| Komerční kód: | SPIW418L |
| Kód 12NC/I.C. kód: | 853005601000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 0999 WHR22071 |
C00386077
482000021419 |
Filter | Na dotaz | Zadat poptávku | |
| 0999 WHR22071 |
C00412065
482000010469 |
Carbon filterr (black net) | Na dotaz | Zadat poptávku | |
| 999 WHR22071 |
C00541560 | Testprogram WHP | Na dotaz | Zadat poptávku | |
| 999 WHR22071 |
C00561879 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
| A1 WHR22071 |
C00385999
482000021393 |
Cover | Na dotaz | Zadat poptávku | |
| A10 WHR22071 |
C00386031
482000021401 |
Cover | Na dotaz | Zadat poptávku | |
| A11 WHR22071 |
C00386038
482000021402 |
Protect motor | Na dotaz | Zadat poptávku | |
| A12 WHR22071 |
C00386049
482000021506 |
Steppin motor | Na dotaz | Zadat poptávku | |
| A13 WHR22071 |
C00385842
482000006237 |
Condensed tube | Na dotaz | Zadat poptávku | |
| A14 WHR22071 |
C00385811
482000010297 |
Baffle | Na dotaz | Zadat poptávku | |
| A15 WHR22071 |
C00386050
482000021404 |
Deflector | Na dotaz | Zadat poptávku | |
| A16 WHR22071 |
C00386051
482000006139 |
Plate mounting | Na dotaz | Zadat poptávku | |
| A17 WHR22071 |
C00386052
482000021405 |
Rear panel | Na dotaz | Zadat poptávku | |
| A18 WHR22071 |
C00386053
482000021409 |
Air guide | Na dotaz | Zadat poptávku | |
| A19 WHR22071 |
C00386054
482000021410 |
Air guide | Na dotaz | Zadat poptávku | |
| A2 WHR22071 |
C00386001
482000021394 |
Clamp | Na dotaz | Zadat poptávku | |
| A20 WHR22071 |
C00386266
482000021407 |
Air guide | Na dotaz | Zadat poptávku | |
| A21 WHR22071 |
C00385844
481252048018 |
Axis sheath | Na dotaz | Zadat poptávku | |
| A22 WHR22071 |
C00386056
482000021411 |
Deflector | Na dotaz | Zadat poptávku | |
| A23 WHR22071 |
C00386059
480150100234 |
Ložisko | Na dotaz | Zadat poptávku | |
| A24 WHR22071 |
C00386061
482000021412 |
Fan | Na dotaz | Zadat poptávku | |
| A25 WHR22071 |
C00386066
482000021413 |
Evaporator | Na dotaz | Zadat poptávku | |
| A26 WHR22071 |
C00386272
482000021414 |
Cover front | Na dotaz | Zadat poptávku | |
| A28 WHR22071 |
C00385852
482000091710 |
Keyboard | Na dotaz | Zadat poptávku | |
| A29 WHR22071 |
C00386282
482000021415 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A3 WHR22071 |
C00385835
482000018034 |
Connection cl. | Na dotaz | Zadat poptávku | |
| A30 WHR22071 |
C00386278
482000092479 |
Dálkový ovladač nástěné klimatizace Whirlpool | 1 294 Kč
€ 53.30 |
||
| A31 WHR22071 |
C00378138
482000000399 |
Temperature sensor | Na dotaz | Zadat poptávku | |
| A32 WHR22071 |
C00385824
482000010333 |
SONDA TEPELNÁ | Na dotaz | Zadat poptávku | |
| A33 WHR22071 |
C00419845
482000092112 |
Display board | Na dotaz | Zadat poptávku | |
| A34 WHR22071 |
C00386286
482000092489 |
panel | Na dotaz | Zadat poptávku | |
| A35 WHR22071 |
C00386280
482000021392 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A4 WHR22071 |
C00386002
482000021395 |
Elect.parts box plate | Na dotaz | Zadat poptávku | |
| A5 WHR22071 |
C00386010
482000021396 |
KRABICE ELEKTRIKA | Na dotaz | Zadat poptávku | |
| A6 WHR22071 |
C00386013
482000021397 |
Control board indoor | Na dotaz | Zadat poptávku | |
| A7 WHR22071 |
C00386027
482000021398 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A8 WHR22071 |
C00386028
482000021399 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A9 WHR22071 |
C00386029
482000021400 |
Motor fan | Na dotaz | Zadat poptávku | |
| B1 WHR22071 |
C00386086
482000006149 |
Front panel | Na dotaz | Zadat poptávku | |
| B10 WHR22071 |
C00386115
482000021423 |
Control board cpl. | Na dotaz | Zadat poptávku | |
| B11 WHR22071 |
C00386118
482000010409 |
Wire box | Na dotaz | Zadat poptávku | |
| B12 WHR22071 |
C00386122
482000092468 |
Filter board | Na dotaz | Zadat poptávku | |
| B13 WHR22071 |
C00385982
482000021177 |
Terminal board | Na dotaz | Zadat poptávku | |
| B14 WHR22071 |
C00385985
480150100377 |
Sensor temper. Outdoor ambient | Na dotaz | Zadat poptávku | |
| B15 WHR22071 |
C00378140
482000000401 |
Sensor temper. | Na dotaz | Zadat poptávku | |
| B16 WHR22071 |
C00377023
480150100848 |
Sensor temper. Outdoor ambient | Na dotaz | Zadat poptávku | |
| B17 WHR22071 |
C00386124
480150100843 |
Valve 4-WAY | Na dotaz | Zadat poptávku | |
| B18 WHR22071 |
C00386125
481236058434 |
Valve 4 Way | Na dotaz | Zadat poptávku | |
| B19 WHR22071 |
C00386126
482000017874 |
Valve 4-way assy | Na dotaz | Zadat poptávku | |
| B2 WHR22071 |
C00386087
482000021420 |
Fan wheel | Na dotaz | Zadat poptávku | |
| B20 WHR22071 |
C00386127
482000017875 |
Compressor | Na dotaz | Zadat poptávku | |
| B21 WHR22071 |
C00385937
482000000391 |
Cable harness | Na dotaz | Zadat poptávku | |
| B22 WHR22071 |
C00386130
482000021428 |
Capillary tube cpl. | Na dotaz | Zadat poptávku | |
| B23 WHR22071 |
C00377578
481236058637 |
Valve 2-way | Na dotaz | Zadat poptávku | |
| B24 WHR22071 |
C00386132
482000010414 |
Valve 3 way | Na dotaz | Zadat poptávku | |
| B25 WHR22071 |
C00412026
482000010413 |
Side panel | Na dotaz | Zadat poptávku | |
| B26 WHR22071 |
C00385959
480150100575 |
Cover | Na dotaz | Zadat poptávku | |
| B27 WHR22071 |
C00386133
482000006169 |
Plate mounting | Na dotaz | Zadat poptávku | |
| B28 WHR22071 |
C00412031
482000010421 |
Plate | Na dotaz | Zadat poptávku | |
| B29 WHR22071 |
C00386135
482000010420 |
Cover | Na dotaz | Zadat poptávku | |
| B3 WHR22071 |
C00386088
482000010405 |
Motor fan | Na dotaz | Zadat poptávku | |
| B30 WHR22071 |
C00386136
482000010419 |
PFC reactor | Na dotaz | Zadat poptávku | |
| B4 WHR22071 |
C00386089
482000021421 |
Bracket motor | Na dotaz | Zadat poptávku | |
| B5 WHR22071 |
C00386090
482000017876 |
Base | Na dotaz | Zadat poptávku | |
| B6 WHR22071 |
C00386098
482000006157 |
Plate mounting | Na dotaz | Zadat poptávku | |
| B7 WHR22071 |
C00386102
482000021422 |
Condenser | Na dotaz | Zadat poptávku | |
| B8 WHR22071 |
C00386110
482000010407 |
Air grid | Na dotaz | Zadat poptávku | |
| B9 WHR22071 |
C00386113
482000006156 |
Cover top | Na dotaz | Zadat poptávku | |
