| Komerční kód: | KHGL 7510/B |
| Kód 12NC: | 851330538000 |
| I.C. kód: | 851330538001 |
| Značka: | KITCHENAID |
| Typ produktu: | Vestavné trouby a varné desky |
| Další podobné modely: | 851330538000, Q0917380000, Q0917380001, 851330529000, 851330529001 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 0310 WHR00757 |
C00328170
481244030004 |
Ceramic hob | Na dotaz | Zadat poptávku | |
| 0330 WHR00757 |
C00330189
481245858522 |
Grid for hob | Na dotaz | Zadat poptávku | |
| 0331 WHR00757 |
C00330186
481245858518 |
Grid for hob | Na dotaz | Zadat poptávku | |
| 0332 WHR00757 |
C00330188
481245858521 |
Grid for hob central | Na dotaz | Zadat poptávku | |
| 0334 WHR00757 |
C00328733
481236068963 |
Wok grid | Na dotaz | Zadat poptávku | |
| 0338 WHR00757 |
C00330467
481246218309 |
Foot | Na dotaz | Zadat poptávku | |
| 0343 WHR00757 |
C00328730
481236068959 |
Cover AUX | Na dotaz | Zadat poptávku | |
| 0344 WHR00757 |
C00328731
481236068961 |
Cover SR | Na dotaz | Zadat poptávku | |
| 0346 WHR00757 |
C00328735
481236068967 |
Cover MWK | Na dotaz | Zadat poptávku | |
| 3343 WHR00757 |
C00325270
481010564640 |
Knob | Na dotaz | Zadat poptávku | |
| 4700 WHR00757 |
C00319136
481236068814 |
teleso hořáku | Na dotaz | Zadat poptávku | |
| 4701 WHR00757 |
C00318490
481236068815 |
Dno hořáku | Na dotaz | Zadat poptávku | |
| 4703 WHR00757 |
C00319960
481236058597 |
Injector holder MWK | Na dotaz | Zadat poptávku | |
| 4710 WHR00757 |
C00316269
481236078135 |
teleso horaku male | Na dotaz | Zadat poptávku | |
| 4711 WHR00757 |
C00313807
481236078136 |
Těleso hořáku plynové varné desky Whirlpool - střední | 307 Kč
€ 12.60 |
||
| 4713 WHR00757 |
C00313733
480121100582 |
horak | Na dotaz | Zadat poptávku | |
| 4730 WHR00757 |
C00328726
481236068955 |
Burner cap AUX | Na dotaz | Zadat poptávku | |
| 4731 WHR00757 |
C00328727
481236068956 |
Burner cap SR | Na dotaz | Zadat poptávku | |
| 4733 WHR00757 |
C00328794
481236078189 |
Burner cap outer MWK | Na dotaz | Zadat poptávku | |
| 4736 WHR00757 |
C00313801
481236068964 |
viko horaku vnitřní náhrada C00313801 | Na dotaz | Zadat poptávku | |
| 4740 WHR00757 |
C00328444
481231039199 |
Set of nozzles G20-20 mbar | Na dotaz | Zadat poptávku | |
| 4743 WHR00757 |
C00328446
481231039202 |
Set of nozzles G30-29 mbar | Na dotaz | Zadat poptávku | |
| 4910 WHR00757 |
C00327598
481229068318 |
svorkovnice | 183 Kč
€ 7.50 |
||
| 5711 WHR00757 |
C00317153
481010651489 |
Gas cock SR G20 | Na dotaz | Zadat poptávku | |
| 5712 WHR00757 |
C00316481
481010651488 |
Ventil plynový | 1 535 Kč
€ 63.00 |
||
| 5713 WHR00757 |
C00325896
481010651480 |
Gas cock MWK 4C/3C G20 | Na dotaz | Zadat poptávku | |
| 5910 WHR00757 |
C00314182
481225268078 |
svicka zapalovaci | 289 Kč
€ 11.90 |
||
| 5911 WHR00757 |
C00316649
481249268204 |
Spring spark plug | Na dotaz | Zadat poptávku | |
| 5912 WHR00757 |
C00312417
481225268079 |
svicka zapalovaci | 374 Kč
€ 15.30 |
||
| 5913 WHR00757 |
C00345757
481249268206 |
pružina | 405 Kč
€ 16.60 |
||
| 5920 WHR00757 |
C00325293
481010566188 |
termopojistka | 687 Kč
€ 28.20 |
||
| 5921 WHR00757 |
C00318235
481249268205 |
pružina | 167 Kč
€ 6.80 |
||
| 5929 WHR00757 |
C00311409
481213838053 |
Termočlánek MWK plynové varné desky Whirlpool, Indesit nahrazeno C00311409 | Na dotaz | Zadat poptávku | |
| 5940 WHR00757 |
C00327433
481227648146 |
Electronic ignition | Na dotaz | Zadat poptávku | |
| 5950 WHR00757 |
C00316225
481213818017 |
Transf,puls | 759 Kč
€ 31.10 |
||
| 7030 WHR00757 |
C00332591
481253049295 |
Gas pipe SR left | Na dotaz | Zadat poptávku | |
| 7031 WHR00757 |
C00332594
481253049298 |
Gas pipe AUX | Na dotaz | Zadat poptávku | |
| 7032 WHR00757 |
C00332592
481253049296 |
Gas pipe SR right | Na dotaz | Zadat poptávku | |
| 7033 WHR00757 |
C00332596
481253049322 |
Gas pipe MWK | Na dotaz | Zadat poptávku | |
| 7039 WHR00757 |
C00317975
481931039599 |
Koleno | 184 Kč
€ 7.50 |
||
| 7940 WHR00757 |
C00314461
481246688908 |
Gasket | Na dotaz | Zadat poptávku | |
| 7941 WHR00757 |
C00314988
481953258229 |
Těsnění | Na dotaz | Zadat poptávku | |
| 7942 WHR00757 |
C00332761
481281518763 |
O-Ring | Na dotaz | Zadat poptávku | |
| 7944 WHR00757 |
C00333307
482000091781 |
Seal pressure chamber ring | Na dotaz | Zadat poptávku | |
| 9001 WHR00757 |
C00328995
481240418589 |
Clamp hob | Na dotaz | Zadat poptávku | |
| 9100 WHR00757 |
C00312965
481250218757 |
Šroubek | Na dotaz | Zadat poptávku | |
| 9120 WHR00757 |
C00332121
481250218754 |
Screw M4x18 | Na dotaz | Zadat poptávku | |
| 9222 WHR00757 |
C00333306
481953058068 |
Gasket ring | Na dotaz | Zadat poptávku | |
| 9225 WHR00757 |
C00312206
481246668814 |
Podložka knoflíku | Na dotaz | Zadat poptávku | |
| 9226 WHR00757 |
C00331516
481246688854 |
Těsnění pod varné desky | 242 Kč
€ 9.90 |
||
| 9322 WHR00757 |
C00317038
481249268203 |
Pružina | 43 Kč
€ 1.80 |
||
| 9640 WHR00757 |
C00319999
481246689004 |
Těsnění varné desky | 594 Kč
€ 24.40 |
||
| 999 WHR00757 |
C00351215 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
| 999 WHR00757 |
C00351216 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
| 999 WHR00757 |
C00351217 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
| 999 WHR00757 |
C00351218 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
| 999 WHR00757 |
C00351219 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
