 |
||
| 15 WHR116678 |
C00313459
481221538028 |
kryt termostatu | 838 Kč
€ 36.80 |
||
| 16 WHR116678 |
C00311118
481221538029 |
Termostat | Na dotaz | Zadat poptávku | |
| 17 WHR116678 |
C00312214
481225518309 |
objimka zarovky | 291 Kč
€ 12.80 |
||
| 18 WHR116678 |
C00314457
480131100738 |
pant | Na dotaz | Zadat poptávku | |
| 19 WHR116678 |
C00312052
481241610566 |
Dveře výparníku | Na dotaz | Zadat poptávku | |
| 19A WHR116678 |
C00300875
482000015071 |
Cover hinge | Na dotaz | Zadat poptávku | |
| 19B WHR116678 |
C00296761
482000021310 |
Gasket Door evaporator | Na dotaz | Zadat poptávku | |
| 20 WHR116678 |
C00323069
480131100742 |
Lock plate Door inner | Na dotaz | Zadat poptávku | |
| 21 WHR116678 |
C00323067
480131100739 |
Rukojeť dveří výparníku | Na dotaz | Zadat poptávku | |
| 22 WHR116678 |
C00323068
480131100741 |
Spring Door inner | Na dotaz | Zadat poptávku | |
| 23 WHR116678 |
C00311925
481213418098 |
Žárovka malá baňka 240V 15W E14 | 251 Kč
€ 11.00 |
||
| 24 WHR116678 |
C00314402
481246229364 |
kryt zarovky | 348 Kč
€ 15.30 |
||
| 25 WHR116678 |
C00335002
482000014875 |
Hinge lower assy | Na dotaz | Zadat poptávku | |
| 26 WHR116678 |
C00312828
481221838665 |
spinac | Na dotaz | Zadat poptávku | |
| 27 WHR116678 |
C00329781
481241719523 |
zaslepka | 507 Kč
€ 22.30 |
||
| 28 WHR116678 |
C00334172
482000011330 |
Cap for hole | Na dotaz | Zadat poptávku | |
| 29 WHR116678 |
C00329861
481241818689 |
Support compressor | Na dotaz | Zadat poptávku | |
| 30 WHR116678 |
C00327874
481241868426 |
zásuvka na zeleninu | 1 092 Kč
€ 48.00 |
||
| 31 WHR116678 |
C00333829
482000008861 |
Cable mains | Na dotaz | Zadat poptávku | |
| 32 WHR116678 |
C00335003
482000014876 |
Decorplate lower | Na dotaz | Zadat poptávku | |
| 33 WHR116678 |
C00323169
480132100021 |
Cable | Na dotaz | Zadat poptávku | |
| 35 WHR116678 |
C00335004
482000014878 |
Compressor | Na dotaz | Zadat poptávku | |
| 36 WHR116678 |
C00333835
482000008909 |
Tube | Na dotaz | Zadat poptávku | |
| 37 WHR116678 |
C00333836
482000008910 |
Cover mainslead | Na dotaz | Zadat poptávku | |
| 38 WHR116678 |
C00333837
482000008911 |
Cover mainslead | Na dotaz | Zadat poptávku | |
| 39 WHR116678 |
C00332357
481252648261 |
Tube short | Na dotaz | Zadat poptávku | |
| 40 WHR116678 |
C00319175
480131100175 |
tray Compressor | Na dotaz | Zadat poptávku | |
| 41 WHR116678 |
C00314654
481248028126 |
Filter drier R600a | Na dotaz | Zadat poptávku | |
| 42 WHR116678 |
C00414455
482000015148 |
Rack middle, grey | Na dotaz | Zadat poptávku | |
| 43 WHR116678 |
C00332267
481251148473 |
kondenzátor | 1 785 Kč
€ 78.50 |
||
| 47 WHR116678 |
C00323743
480132103067 |
Cover Slide block | Na dotaz | Zadat poptávku | |
| 48 WHR116678 |
C00323741
480132103065 |
Slide block | Na dotaz | Zadat poptávku | |
| 49 WHR116678 |
C00323742
480132103066 |
cover Slide bearing | Na dotaz | Zadat poptávku | |
| 50 WHR116678 |
C00323740
480132103064 |
Slide bearing | Na dotaz | Zadat poptávku | |
| 99 WHR116678 |
C00335045
482000016159 |
Mounting kit 9M rail system | Na dotaz | Zadat poptávku | |
| 999 WHR116678 |
C00563176 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
| 9999 WHR116678 |
C00404823
481246229367 |
Cover top | Na dotaz | Zadat poptávku | |
