ARISTON K-UP 140
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | K-UP 140 |
| Kód 12NC: | 869990062240 |
| I.C. kód: | 47062240000 |
| Značka: | ARISTON |
| Typ produktu: | Vestavné mrazáky |
| Další podobné modely: | 47062240100, 47062240000, 47062240100 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 004 5220110 |
C00013120
482000044476 |
UPPER HINGE | Na dotaz | Zadat poptávku | |
| 004 5220110 |
C00013123 | ROOF WHITE | Na dotaz | Zadat poptávku | |
| 005 5220110 |
C00010699
482000072639 |
PIN FOR HINGE AND ROOF M5X16 MM | Na dotaz | Zadat poptávku | |
| 009 5220110 |
C00003261
482000025912 |
ŠKRABKA LEDU (730412) | Na dotaz | Zadat poptávku | |
| 016 5220110 |
C00011641 | HINGE BUSH 15X3X17 | Na dotaz | Zadat poptávku | |
| 018 5220110 |
C00007754 | PIPE BEIGE D.8,5 MM'COVER CAP' | Na dotaz | Zadat poptávku | |
| 025 5220110 |
C00008699
482000050031 |
MAGNETIC GASKET | Na dotaz | Zadat poptávku | |
| 025 5220110 |
C00014128 | PIERCED DOOR ASSEMBLY 812X544X17,5 | Na dotaz | Zadat poptávku | |
| 039 5220110 |
C00009624 | DOOR WHITE (014551) | Na dotaz | Zadat poptávku | |
| 040 5220110 |
C00008888 | BASKET DOOR WHITE (014551) | Na dotaz | Zadat poptávku | |
| 041 5220110 |
C00008848 | BASKET (014551) | Na dotaz | Zadat poptávku | |
| 042 5220110 |
C00014125 | BASE ARISTON | Na dotaz | Zadat poptávku | |
| 043 5220110 |
C00013121 | LOWER HINGE | Na dotaz | Zadat poptávku | |
| 045 5220110 |
C00006966 | FOOT | Na dotaz | Zadat poptávku | |
| 046 5220110 |
C00012798 | FOOT SUPPORT | Na dotaz | Zadat poptávku | |
| 048 5220110 |
C00008736 | BASKET STOP | Na dotaz | Zadat poptávku | |
| 049 5220110 |
C00011381
482000043818 |
SPRING-REST DX DOOR | Na dotaz | Zadat poptávku | |
| 049 5220110 |
C00011382
482000043819 |
SPRING-REST SX DOOR | Na dotaz | Zadat poptávku | |
| 050 5220110 |
C00014395 | EVAPORATOR PLATE STOP UPPER DX | Na dotaz | Zadat poptávku | |
| 050 5220110 |
C00014396 | EVAPORATOR PLATE STOP UPPER SX | Na dotaz | Zadat poptávku | |
| 052 5220110 |
C00011304 | SYMBOLS SUPPORT BROWN | Na dotaz | Zadat poptávku | |
| 052 5220110 |
C00011305 | SYMBOLS SUPPORT ORANGE | Na dotaz | Zadat poptávku | |
| 099 5220110 |
C00013125 | VERTICAL PROFILE PVC 1570MM | Na dotaz | Zadat poptávku | |
| 099 5220110 |
C00013118
482000044475 |
SMALL DOOR RAIL BEIGE | Na dotaz | Zadat poptávku | |
| 099 5220110 |
C00013119
482000043512 |
DOOR RAIL BEIGE | Na dotaz | Zadat poptávku | |
| 006 5220120 |
C00014970 | PIN FOR LOWER HINGE M5X(8+19,5) MM | Na dotaz | Zadat poptávku | |
| 016 5220120 |
C00013720 | QUADRANGULAR HINGE BUSH | Na dotaz | Zadat poptávku | |
| 025 5220120 |
C00012800 | PILOT LAMP | Na dotaz | Zadat poptávku | |
| 026 5220120 |
C00012799 | PILOT LAMP SUPPORT | Na dotaz | Zadat poptávku | |
| 027 5220120 |
C00011271 | BUSH FOR DOOR STOP | Na dotaz | Zadat poptávku | |
| 029 5220120 |
C00013721 | MAGNETIC DASKET BROWN | Na dotaz | Zadat poptávku | |
| 029 5220120 |
C00014964
482000044550 |
ASSEMBLY DOOR PROD 80 812X544X17,5 | Na dotaz | Zadat poptávku | |
| 041 5220120 |
C00014612
482000025956 |
ROZPĚRNÝ KROUŽEK | Na dotaz | Zadat poptávku | |
| 043 5220120 |
C00014394
482000044516 |
DOOR COMPART SENAPE SUPER/FREEZER BROWN | Na dotaz | Zadat poptávku | |
| 043 5220120 |
C00014623
482000044532 |
HOLE FOR MOULDING WITH DOOR H202 | Na dotaz | Zadat poptávku | |
| 044 5220120 |
C00014408
482000044519 |
LOWER DRAWER BEIGE 550 | Na dotaz | Zadat poptávku | |
| 045 5220120 |
C00014379 | BEIGE-SENAPE CALENDAR FREEZER | Na dotaz | Zadat poptávku | |
| 046 5220120 |
C00014380 | SENAPE-YELLOW CALENDAR FREEZER | Na dotaz | Zadat poptávku | |
| 050 5220120 |
C00014967 | LOWER HINGE (1980) | Na dotaz | Zadat poptávku | |
| 001 5220130 |
C00017857
482000044613 |
UPPER/INF COVERING PROFILE BEIGE H=12MM | Na dotaz | Zadat poptávku | |
| 001 5220130 |
C00018777 | UNDER COVERING PROFIL WHITE | Na dotaz | Zadat poptávku | |
| 008 5220130 |
C00018413
482000044629 |
DOOR YELLOW TRASP. SUPERFREEZE ARISTON | Na dotaz | Zadat poptávku | |
| 026 5220130 |
C00014965
482000044551 |
ASSEMBLY DOOR PROD.81 BEIGE (785X544X17,5 | Na dotaz | Zadat poptávku | |
| 041 5220130 |
C00017901 | LATERAL BASE DX-SX H=24 MM'I-K-KC160-220' | Na dotaz | Zadat poptávku | |
| 045 5220130 |
C00014968
482000044552 |
LOWER HINGE (1981) | Na dotaz | Zadat poptávku | |
| 003 5220210 |
C00011320 | UPPER PLATE AL | Na dotaz | Zadat poptávku | |
| 004 5220210 |
C00011328
482000050066 |
EXPANSION DRYER ASSEMBLY | Na dotaz | Zadat poptávku | |
| 005 5220210 |
C00010948 | MIDDLE PLATE AL (71010) | Na dotaz | Zadat poptávku | |
| 006 5220210 |
C00011299 | THERMOSTAT SENSOR PLATE | Na dotaz | Zadat poptávku | |
| 008 5220210 |
C00010947 | LOWER PLATE AL (71010) | Na dotaz | Zadat poptávku | |
| 010 5220210 |
C00009872 | FILTER 12 GR + (014800) | Na dotaz | Zadat poptávku | |
| 011 5220210 |
C00008800 | EARTH LEAD | Na dotaz | Zadat poptávku | |
| 013 5220210 |
C00009398 | EARTHING PLATE | Na dotaz | Zadat poptávku | |
| 014 5220210 |
C00006962 | U-PLATE | Na dotaz | Zadat poptávku | |
| 016 5220210 |
C00008591 | EARTH PLATE COMPRESSOR ASPERA-MATSUSHITA | Na dotaz | Zadat poptávku | |
| 017 5220210 |
C00010027 | COMPRESSOR CROSS-PIECE | Na dotaz | Zadat poptávku | |
| 017 5220210 |
C00016534 | COMPRESSOR CROSS-PIECE | Na dotaz | Zadat poptávku | |
| 019 5220210 |
C00010385
482000044432 |
COMPRESSOR A1075A-B1075A 220-240/50 +FLAS | Na dotaz | Zadat poptávku | |
| 020 5220210 |
C00009046 | RUBBER SHOCK ABSORBER DI.10/DE.22-25/H=16 | Na dotaz | Zadat poptávku | |
| 021 5220210 |
C00006497
482000053933 |
SPACER NECCHI, 9X16 MM | Na dotaz | Zadat poptávku | |
| 022 5220210 |
C00008471
482000041838 |
FIXING PLATE COMPRESSOR | Na dotaz | Zadat poptávku | |
| 023 5220210 |
C00008727
482000025926 |
TRUBKA NAPOUŠTĚNÍ DE.5,8X180MM BEZ VALVE | Na dotaz | Zadat poptávku | |
| 023 5220210 |
C00043021
482000074099 |
TRUBKA LOKRING S VENTILEM A (6 NFMSSV) | Na dotaz | Zadat poptávku | |
| 024 5220210 |
C00012627 | PIPE-CLAMP | Na dotaz | Zadat poptávku | |
| 027 5220210 |
C00014127
482000044511 |
CONDENSER 500X546X22 | Na dotaz | Zadat poptávku | |
| 028 5220210 |
C00011327
482000044457 |
SET OF EVAPORATOR AL | Na dotaz | Zadat poptávku | |
| 028 5220210 |
C00018574
482000050136 |
EVAPORATOR CONDENSER | Na dotaz | Zadat poptávku | |
| 001 5220310 |
C00008851 | FEEDER (KEMA-VDE-OVE-IMQ-F-D-N) | Na dotaz | Zadat poptávku | |
| 006 5220310 |
C00010375 | RELAY 9660-437-095 'ZEM E36101 220V' | Na dotaz | Zadat poptávku | |
| 007 5220310 |
C00008607 | THERMOPROTECTOR SPRING ASPERA (750509) | Na dotaz | Zadat poptávku | |
| 008 5220310 |
C00010374
482000052044 |
THERMOPROTECTOR MRP412HZL3119 | Na dotaz | Zadat poptávku | |
| 010 5220310 |
C00008586 | TERMINAL BOARD ASPERA (750509) | Na dotaz | Zadat poptávku | |
| 011 5220310 |
C00008590 | TERMINAL BOARD COVER ASPERA (750509) | Na dotaz | Zadat poptávku | |
| 012 5220310 |
C00008589 | COVER SPRING ASPERA/ZEM (750509) | Na dotaz | Zadat poptávku | |
| 013 5220310 |
C00008608 | CABLE CLAMP ASPERA (750509) | Na dotaz | Zadat poptávku | |
| 017 5220310 |
C00012803 | WIRING ASPERA | Na dotaz | Zadat poptávku | |
| 018 5220310 |
C00012802 | CONTROL BRACKET MICROEL-ERZ | Na dotaz | Zadat poptávku | |
| 020 5220310 |
C00011337 | THERMOSTAT KNOB FREEZER | Na dotaz | Zadat poptávku | |
| 021 5220310 |
C00012801 | CONTROL SUPPORTING BRACKET | Na dotaz | Zadat poptávku | |
| 022 5220310 |
C00011358 | BULB PROTECTIVE THERMOSTAT 4X950MM | Na dotaz | Zadat poptávku | |
| 022 5220310 |
C00011302
482000044454 |
THERMOSTAT L390087 | Na dotaz | Zadat poptávku | |
| 001 5220320 |
C00008593 | SUPPLY CABLE (3X0,75) NECCHI-EGER | Na dotaz | Zadat poptávku | |
| 011 5220320 |
C00015359 | THERMOSTAT BOX | Na dotaz | Zadat poptávku | |
| 012 5220320 |
C00017878 | PLATE THERMOSTAT | Na dotaz | Zadat poptávku | |
| 017 5220320 |
C00017887 | THERMOSTAT ATEA L3C-0139 | Na dotaz | Zadat poptávku | |
| 027 5220320 |
C00017885
482000072762 |
OVLÁDACÍ JEDNOTKA | Na dotaz | Zadat poptávku | |
| 028 5220320 |
C00017890 | CONTROL SWITCH COVER | Na dotaz | Zadat poptávku | |
