WHIRLPOOL SPOW218/3
Zeptejte se. Rádi poradíme.
Marek Proche
Zákaznická podpora
Po–Čt 8:00—17:00
Pá 8:00—15:00
poradna@servis-whirlpool.cz
| Komerční kód: | SPOW218/3 |
| Kód 12NC: | 853005779000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Klimatizace |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 999 WHR22073 |
C00561926 | NTC/PTC Chart WHP | Na dotaz | Zadat poptávku | |
| 999 WHR22073 |
C00561928 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
| A01 WHR22073 |
C00385999
482000021393 |
Cover | Na dotaz | Zadat poptávku | |
| A02 WHR22073 |
C00386001
482000021394 |
Clamp | Na dotaz | Zadat poptávku | |
| A03 WHR22073 |
C00503702
482000093941 |
Wire | Na dotaz | Zadat poptávku | |
| A04 WHR22073 |
C00386002
482000021395 |
Elect.parts box plate | Na dotaz | Zadat poptávku | |
| A05 WHR22073 |
C00386010
482000021396 |
KRABICE ELEKTRIKA | Na dotaz | Zadat poptávku | |
| A06 WHR22073 |
C00419692
482000091850 |
Control board indoor | Na dotaz | Zadat poptávku | |
| A07 WHR22073 |
C00386027
482000021398 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A08 WHR22073 |
C00386028
482000021399 |
Elect.parts box cover | Na dotaz | Zadat poptávku | |
| A09 WHR22073 |
C00386029
482000021400 |
Motor fan | Na dotaz | Zadat poptávku | |
| A10 WHR22073 |
C00386031
482000021401 |
Cover | Na dotaz | Zadat poptávku | |
| A11 WHR22073 |
C00386038
482000021402 |
Protect motor | Na dotaz | Zadat poptávku | |
| A12 WHR22073 |
C00386049
482000021506 |
Steppin motor | Na dotaz | Zadat poptávku | |
| A13 WHR22073 |
C00385842
482000006237 |
Condensed tube | Na dotaz | Zadat poptávku | |
| A14 WHR22073 |
C00385811
482000010297 |
Baffle | Na dotaz | Zadat poptávku | |
| A15 WHR22073 |
C00386050
482000021404 |
Deflector | Na dotaz | Zadat poptávku | |
| A16 WHR22073 |
C00386051
482000006139 |
Plate mounting | Na dotaz | Zadat poptávku | |
| A17 WHR22073 |
C00386052
482000021405 |
Rear panel | Na dotaz | Zadat poptávku | |
| A18 WHR22073 |
C00386053
482000021409 |
Air guide | Na dotaz | Zadat poptávku | |
| A19 WHR22073 |
C00386054
482000021410 |
Air guide | Na dotaz | Zadat poptávku | |
| A20 WHR22073 |
C00386266
482000021407 |
Air guide | Na dotaz | Zadat poptávku | |
| A21 WHR22073 |
C00385844
481252048018 |
Axis sheath | Na dotaz | Zadat poptávku | |
| A22 WHR22073 |
C00386056
482000021411 |
Deflector | Na dotaz | Zadat poptávku | |
| A23 WHR22073 |
C00386059
480150100234 |
Ložisko | Na dotaz | Zadat poptávku | |
| A24 WHR22073 |
C00386061
482000021412 |
Fan | Na dotaz | Zadat poptávku | |
| A25 WHR22073 |
C00386066
482000021413 |
Evaporator | Na dotaz | Zadat poptávku | |
| A26 WHR22073 |
C00386272
482000021414 |
Cover front | Na dotaz | Zadat poptávku | |
| A27 WHR22073 |
C00386280
482000021392 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A28 WHR22073 |
C00386282
482000021415 |
Cap ornamental | Na dotaz | Zadat poptávku | |
| A29 WHR22073 |
C00378274
482000010320 |
Ovladač dálkový | 1 704 Kč
€ 74.90 |
||
| A30 WHR22073 |
C00386426
482000091724 |
TEMPERATURE SENSOR | Na dotaz | Zadat poptávku | |
| A31 WHR22073 |
C00386427
482000091843 |
AC POWER CORD | Na dotaz | Zadat poptávku | |
| A32 WHR22073 |
C00419624
482000091711 |
Display board | Na dotaz | Zadat poptávku | |
| A33 WHR22073 |
C00417573
482000021417 |
Front panel | Na dotaz | Zadat poptávku | |
| A34 WHR22073 |
C00419637
482000091726 |
Display | Na dotaz | Zadat poptávku | |
| A35 WHR22073 |
C00385852
482000091710 |
Keyboard | Na dotaz | Zadat poptávku | |
| B01 WHR22073 |
C00386086
482000006149 |
Front panel | Na dotaz | Zadat poptávku | |
| B02 WHR22073 |
C00386435
482000006228 |
Base | Na dotaz | Zadat poptávku | |
| B03 WHR22073 |
C00409765
482000006151 |
Fan Out door | Na dotaz | Zadat poptávku | |
| B04 WHR22073 |
C00386433
482000006229 |
Motor fan | Na dotaz | Zadat poptávku | |
| B05 WHR22073 |
C00386434
482000021283 |
Bracket motor | Na dotaz | Zadat poptávku | |
| B06 WHR22073 |
C00386436
482000091851 |
CONDENSER ASSEMBLY | Na dotaz | Zadat poptávku | |
| B07 WHR22073 |
C00386448
482000006155 |
Panel rear | Na dotaz | Zadat poptávku | |
| B08 WHR22073 |
C00386113
482000006156 |
Cover top | Na dotaz | Zadat poptávku | |
| B09 WHR22073 |
C00386098
482000006157 |
Plate mounting | Na dotaz | Zadat poptávku | |
| B10 WHR22073 |
C00386437
482000006158 |
Separator | Na dotaz | Zadat poptávku | |
| B11 WHR22073 |
C00386442
482000091853 |
COMPRESSOR PH310G2C - 7KTS - R22 | Na dotaz | Zadat poptávku | |
| B12 WHR22073 |
C00386443
482000000346 |
Cable harness | Na dotaz | Zadat poptávku | |
| B13 WHR22073 |
C00386446
480150100462 |
Valve | Na dotaz | Zadat poptávku | |
| B14 WHR22073 |
C00386441
482000091852 |
PIPE ASS'Y | Na dotaz | Zadat poptávku | |
| B15 WHR22073 |
C00386447
482000006163 |
Side panel | Na dotaz | Zadat poptávku | |
| B16 WHR22073 |
C00385959
480150100575 |
Cover | Na dotaz | Zadat poptávku | |
| B17 WHR22073 |
C00386445
482000000358 |
Valve | Na dotaz | Zadat poptávku | |
| B18 WHR22073 |
C00503703
482000093942 |
Suction pipe | Na dotaz | Zadat poptávku | |
| B18 WHR22073 |
C00503704
482000093943 |
Pipe DISCHARGE | Na dotaz | Zadat poptávku | |
| B19 WHR22073 |
C00386421
480150100141 |
Terminal Board | Na dotaz | Zadat poptávku | |
| B20 WHR22073 |
C00386440
482000006168 |
Capacitor Fan | Na dotaz | Zadat poptávku | |
| B21 WHR22073 |
C00386438
482000006167 |
Elect.parts box | Na dotaz | Zadat poptávku | |
| B22 WHR22073 |
C00386439
480150100206 |
Capacitor | Na dotaz | Zadat poptávku | |
