| Komerční kód: | 045 381 10 |
| Kód 12NC: | 850729315000 |
| Značka: | IKEA |
| Typ produktu: | |
| Další podobné modely: | 850729315001 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 011 0 WHR107745 |
C00311579
481950018141 |
noha lednice | 75 Kč
€ 3.30 |
||
| 041 1 WHR107745 |
C00320884
481241718782 |
Hinge low.re./up.le. | Na dotaz | Zadat poptávku | |
| 041 2 WHR107745 |
C00320868
481241718781 |
HINGE LOW.LE./UP.RI. | Na dotaz | Zadat poptávku | |
| 051 0 WHR107745 |
C00333116
481946418163 |
Base | Na dotaz | Zadat poptávku | |
| 065 0 WHR107745 |
C00333279
481952918041 |
Buffer piece | Na dotaz | Zadat poptávku | |
| 071 0 WHR107745 |
C00333050
481945858331 |
Grid air | Na dotaz | Zadat poptávku | |
| 071 2 WHR107745 |
C00337694
481944228604 |
Plinth | Na dotaz | Zadat poptávku | |
| 071 3 WHR107745 |
C00333019
481944229927 |
Kryt | 397 Kč
€ 17.50 |
||
| 071 5 WHR107745 |
C00333319
481953268472 |
Spacer | Na dotaz | Zadat poptávku | |
| 084 3 WHR107745 |
C00333073
481946248211 |
gufero | 121 Kč
€ 5.30 |
||
| 101 0 WHR107745 |
C00333020
481944229989 |
Door freezer | Na dotaz | Zadat poptávku | |
| 105 0 WHR107745 |
C00344633
481953268521 |
sroubek | 39 Kč
€ 1.70 |
||
| 105 1 WHR107745 |
C00333274
481952838286 |
kolik s excentrem | 40 Kč
€ 1.80 |
||
| 105 3 WHR107745 |
C00333128
481946689044 |
Fastener | Na dotaz | Zadat poptávku | |
| 111 4 WHR107745 |
C00333061
481946049859 |
Nameplate | Na dotaz | Zadat poptávku | |
| 156 0 WHR107745 |
C00287849
481941878977 |
miska na led | 290 Kč
€ 12.70 |
||
| 170 7 WHR107745 |
C00337470
481946088703 |
Trim, side | Na dotaz | Zadat poptávku | |
| 170 8 WHR107745 |
C00337466
481946049686 |
Trim, upper | Na dotaz | Zadat poptávku | |
| 171 1 WHR107745 |
C00337476
481946088833 |
TRIM, GRID | Na dotaz | Zadat poptávku | |
| 191 1 WHR107745 |
C00312856
481946818162 |
Těsnění magnetické | 2 294 Kč
€ 100.80 |
||
| 231 1 WHR107745 |
C00333126
481946688956 |
PLATE THERMOSTAT SENSOR | Na dotaz | Zadat poptávku | |
| 231 2 WHR107745 |
C00343341
481946689101 |
Clamp sensor | Na dotaz | Zadat poptávku | |
| 241 0 WHR107745 |
C00499267
481945819706 |
BASKET | Na dotaz | Zadat poptávku | |
| 241 3 WHR107745 |
C00499169
481944228613 |
RUKOVAT KOSA | Na dotaz | Zadat poptávku | |
| 241 4 WHR107745 |
C00741022
481944278403 |
kryt | 705 Kč
€ 31.00 |
||
| 252 1 WHR107745 |
C00333095
481946279338 |
kryt | 121 Kč
€ 5.30 |
||
| 253 0 WHR107745 |
C00340904
481240448489 |
Fixation f. light switch | Na dotaz | Zadat poptávku | |
| 253 3 WHR107745 |
C00339614
481240448491 |
Holder f.Lightswitch | Na dotaz | Zadat poptávku | |
| 263 0 WHR107745 |
C00499355
481946238557 |
FRICTION PLATE | Na dotaz | Zadat poptávku | |
| 263 1 WHR107745 |
C00336946
481946238558 |
RAIL | Na dotaz | Zadat poptávku | |
| 263 2 WHR107745 |
C00499010
481940478193 |
DRZIAK VYPARNIKA N | Na dotaz | Zadat poptávku | |
| 263 3 WHR107745 |
C00499011
481940478194 |
DRZIAK VYPARNIKA N | Na dotaz | Zadat poptávku | |
| 301 8 WHR107745 |
C00312136
481228018015 |
jednotka signalek | 3 973 Kč
€ 174.60 |
||
| 335 2 WHR107745 |
C00333349
481953598346 |
Rod | Na dotaz | Zadat poptávku | |
| 402 0 WHR107745 |
C00741023
481936038703 |
Compressor BP 1111 Z | Na dotaz | Zadat poptávku | |
| 402 3 WHR107745 |
C00333348
481953598345 |
Fastener | Na dotaz | Zadat poptávku | |
| 402 4 WHR107745 |
C00333135
481946689405 |
PRICHYTKA | 120 Kč
€ 5.30 |
||
| 442 0 WHR107745 |
C00314229
481936178144 |
motorek ventilatoru | 2 093 Kč
€ 92.00 |
||
| 442 1 WHR107745 |
C00332945
481940478859 |
drzak | 169 Kč
€ 7.40 |
||
| 493 0 WHR107745 |
C00499385
481946279046 |
KRYT SVORKOVNICE MR.BOXU N | Na dotaz | Zadat poptávku | |
| 556 0 WHR107745 |
C00374331
481927129073 |
termostat A04- | 1 561 Kč
€ 68.60 |
||
| 561 0 WHR107745 |
C00337116
481928228499 |
ochrana motoru | 219 Kč
€ 9.60 |
||
| 561 2 WHR107745 |
C00498894
481929068198 |
svorkovnice | 267 Kč
€ 11.70 |
||
| 614 0 WHR107745 |
C00336871
481928068359 |
Relé rozběhové | Na dotaz | Zadat poptávku | |
| 740 0 WHR107745 |
C00332223
481251148068 |
Condenser | Na dotaz | Zadat poptávku | |
| 745 0 WHR107745 |
C00341093
481951138577 |
EVAPORATOR | Na dotaz | Zadat poptávku | |
| 745 1 WHR107745 |
C00333321
481953268708 |
Bushing | Na dotaz | Zadat poptávku | |
| 745 2 WHR107745 |
C00339412
481953028527 |
Hose | Na dotaz | Zadat poptávku | |
| 764 0 WHR107745 |
C00266743
481948028144 |
Filtr chladničky - patrona | Na dotaz | Zadat poptávku | |
| 904 2 WHR107745 |
C00336008
481946248175 |
Stopper | Na dotaz | Zadat poptávku | |
| 904 4 WHR107745 |
C00336009
481946248186 |
Stopper | Na dotaz | Zadat poptávku | |
| 904 5 WHR107745 |
C00336191
481953268471 |
SPACER | Na dotaz | Zadat poptávku | |
| 904 7 WHR107745 |
C00333278
481952918039 |
Spacer | Na dotaz | Zadat poptávku | |
| 934 2 WHR107745 |
C00336101
481949268431 |
pruzina | 106 Kč
€ 4.70 |
||
| 993 9 WHR107745 |
C00498910
481931038798 |
balicek montazni | 495 Kč
€ 21.80 |
||
| 999 WHR107745 |
C00786942 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
