| Komerční kód: | OBI 9M S |
| Kód 12NC/I.C. kód: | 857791815000 |
| Značka: | IKEA |
| Typ produktu: | Vestavné trouby a varné desky |
| Další podobné modely: | Q0924880000, 857791815001, Q0924880001 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 022 0 WHR05746 |
C00341537 | Panel right side | Na dotaz | Zadat poptávku | |
| 022 1 WHR05746 |
C00341577 | Panel left side | Na dotaz | Zadat poptávku | |
| 022 2 WHR05746 |
C00340724 | Frame right post | Na dotaz | Zadat poptávku | |
| 022 3 WHR05746 |
C00340735 | Frame left post | Na dotaz | Zadat poptávku | |
| 025 0 WHR05746 |
C00335218
481246079053 |
Trim lower frame | Na dotaz | Zadat poptávku | |
| 025 1 WHR05746 |
C00337533 | Profile | Na dotaz | Zadat poptávku | |
| 025 2 WHR05746 |
C00337522 | Profile upper heat guard | Na dotaz | Zadat poptávku | |
| 040 0 WHR05746 |
C00339784
481241719322 |
Hinge oven door | Na dotaz | Zadat poptávku | |
| 040 1 WHR05746 |
C00339821
481241718864 |
Hinge inner door (upper) | Na dotaz | Zadat poptávku | |
| 043 1 WHR05746 |
C00316860
481241718863 |
Hinge left | Na dotaz | Zadat poptávku | |
| 043 2 WHR05746 |
C00316858 | Hinge right | Na dotaz | Zadat poptávku | |
| 100 0 WHR05746 |
C00337947 | Oven door complete (lower) | Na dotaz | Zadat poptávku | |
| 100 1 WHR05746 |
C00337946 | Oven door complete (upper) | Na dotaz | Zadat poptávku | |
| 110 0 WHR05746 |
C00339986 | Handle WP S/Steel | Na dotaz | Zadat poptávku | |
| 110 1 WHR05746 |
C00329035 | Holder door | Na dotaz | Zadat poptávku | |
| 110 2 WHR05746 |
C00344164 | Bracket oven door | Na dotaz | Zadat poptávku | |
| 121 0 WHR05746 |
C00337943 | Oven door inner | Na dotaz | Zadat poptávku | |
| 121 1 WHR05746 |
C00337942 | Oven door inner (upper) | Na dotaz | Zadat poptávku | |
| 130 0 WHR05746 |
C00344202 | Bracket childlock | Na dotaz | Zadat poptávku | |
| 130 1 WHR05746 |
C00344203 | Bracket childlock | Na dotaz | Zadat poptávku | |
| 130 2 WHR05746 |
C00340103 | Handle childlock | Na dotaz | Zadat poptávku | |
| 142 0 WHR05746 |
C00337945
481245059422 |
Oven door glass | Na dotaz | Zadat poptávku | |
| 142 1 WHR05746 |
C00340375 | Glass medium | Na dotaz | Zadat poptávku | |
| 142 2 WHR05746 |
C00335806 | Support oven door glass right | Na dotaz | Zadat poptávku | |
| 142 3 WHR05746 |
C00335807 | Support oven door glass left | Na dotaz | Zadat poptávku | |
| 142 4 WHR05746 |
C00340762 | FRAME | Na dotaz | Zadat poptávku | |
| 143 0 WHR05746 |
C00317626 | Oven door glass | Na dotaz | Zadat poptávku | |
| 143 1 WHR05746 |
C00340328 | Glass thermo | Na dotaz | Zadat poptávku | |
| 191 0 WHR05746 |
C00316005
481246688659 |
Gasket oven seal | Na dotaz | Zadat poptávku | |
| 191 1 WHR05746 |
C00313521
481204658002 |
GASKET | Na dotaz | Zadat poptávku | |
| 192 0 WHR05746 |
C00340553 | GASKET | Na dotaz | Zadat poptávku | |
| 192 1 WHR05746 |
C00340451 | Gasket ext. glass | Na dotaz | Zadat poptávku | |
| 192 2 WHR05746 |
C00316815 | GASKET | Na dotaz | Zadat poptávku | |
| 201 0 WHR05746 |
C00341061 | Fan diffuser | Na dotaz | Zadat poptávku | |
| 245 0 WHR05746 |
C00342073
481245819289 |
Oven shelf | Na dotaz | Zadat poptávku | |
| 245 1 WHR05746 |
C00340234
481245819025 |
GRILL GRID | Na dotaz | Zadat poptávku | |
| 247 0 WHR05746 |
C00335320
481241838093 |
Tray oven | Na dotaz | Zadat poptávku | |
| 247 1 WHR05746 |
C00339996
481245819291 |
Handle oven tray | Na dotaz | Zadat poptávku | |
| 261 0 WHR05746 |
C00340241 | Grid oven side | Na dotaz | Zadat poptávku | |
| 261 2 WHR05746 |
C00328960
481240418118 |
Bracket | Na dotaz | Zadat poptávku | |
| 261 8 WHR05746 |
C00344162
481245818976 |
Bracket racks side | Na dotaz | Zadat poptávku | |
| 301 0 WHR05746 |
C00343206 | Control panel support | Na dotaz | Zadat poptávku | |
| 320 0 WHR05746 |
C00342636 | Control panel | Na dotaz | Zadat poptávku | |
| 331 0 WHR05746 |
C00318183
481241259122 |
Knob BL | Na dotaz | Zadat poptávku | |
| 332 0 WHR05746 |
C00335762 | SWITCH | Na dotaz | Zadat poptávku | |
| 351 0 WHR05746 |
C00311750
481213428063 |
Pilot lamp yellow | Na dotaz | Zadat poptávku | |
| 354 1 WHR05746 |
C00311674
481221778107 |
Lens lens (yellow) | Na dotaz | Zadat poptávku | |
| 400 0 WHR05746 |
C00315607
481202858333 |
motor fan tang. | Na dotaz | Zadat poptávku | |
| 401 0 WHR05746 |
C00314813
481202858332 |
MOTOR | Na dotaz | Zadat poptávku | |
| 440 0 WHR05746 |
C00314972
481202858331 |
Motor fan fan | Na dotaz | Zadat poptávku | |
| 451 0 WHR05746 |
C00316214
481225998485 |
Heating element circular | Na dotaz | Zadat poptávku | |
| 452 0 WHR05746 |
C00312039
481225948111 |
Topné těleso trouby – horní + grill | Na dotaz | Zadat poptávku | |
| 456 0 WHR05746 |
C00311969
481225948189 |
Heating element lower | Na dotaz | Zadat poptávku | |
| 491 0 WHR05746 |
C00327595
481229068305 |
Terminal Board | Na dotaz | Zadat poptávku | |
| 500 0 WHR05746 |
C00335452
481221458215 |
Timer | Na dotaz | Zadat poptávku | |
| 500 1 WHR05746 |
C00335786 | Support timer | Na dotaz | Zadat poptávku | |
| 521 0 WHR05746 |
C00314539
481227328158 |
Selector,switch and thermostat | Na dotaz | Zadat poptávku | |
| 521 1 WHR05746 |
C00314735
481228208648 |
Switch,oven + thermostat upper | Na dotaz | Zadat poptávku | |
| 522 0 WHR05746 |
C00315975
481227328159 |
REGULATOR | Na dotaz | Zadat poptávku | |
| 554 1 WHR05746 |
C00315994
481228268022 |
Holder Thermostat | Na dotaz | Zadat poptávku | |
| 561 0 WHR05746 |
C00314981
481221538001 |
Thermostat safety T115 | Na dotaz | Zadat poptávku | |
| 562 0 WHR05746 |
C00319446
481228248286 |
termostat | Na dotaz | Zadat poptávku | |
| 652 0 WHR05746 |
C00327121
481225518243 |
Lamp oven 50HZ 25W | Na dotaz | Zadat poptávku | |
| 652 1 WHR05746 |
C00342075 | Oven Lamp | Na dotaz | Zadat poptávku | |
| 743 0 WHR05746 |
C00343127
481213638006 |
Conveyor air | Na dotaz | Zadat poptávku | |
| 910 0 WHR05746 |
C00336588
481250218474 |
Screw door stop | Na dotaz | Zadat poptávku | |
| 910 0 WHR05746 |
C00342212 | Damper Oven door | Na dotaz | Zadat poptávku | |
| 999 WHR05746 |
C00371993 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
| 999 WHR05746 |
C00371994 | SERVICE MANUAL WHP | Na dotaz | Zadat poptávku | |
