BAUKNECHT KGNA 301 WS REFRIGERATORS B
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | KGNA 301 WS REFRIGERATORS B |
| Kód 12NC: | 855020901210 |
| I.C. kód: | 855020901211 |
| Značka: | BAUKNECHT |
| Typ produktu: | Volně stojící lednice s mrazákem |
| Další podobné modely: | 855020901210 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 001 2 WHR80470 |
C00498593
481252518014 |
Guide | Na dotaz | Zadat poptávku | |
| 002 0 WHR80470 |
C00330806
481246418141 |
deska horni-kryt | Na dotaz | Zadat poptávku | |
| 002 1 WHR80470 |
C00326888
481215748001 |
VLOZKA PLAST | Na dotaz | Zadat poptávku | |
| 004 0 WHR80470 |
C00330828
481246428054 |
drzak kompr.a kolec | 563 Kč
€ 22.70 |
||
| 011 0 WHR80470 |
C00330455
481246218263 |
noha lednice | 61 Kč
€ 2.50 |
||
| 012 1 WHR80470 |
C00332373
481252878062 |
kolecko lednice | 311 Kč
€ 12.50 |
||
| 012 2 WHR80470 |
C00332726
481253578074 |
osa kolecka lednice | Na dotaz | Zadat poptávku | |
| 040 0 WHR80470 |
C00329716
481241719231 |
Hinge upper left | Na dotaz | Zadat poptávku | |
| 040 1 WHR80470 |
C00315502
481241719232 |
Hinge upper right | Na dotaz | Zadat poptávku | |
| 040 2 WHR80470 |
C00329754
481241719432 |
pant dveri spodni | 680 Kč
€ 27.40 |
||
| 040 3 WHR80470 |
C00318955
481231019124 |
Hinge middle kit | Na dotaz | Zadat poptávku | |
| 084 3 WHR80470 |
C00333280
481952918093 |
tlumic ventilatoru | 354 Kč
€ 14.30 |
||
| 101 0 WHR80470 |
C00458048
481241610094 |
DVEŘE MRAZNIČKY | Na dotaz | Zadat poptávku | |
| 104 0 WHR80470 |
C00458039
481241610079 |
Door refriger. printed Bauknecht | Na dotaz | Zadat poptávku | |
| 105 0 WHR80470 |
C00314960
481253288064 |
BUSHING WHITE GW | Na dotaz | Zadat poptávku | |
| 105 1 WHR80470 |
C00311490
481253288076 |
Pouzdro závěsu pravé | Na dotaz | Zadat poptávku | |
| 105 2 WHR80470 |
C00313005
481253288077 |
Pouzdro závěsu levé | 485 Kč
€ 19.50 |
||
| 152 2 WHR80470 |
C00458785
481241829748 |
Door dairy | Na dotaz | Zadat poptávku | |
| 154 0 WHR80470 |
C00458784
481241829747 |
Bottle shelf | Na dotaz | Zadat poptávku | |
| 155 0 WHR80470 |
C00339625
481241828448 |
drzak vajec | Na dotaz | Zadat poptávku | |
| 156 0 WHR80470 |
C00339162
481241828416 |
Icecube tray | Na dotaz | Zadat poptávku | |
| 190 1 WHR80470 |
C00333144
481946698957 |
Gasket | Na dotaz | Zadat poptávku | |
| 191 0 WHR80470 |
C00312531
481246668818 |
Těsnění magnetické do dveří lednice chladničky Whirlpool | 1 387 Kč
€ 55.80 |
||
| 191 1 WHR80470 |
C00311938
481246668817 |
Těsnění magnetické do dveří mrazáku chladničky Whirlpool | 1 356 Kč
€ 54.60 |
||
| 201 0 WHR80470 |
C00319407
481246228895 |
Cover front | Na dotaz | Zadat poptávku | |
| 201 1 WHR80470 |
C00344623
481244229332 |
Air conveyor | Na dotaz | Zadat poptávku | |
| 201 2 WHR80470 |
C00342502
481246228896 |
Cover fan miniplenum 06 | Na dotaz | Zadat poptávku | |
| 201 4 WHR80470 |
C00333098
481946279776 |
Cover wires | Na dotaz | Zadat poptávku | |
| 232 0 WHR80470 |
C00327716
481241829739 |
miska na kondenzát | Na dotaz | Zadat poptávku | |
| 241 0 WHR80470 |
C00317077
481241868334 |
kos mraznicky | 3 208 Kč
€ 129.10 |
||
| 241 2 WHR80470 |
C00315606
481241868299 |
kos mraznicky maly | Na dotaz | Zadat poptávku | |
| 241 4 WHR80470 |
C00381242
481241848781 |
Cover basket | Na dotaz | Zadat poptávku | |
| 241 5 WHR80470 |
C00590551
481241848779 |
Cover basket printed | Na dotaz | Zadat poptávku | |
| 242 0 WHR80470 |
C00342299
481241879806 |
Crisper | Na dotaz | Zadat poptávku | |
| 242 2 WHR80470 |
C00458939
481241868362 |
Drawer | Na dotaz | Zadat poptávku | |
| 244 7 WHR80470 |
C00458786
481241829751 |
Flap FFC printed | Na dotaz | Zadat poptávku | |
| 246 2 WHR80470 |
C00317765
481241848916 |
Tray icecubes | Na dotaz | Zadat poptávku | |
| 255 1 WHR80470 |
C00379147
481245088305 |
ODKLAD.PLOCHA SKLO | Na dotaz | Zadat poptávku | |
| 255 2 WHR80470 |
C00460192
481245088336 |
Glass shelf FFC | Na dotaz | Zadat poptávku | |
| 256 1 WHR80470 |
C00330655
481246238232 |
kolik | 263 Kč
€ 10.60 |
||
| 261 0 WHR80470 |
C00464522
481246818363 |
Rail for basket right | Na dotaz | Zadat poptávku | |
| 261 1 WHR80470 |
C00345161
481246818364 |
Rail for basket left | Na dotaz | Zadat poptávku | |
| 264 0 WHR80470 |
C00332376
481252878073 |
kolecko zasuvky | 75 Kč
€ 3.00 |
||
| 301 0 WHR80470 |
C00464328
481246469254 |
Control panel | Na dotaz | Zadat poptávku | |
| 301 1 WHR80470 |
C00328422
481244098137 |
kryt | Na dotaz | Zadat poptávku | |
| 301 4 WHR80470 |
C00330515
481246228615 |
Cover | Na dotaz | Zadat poptávku | |
| 301 5 WHR80470 |
C00319387
481246228614 |
kryt zavesu horniho | Na dotaz | Zadat poptávku | |
| 334 0 WHR80470 |
C00374101
481241218033 |
Knob | Na dotaz | Zadat poptávku | |
| 335 5 WHR80470 |
C00327070
481222318433 |
Regulator | Na dotaz | Zadat poptávku | |
| 402 0 WHR80470 |
C00313753
481236058114 |
COMPRESSOR | Na dotaz | Zadat poptávku | |
| 402 1 WHR80470 |
C00319502
481241870024 |
miska na kondenzat | 212 Kč
€ 8.50 |
||
| 402 2 WHR80470 |
C00195454
481936048014 |
VENTIL | Na dotaz | Zadat poptávku | |
| 420 0 WHR80470 |
C00318160
481212028053 |
Kondenzátor 5 µF | 191 Kč
€ 7.70 |
||
| 440 0 WHR80470 |
C00312313
481936118428 |
motor ventilatoru | Na dotaz | Zadat poptávku | |
| 440 5 WHR80470 |
C00340262
481945858558 |
Grid air | Na dotaz | Zadat poptávku | |
| 442 3 WHR80470 |
C00333097
481946279775 |
Cover | Na dotaz | Zadat poptávku | |
| 443 0 WHR80470 |
C00313351
481951548034 |
vrtule ventilatoru | 241 Kč
€ 9.70 |
||
| 451 0 WHR80470 |
C00314276
481225948194 |
topeni | 2 765 Kč
€ 111.30 |
||
| 451 1 WHR80470 |
C00319364
481225948205 |
topeni | Na dotaz | Zadat poptávku | |
| 491 3 WHR80470 |
C00267000
481229088084 |
KRYT PLAST | Na dotaz | Zadat poptávku | |
| 526 3 WHR80470 |
C00315770
481244079239 |
prepinac otocny | Na dotaz | Zadat poptávku | |
| 561 2 WHR80470 |
C00267004
481229088112 |
konektor | 85 Kč
€ 3.40 |
||
| 562 0 WHR80470 |
C00312889
481228228281 |
termostat | 1 420 Kč
€ 57.20 |
||
| 566 1 WHR80470 |
C00333185
481949268723 |
pruzina | 248 Kč
€ 10.00 |
||
| 614 0 WHR80470 |
C00327503
481228068373 |
Monoblock | Na dotaz | Zadat poptávku | |
| 651 0 WHR80470 |
C00313818
481913488178 |
Lamp Tclick T25 - 15W - 220V | Na dotaz | Zadat poptávku | |
| 652 0 WHR80470 |
C00315045
481225528026 |
Holder lamp | Na dotaz | Zadat poptávku | |
| 652 2 WHR80470 |
C00317259
481244098245 |
Housing lamp | Na dotaz | Zadat poptávku | |
| 656 0 WHR80470 |
C00312883
481246098066 |
Stínidlo světla | Na dotaz | Zadat poptávku | |
| 691 7 WHR80470 |
C00311307
481231018846 |
Senzor teploty chladničky Whirlpool - sada | 1 534 Kč
€ 61.80 |
||
| 740 0 WHR80470 |
C00332244
481251148382 |
Condenser | Na dotaz | Zadat poptávku | |
| 740 1 WHR80470 |
C00330494
481246228448 |
Holder | Na dotaz | Zadat poptávku | |
| 743 0 WHR80470 |
C00482954
481244079162 |
Air diffuser multiflow cpl.+ chart | Na dotaz | Zadat poptávku | |
| 746 0 WHR80470 |
C00341085
481251138331 |
VYPARNIK | Na dotaz | Zadat poptávku | |
| 764 0 WHR80470 |
C00311590
481952648527 |
Dryer DRS15 With 3 ways valve | Na dotaz | Zadat poptávku | |
| 783 0 WHR80470 |
C00318198
481952643046 |
SPOJKA | 161 Kč
€ 6.50 |
||
| 965 0 WHR80470 |
C00332698
481253288061 |
Cover | Na dotaz | Zadat poptávku | |
| 965 1 WHR80470 |
C00332688
481253288029 |
zaslepka 480132102378 | Na dotaz | Zadat poptávku | |
| 965 2 WHR80470 |
C00316614
481222608029 |
zaslepka | Na dotaz | Zadat poptávku | |
| 965 6 WHR80470 |
C00330501
481246228511 |
drzak | Na dotaz | Zadat poptávku | |
| 965 7 WHR80470 |
C00316993
481222608003 |
zaslepka | Na dotaz | Zadat poptávku | |
| 999 WHR80470 |
C00710738 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
