IGNIS AWF026 TUMBLE DRYER IG
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | AWF026 TUMBLE DRYER IG |
| Kód 12NC/I.C. kód: | 851902645000 |
| Značka: | IGNIS |
| Typ produktu: | Sušičky |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 101 WHR93188 |
C00313955
481936158089 |
motor susicky | Na dotaz | Zadat poptávku | |
| 112 WHR93188 |
C00313246
481912118279 |
Capacitor 8çF - 450V - 6çm dielectric | Na dotaz | Zadat poptávku | |
| 125 WHR93188 |
C00311098
481935818131 |
V-ribbed belt | Na dotaz | Zadat poptávku | |
| 141 WHR93188 |
C00311735
481232118094 |
Cable mains | Na dotaz | Zadat poptávku | |
| 142 WHR93188 |
C00314578
481229068217 |
Terminal Block | Na dotaz | Zadat poptávku | |
| 196 WHR93188 |
C00343890
481944019603 |
SKRIŇA | Na dotaz | Zadat poptávku | |
| 199 WHR93188 |
C00582324
481944019679 |
Plinth w.grid. | Na dotaz | Zadat poptávku | |
| 201 WHR93188 |
C00581636
481946669976 |
TESNENIE DVIEROK N | Na dotaz | Zadat poptávku | |
| 203 WHR93188 |
C00311644
481244019905 |
.oor cpl. | Na dotaz | Zadat poptávku | |
| 203 A WHR93188 |
C00581561
481244019906 |
FRAME,DOOR GLAS (CPL). | Na dotaz | Zadat poptávku | |
| 211 WHR93188 |
C00491209
481228218681 |
Timer CS 1079 D | Na dotaz | Zadat poptávku | |
| 227 WHR93188 |
C00316410
481225928753 |
HEATING ELEMENT | Na dotaz | Zadat poptávku | |
| 228 WHR93188 |
C00313187
481928248221 |
SNIMAC PRETAZENIA | 779 Kč
€ 32.00 |
||
| 229 WHR93188 |
C00313066
481228248241 |
Thermostat exhaust | Na dotaz | Zadat poptávku | |
| 230 WHR93188 |
C00574328
481228248251 |
Thermostat inlet. | Na dotaz | Zadat poptávku | |
| 235 WHR93188 |
C00314622
481231038507 |
Switch | Na dotaz | Zadat poptávku | |
| 248 WHR93188 |
C00311325
481231038505 |
icroswitch door | Na dotaz | Zadat poptávku | |
| 266 WHR93188 |
C00311012
481241818272 |
Drum | Na dotaz | Zadat poptávku | |
| 270 WHR93188 |
C00311275
481953578078 |
ulozeni bubnu | Na dotaz | Zadat poptávku | |
| 352 WHR93188 |
C00341868
481941249468 |
Knob timeswitch | Na dotaz | Zadat poptávku | |
| 353 WHR93188 |
C00582207
481245319964 |
Control panel. | Na dotaz | Zadat poptávku | |
| 355 WHR93188 |
C00484932
481241778051 |
Cover for hinge | Na dotaz | Zadat poptávku | |
| 356 WHR93188 |
C00336624
481950238185 |
Screw 6 x 11 | Na dotaz | Zadat poptávku | |
| 359 WHR93188 |
C00377656
481241718942 |
Hinge Door (assy) | Na dotaz | Zadat poptávku | |
| 362 WHR93188 |
C00314081
481244019907 |
Frame door glas | Na dotaz | Zadat poptávku | |
| 363 WHR93188 |
C00340322
481944019332 |
ram dveri | 788 Kč
€ 32.40 |
||
| 363 a WHR93188 |
C00574551
481246268015 |
RUKOVAT N | Na dotaz | Zadat poptávku | |
| 364 WHR93188 |
C00336446
481953518013 |
osa uzaveru dveri | Na dotaz | Zadat poptávku | |
| 365 WHR93188 |
C00336066
481949248105 |
pruzina dveri | Na dotaz | Zadat poptávku | |
| 366 WHR93188 |
C00315006
481941758128 |
Hook | Na dotaz | Zadat poptávku | |
| 367 WHR93188 |
C00314233
481940478695 |
HOLDER,ADJUST. DOOR | Na dotaz | Zadat poptávku | |
| 369 WHR93188 |
C00336096
481949268299 |
SPONA | Na dotaz | Zadat poptávku | |
| 370 WHR93188 |
C00313111
481946238702 |
Latch Guide | Na dotaz | Zadat poptávku | |
| 376 WHR93188 |
C00340653
481944019642 |
Front panel white | Na dotaz | Zadat poptávku | |
| 377 WHR93188 |
C00499039
481941028528 |
TLAČÍTKO | Na dotaz | Zadat poptávku | |
| 385 WHR93188 |
C00482929
481244019741 |
Bracket Top cover | Na dotaz | Zadat poptávku | |
| 386 WHR93188 |
C00557098
481244019938 |
TABLE TOP WHITE.. | Na dotaz | Zadat poptávku | |
| 390 WHR93188 |
C00319802
481932568005 |
Gasket Thermostat | Na dotaz | Zadat poptávku | |
| 393 WHR93188 |
C00574345
481240118475 |
BRACKET. | Na dotaz | Zadat poptávku | |
| 394 WHR93188 |
C00553725
481246279727 |
FOOT | Na dotaz | Zadat poptávku | |
| 395 WHR93188 |
C00315766
481949268317 |
Clip fix Heater | Na dotaz | Zadat poptávku | |
| 399 WHR93188 |
C00311594
481240448707 |
Support heating element | Na dotaz | Zadat poptávku | |
| 400 WHR93188 |
C00314222
481240478376 |
Plate heating element | Na dotaz | Zadat poptávku | |
| 402 WHR93188 |
C00499130
481944018854 |
ZADN? MRIEYKA N | Na dotaz | Zadat poptávku | |
| 405 WHR93188 |
C00582231
481250238157 |
Screw M5 X 16. | Na dotaz | Zadat poptávku | |
| 406 WHR93188 |
C00548215
481250218447 |
Washer selflock. | Na dotaz | Zadat poptávku | |
| 407 WHR93188 |
C00529857
481250518377 |
NUT M5 M5 | Na dotaz | Zadat poptávku | |
| 408 WHR93188 |
C00343380
481243518092 |
Clamp cable | Na dotaz | Zadat poptávku | |
| 413 WHR93188 |
C00582174
481244019744 |
PANEL, REAR | Na dotaz | Zadat poptávku | |
| 427 WHR93188 |
C00311436
482231020275 |
Clamp Motor | Na dotaz | Zadat poptávku | |
| 432 WHR93188 |
C00500788
481240118476 |
Bracket Motor | Na dotaz | Zadat poptávku | |
| 437 WHR93188 |
C00744329
481253029021 |
Hose Vent(fixed Rear) | Na dotaz | Zadat poptávku | |
| 440 WHR93188 |
C00313022
481941878978 |
Air Guide | Na dotaz | Zadat poptávku | |
| 441 WHR93188 |
C00311530
481952028022 |
Ložisko predni krat. | Na dotaz | Zadat poptávku | |
| 442 WHR93188 |
C00319777
481246668625 |
Seal Front | Na dotaz | Zadat poptávku | |
| 444 WHR93188 |
C00312492
481946698324 |
Drum lifter | Na dotaz | Zadat poptávku | |
| 445 WHR93188 |
C00313188
481952028021 |
lozisko predni dlou. | Na dotaz | Zadat poptávku | |
| 446 WHR93188 |
C00310991
481951528127 |
Ventilátor | Na dotaz | Zadat poptávku | |
| 447 WHR93188 |
C00311704
481944019619 |
PRÍKLOP | Na dotaz | Zadat poptávku | |
| 448 WHR93188 |
C00343284
481949268679 |
Clip fix | Na dotaz | Zadat poptávku | |
| 449 WHR93188 |
C00582101
481227898001 |
Spring switch. | Na dotaz | Zadat poptávku | |
| 450 WHR93188 |
C00499297
481945919256 |
DO?TIAKA TLAAIDLA N | Na dotaz | Zadat poptávku | |
| 454 WHR93188 |
C00553739
481248128152 |
FILTER | Na dotaz | Zadat poptávku | |
| 455 WHR93188 |
C00336626
481950238209 |
Screw 6 x 1/2 C.S. | Na dotaz | Zadat poptávku | |
| 456 WHR93188 |
C00311432
481246668626 |
Gasket banjo | Na dotaz | Zadat poptávku | |
| 457 WHR93188 |
C00343306
481949268296 |
SPONA "J" | Na dotaz | Zadat poptávku | |
| 458 WHR93188 |
C00313299
481240448709 |
Insert No. 2, banjo | Na dotaz | Zadat poptávku | |
| 459 WHR93188 |
C00313495
481240448711 |
Insert No. 1, banjo | Na dotaz | Zadat poptávku | |
| 518 WHR93188 |
C00491698
481243518088 |
CABLE CLAMP | Na dotaz | Zadat poptávku | |
| 519 WHR93188 |
C00557127
481250518378 |
NUT M5.. | Na dotaz | Zadat poptávku | |
| 520 WHR93188 |
C00574329
481229068216 |
Connection Earth. | Na dotaz | Zadat poptávku | |
| 537 WHR93188 |
C00343285
481946248404 |
Clip fix | Na dotaz | Zadat poptávku | |
| 554 WHR93188 |
C00582141
481240468031 |
Holder Knob. | Na dotaz | Zadat poptávku | |
| 999 WHR93188 |
C00761202 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
