BAUKNECHT GKEA 245 STUTT UPRIGHT FREEZERS BK
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | GKEA 245 STUTT UPRIGHT FREEZERS BK |
| Kód 12NC: | 855264701020 |
| I.C. kód: | 855264701022 |
| Značka: | BAUKNECHT |
| Typ produktu: | Volně stojící mrazáky |
| Další podobné modely: | 855264701021, 855264701023 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 011 0 WHR80897 |
C00330677
481246248398 |
Foot | Na dotaz | Zadat poptávku | |
| 012 1 WHR80897 |
C00333276
481952878028 |
kolecko lednice | Na dotaz | Zadat poptávku | |
| 012 2 WHR80897 |
C00333340
481953538013 |
osa kolecka lednice | 19 Kč
€ 0.80 |
||
| 040 0 WHR80897 |
C00339732
481231018753 |
HINGE KIT right/left | Na dotaz | Zadat poptávku | |
| 040 2 WHR80897 |
C00497780
481241718879 |
Hinge lower/right | Na dotaz | Zadat poptávku | |
| 040 4 WHR80897 |
C00497781
481241718881 |
Hinge lower/left | Na dotaz | Zadat poptávku | |
| 045 5 WHR80897 |
C00333341
481953538056 |
Shaft | Na dotaz | Zadat poptávku | |
| 045 8 WHR80897 |
C00317178
481253538098 |
kolik | Na dotaz | Zadat poptávku | |
| 045 9 WHR80897 |
C00315304
481953538093 |
Extension piece f.hing f.hinge | Na dotaz | Zadat poptávku | |
| 047 0 WHR80897 |
C00317172
481253268136 |
drzak dveri levy | Na dotaz | Zadat poptávku | |
| 047 1 WHR80897 |
C00320211
481253268135 |
Bushing | Na dotaz | Zadat poptávku | |
| 070 0 WHR80897 |
C00337686
481244089057 |
Plinth + insert | Na dotaz | Zadat poptávku | |
| 101 0 WHR80897 |
C00591146
481244069258 |
Door freezer. | Na dotaz | Zadat poptávku | |
| 105 2 WHR80897 |
C00320126
481946699106 |
distancni podlozka | Na dotaz | Zadat poptávku | |
| 105 6 WHR80897 |
C00344100
481244688141 |
Bushing | Na dotaz | Zadat poptávku | |
| 111 0 WHR80897 |
C00380916
481246268819 |
Door handle | Na dotaz | Zadat poptávku | |
| 156 0 WHR80897 |
C00287849
481941878977 |
miska na led | 180 Kč
€ 7.40 |
||
| 191 1 WHR80897 |
C00590029
481246818292 |
Magnetic seal. | Na dotaz | Zadat poptávku | |
| 233 0 WHR80897 |
C00589826
481241828636 |
Support. | Na dotaz | Zadat poptávku | |
| 233 1 WHR80897 |
C00374025
481246049427 |
Support | Na dotaz | Zadat poptávku | |
| 233 9 WHR80897 |
C00484014
481246049428 |
drzak mrizky | 708 Kč
€ 29.10 |
||
| 241 4 WHR80897 |
C00591139
481244069123 |
Flap. | Na dotaz | Zadat poptávku | |
| 241 5 WHR80897 |
C00511352
481244069122 |
Flap | Na dotaz | Zadat poptávku | |
| 242 7 WHR80897 |
C00591080
481241828556 |
Drawer. | Na dotaz | Zadat poptávku | |
| 242 9 WHR80897 |
C00591081
481241828557 |
Drawer. | Na dotaz | Zadat poptávku | |
| 263 0 WHR80897 |
C00340172
481946238886 |
kolejnice kose | Na dotaz | Zadat poptávku | |
| 263 2 WHR80897 |
C00319283
481240448879 |
drzak dveri vyparnik | Na dotaz | Zadat poptávku | |
| 263 3 WHR80897 |
C00319293
481240448881 |
drzak dveri vyparnik | Na dotaz | Zadat poptávku | |
| 263 6 WHR80897 |
C00311882
481953598591 |
Čep dvířek mrazáku Whirlpool | 1 528 Kč
€ 62.80 |
||
| 301 3 WHR80897 |
C00483456
481245228613 |
Control panel | Na dotaz | Zadat poptávku | |
| 301 4 WHR80897 |
C00591233
481246048949 |
Insert. | Na dotaz | Zadat poptávku | |
| 324 0 WHR80897 |
C00591231
481246048946 |
Insert. | Na dotaz | Zadat poptávku | |
| 324 1 WHR80897 |
C00591232
481246048947 |
Insert. | Na dotaz | Zadat poptávku | |
| 402 0 WHR80897 |
C00527363
481236038903 |
Compressor VEGT7C | Na dotaz | Zadat poptávku | |
| 491 0 WHR80897 |
C00574691
481229088091 |
Connect.block. | Na dotaz | Zadat poptávku | |
| 526 2 WHR80897 |
C00482449
481221778158 |
Unit electrical VCC2 compressor | Na dotaz | Zadat poptávku | |
| 526 5 WHR80897 |
C00574872
481245228565 |
Cover. | Na dotaz | Zadat poptávku | |
| 633 0 WHR80897 |
C00332844
481927618355 |
magnet | Na dotaz | Zadat poptávku | |
| 691 0 WHR80897 |
C00326911
481221058042 |
Sensor | Na dotaz | Zadat poptávku | |
| 691 3 WHR80897 |
C00329174
481240478272 |
Support sensor | Na dotaz | Zadat poptávku | |
| 740 0 WHR80897 |
C00590082
481251148375 |
CONDENSER. | Na dotaz | Zadat poptávku | |
| 740 3 WHR80897 |
C00333148
481946699109 |
Spacer | Na dotaz | Zadat poptávku | |
| 745 0 WHR80897 |
C00590060
481251138216 |
Evaporator. | Na dotaz | Zadat poptávku | |
| 764 0 WHR80897 |
C00266743
481948028144 |
Filtr chladničky - patrona Náhrada C00495431 |
Na dotaz | Zadat poptávku | |
| 781 0 WHR80897 |
C00331410
481245298259 |
Defroster plug | Na dotaz | Zadat poptávku | |
| 781 1 WHR80897 |
C00327909
481241889008 |
kanal odtokovy | 114 Kč
€ 4.70 |
||
| 903 0 WHR80897 |
C00333338
481953518117 |
Záslepka do dveří chladničky Whirlpool | 4 Kč
€ 0.20 |
||
| 965 3 WHR80897 |
C00498308
481245988014 |
Separator | Na dotaz | Zadat poptávku | |
| 993 4 WHR80897 |
C00328319
481244079087 |
Ice pack | 720 Kč
€ 29.60 |
||
| 993 7 WHR80897 |
C00591230
481246048945 |
Insert. | Na dotaz | Zadat poptávku | |
| 993 9 WHR80897 |
C00590988
481231028193 |
Door revers.Kit not shown | Na dotaz | Zadat poptávku | |
| 999 WHR80897 |
C00711604 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
