WHIRLPOOL SPIW412A1
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | SPIW412A1 |
| Kód 12NC/I.C. kód: | 859991584360 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 001 SPIW412I |
C00386236
482000010322 |
Mounting plate | Na dotaz | Zadat poptávku | |
| 002 SPIW412I |
C00533351
488000533351 |
baffle | Na dotaz | Zadat poptávku | |
| 003 SPIW412I |
C00386303
482000021180 |
Rear panel | Na dotaz | Zadat poptávku | |
| 004 SPIW412I |
C00385801
482000010300 |
Air guide | Na dotaz | Zadat poptávku | |
| 005 SPIW412I |
C00386251
482000021181 |
Air guide | Na dotaz | Zadat poptávku | |
| 006 SPIW412I |
C00378268
482000010298 |
Turbine blades | Na dotaz | Zadat poptávku | |
| 007 SPIW412I |
C00377868
481252048017 |
Bearing | Na dotaz | Zadat poptávku | |
| 008 SPIW412I |
C00385811
482000010297 |
Baffle | Na dotaz | Zadat poptávku | |
| 009 SPIW412I |
C00386261
482000021240 |
Evaporator | Na dotaz | Zadat poptávku | |
| 010 SPIW412I |
C00627209
488000627209 |
Kryt motoru | Na dotaz | Zadat poptávku | |
| 011 SPIW412I |
C00378271
482000010312 |
Motor ventilátoru klimatizace Whirlpool | 3 909 Kč
€ 159.90 |
||
| 012 SPIW412I |
C00630579
488000630579 |
motor cover | Na dotaz | Zadat poptávku | |
| 013 SPIW412I |
C00506408
482000095040 |
Remote control | Na dotaz | Zadat poptávku | |
| 014 SPIW412I |
C00385823
482000010315 |
Electric box cover | Na dotaz | Zadat poptávku | |
| 015 SPIW412I |
C00378138
482000000399 |
Temperature sensor | Na dotaz | Zadat poptávku | |
| 016 SPIW412I |
C00378139
482000000400 |
Sensor temper. coil | Na dotaz | Zadat poptávku | |
| 017 SPIW412I |
C00385825
482000092111 |
Clamp | Na dotaz | Zadat poptávku | |
| 018 SPIW412I |
C00386257
482000021188 |
Mains cable | Na dotaz | Zadat poptávku | |
| 019 SPIW412I |
C00386171
482000010332 |
Wire terminal board | Na dotaz | Zadat poptávku | |
| 020 SPIW412I |
C00385837
482000010307 |
Electric box cover | Na dotaz | Zadat poptávku | |
| 021 SPIW412I |
C00385841
482000010303 |
Electric parts box cover | Na dotaz | Zadat poptávku | |
| 022 SPIW412I |
C00632987
488000632987 |
Indoor Main Control Board Component | Na dotaz | Zadat poptávku | |
| 023 SPIW412I |
C00385840
482000010304 |
KRABICE ELEKTRIKA | Na dotaz | Zadat poptávku | |
| 024 SPIW412I |
C00385838
482000010306 |
Electric joint box plate | Na dotaz | Zadat poptávku | |
| 025 SPIW412I |
C00385842
482000006237 |
Condensed tube | Na dotaz | Zadat poptávku | |
| 026 SPIW412I |
C00385844
481252048018 |
Axis sheath | Na dotaz | Zadat poptávku | |
| 027 SPIW412I |
C00378270
482000010310 |
Step motor | Na dotaz | Zadat poptávku | |
| 028 SPIW412I |
C00520285
482000098628 |
P.U.shell | Na dotaz | Zadat poptávku | |
| 029 SPIW412I |
C00630812
488000630812 |
shell | Na dotaz | Zadat poptávku | |
| 030 SPIW412I |
C00520286
482000098629 |
P.U.shell | Na dotaz | Zadat poptávku | |
| 031 SPIW412I |
C00386262
482000021361 |
Carbon filter (white grid) | Na dotaz | Zadat poptávku | |
| 032 SPIW412I |
C00506410
482000095042 |
Display | Na dotaz | Zadat poptávku | |
| 033 SPIW412I |
C00632985
488000632985 |
panel | Na dotaz | Zadat poptávku | |
| 001 SPIW412O |
C00520226
482000098610 |
Panel parts | Na dotaz | Zadat poptávku | |
| 002 SPIW412O |
C00386274
482000021191 |
Fan wheel | Na dotaz | Zadat poptávku | |
| 003 SPIW412O |
C00386276
482000021192 |
FAN MOTOR outdoor | Na dotaz | Zadat poptávku | |
| 004 SPIW412O |
C00385868
480150100117 |
Bracket Motor | Na dotaz | Zadat poptávku | |
| 005 SPIW412O |
C00385869
480150100107 |
Support | Na dotaz | Zadat poptávku | |
| 006 SPIW412O |
C00386351
482000091714 |
UPPER BOARD | Na dotaz | Zadat poptávku | |
| 007 SPIW412O |
C00386312
482000021211 |
Air grid rear | Na dotaz | Zadat poptávku | |
| 008 SPIW412O |
C00386292
482000021242 |
Condenser cpl. | Na dotaz | Zadat poptávku | |
| 009 SPIW412O |
C00632983
488000632983 |
base holder part | Na dotaz | Zadat poptávku | |
| 010 SPIW412O |
C00386288
482000021196 |
Separator | Na dotaz | Zadat poptávku | |
| 011 SPIW412O |
C00385880
482000000386 |
Transformer | Na dotaz | Zadat poptávku | |
| 012 SPIW412O |
C00386309
482000021243 |
Valve 4 way cpl. | Na dotaz | Zadat poptávku | |
| 013 SPIW412O |
C00377009
480150100338 |
Valve 4-way | Na dotaz | Zadat poptávku | |
| 014 SPIW412O |
C00386291
482000021198 |
Coil | Na dotaz | Zadat poptávku | |
| 015 SPIW412O |
C00386290
482000021199 |
Compressor | Na dotaz | Zadat poptávku | |
| 016 SPIW412O |
C00386293
482000021200 |
Cable harness | Na dotaz | Zadat poptávku | |
| 018 SPIW412O |
C00386311
482000021244 |
Capillary tube | Na dotaz | Zadat poptávku | |
| 019 SPIW412O |
C00377578
481236058637 |
Valve 2-way | Na dotaz | Zadat poptávku | |
| 020 SPIW412O |
C00385957
482000010346 |
Valve 3 way | Na dotaz | Zadat poptávku | |
| 021 SPIW412O |
C00386297
482000021203 |
Side panel | Na dotaz | Zadat poptávku | |
| 022 SPIW412O |
C00533356
488000533356 |
wiring distribution cover assy | Na dotaz | Zadat poptávku | |
| 023 SPIW412O |
C00386300
482000021204 |
Kryt zdroje napájení - externí | Na dotaz | Zadat poptávku | |
| 024 SPIW412O |
C00385981
482000000382 |
Support plate | Na dotaz | Zadat poptávku | |
| 025 SPIW412O |
C00386298
480150100391 |
Terminal Board. | Na dotaz | Zadat poptávku | |
| 026 SPIW412O |
C00386313
482000021245 |
Control board outdoor | Na dotaz | Zadat poptávku | |
| 027 SPIW412O |
C00386306
482000021207 |
Cover | Na dotaz | Zadat poptávku | |
| 028 SPIW412O |
C00386307
482000021208 |
Sensor temper. | Na dotaz | Zadat poptávku | |
| 029 SPIW412O |
C00386308
482000021209 |
Sensor temper. | Na dotaz | Zadat poptávku | |
| 030 SPIW412O |
C00386310
482000021210 |
Temperature sensor | Na dotaz | Zadat poptávku | |
| 031 SPIW412O |
C00632986
488000632986 |
sensor mounting plate | Na dotaz | Zadat poptávku | |
