| Komerční kód: | WRF 40 REFRIGERATORS WP |
| Kód 12NC/I.C. kód: | 853476465000 |
| Značka: | WHIRLPOOL |
| Typ produktu: | Volně stojící lednice |
| Další podobné modely: | 853476443000, 853476443001 |
Potřebujete servis? Jsme tady pro Vás
Nabídka náhradních dílů
| Číslo | Kód | Název | Cena | ||
|---|---|---|---|---|---|
| 011 0 WHR67809 |
C00584698
481246218253 |
Adjusting screw. | Na dotaz | Zadat poptávku | |
| 012 0 WHR67809 |
C00491928
481246238133 |
Roller | Na dotaz | Zadat poptávku | |
| 040 0 WHR67809 |
C00488983
481241719287 |
Závěs dveří - horní, dolní šuplíkového mrazáku Whirlpool | 100 Kč
€ 4.10 |
||
| 040 1 WHR67809 |
C00500817
481241778095 |
Hinge middle | Na dotaz | Zadat poptávku | |
| 040 2 WHR67809 |
C00491670
481241778082 |
Shim | Na dotaz | Zadat poptávku | |
| 040 3 WHR67809 |
C00584841
481252648197 |
Shim Hinge. | Na dotaz | Zadat poptávku | |
| 040 4 WHR67809 |
C00584458
481241378754 |
Shim. | Na dotaz | Zadat poptávku | |
| 047 0 WHR67809 |
C00530022
481253548033 |
Shaft Roller | Na dotaz | Zadat poptávku | |
| 047 1 WHR67809 |
C00500818
481241778096 |
Pin hinge | Na dotaz | Zadat poptávku | |
| 050 0 WHR67809 |
C00403528
481244079205 |
Rail | Na dotaz | Zadat poptávku | |
| 050 1 WHR67809 |
C00517537
481232588014 |
Insulation | Na dotaz | Zadat poptávku | |
| 050 2 WHR67809 |
C00584399
481225948158 |
Heating element | Na dotaz | Zadat poptávku | |
| 050 3 WHR67809 |
C00584398
481225948157 |
Cover f.shield. | Na dotaz | Zadat poptávku | |
| 070 0 WHR67809 |
C00403909
481245228761 |
Plinth | Na dotaz | Zadat poptávku | |
| 104 0 WHR67809 |
C00402709
481241619986 |
Door refriger. GW | Na dotaz | Zadat poptávku | |
| 104 5 WHR67809 |
C00402697
481241619945 |
Door small white color | Na dotaz | Zadat poptávku | |
| 105 0 WHR67809 |
C00344062
481253288067 |
Bushing WH | Na dotaz | Zadat poptávku | |
| 105 1 WHR67809 |
C00491933
481246258091 |
Stop door right | Na dotaz | Zadat poptávku | |
| 105 2 WHR67809 |
C00402731
481241719371 |
Stop door | Na dotaz | Zadat poptávku | |
| 111 0 WHR67809 |
C00487794
481249848012 |
Handle | Na dotaz | Zadat poptávku | |
| 111 1 WHR67809 |
C00405332
481249818674 |
Door handle GW | Na dotaz | Zadat poptávku | |
| 111 5 WHR67809 |
C00576370
481245918254 |
Nameplate Whirlpool.. | Na dotaz | Zadat poptávku | |
| 111 7 WHR67809 |
C00576353
481245918226 |
Nameplate white colour.. | Na dotaz | Zadat poptávku | |
| 111 8 WHR67809 |
C00584669
481245918225 |
Nameplate. | Na dotaz | Zadat poptávku | |
| 152 0 WHR67809 |
C00485997
481246228476 |
Shelf | Na dotaz | Zadat poptávku | |
| 152 1 WHR67809 |
C00485002
481241858041 |
Cover | Na dotaz | Zadat poptávku | |
| 153 0 WHR67809 |
C00485998
481246228477 |
Shelf | Na dotaz | Zadat poptávku | |
| 153 1 WHR67809 |
C00584770
481246428036 |
Shelf. | Na dotaz | Zadat poptávku | |
| 154 0 WHR67809 |
C00486092
481246428035 |
Shelf | Na dotaz | Zadat poptávku | |
| 155 0 WHR67809 |
C00584769
481246428034 |
Shelf. | Na dotaz | Zadat poptávku | |
| 155 1 WHR67809 |
C00404858
481246238263 |
Separator | Na dotaz | Zadat poptávku | |
| 156 0 WHR67809 |
C00517547
481246088263 |
Holder eggs | Na dotaz | Zadat poptávku | |
| 191 0 WHR67809 |
C00486175
481246688789 |
Gasket ref.door | Na dotaz | Zadat poptávku | |
| 191 1 WHR67809 |
C00486176
481246688791 |
Gasket ref.door smal | Na dotaz | Zadat poptávku | |
| 242 0 WHR67809 |
C00402929
481241828939 |
Crisper | Na dotaz | Zadat poptávku | |
| 242 2 WHR67809 |
C00584771
481246428037 |
Separator. | Na dotaz | Zadat poptávku | |
| 242 3 WHR67809 |
C00517540
481240448854 |
Roller | Na dotaz | Zadat poptávku | |
| 243 0 WHR67809 |
C00402960
481241828989 |
Tray | Na dotaz | Zadat poptávku | |
| 243 1 WHR67809 |
C00584550
481241848751 |
Shelf. | Na dotaz | Zadat poptávku | |
| 243 2 WHR67809 |
C00584559
481241879787 |
Tray meat | Na dotaz | Zadat poptávku | |
| 243 3 WHR67809 |
C00404956
481246418195 |
Batten | Na dotaz | Zadat poptávku | |
| 255 0 WHR67809 |
C00403814
481245088341 |
Glass shelf | Na dotaz | Zadat poptávku | |
| 301 0 WHR67809 |
C00584754
481246228724 |
Cover plate , white color. | Na dotaz | Zadat poptávku | |
| 301 1 WHR67809 |
C00383490
481246049645 |
Console white | Na dotaz | Zadat poptávku | |
| 301 2 WHR67809 |
C00383491
481221848126 |
Electronic box white color | Na dotaz | Zadat poptávku | |
| 301 3 WHR67809 |
C00482883
481240478518 |
Support | Na dotaz | Zadat poptávku | |
| 301 4 WHR67809 |
C00404056
481245310364 |
Display GW | Na dotaz | Zadat poptávku | |
| 321 0 WHR67809 |
C00484601
481213488046 |
Protector LED | Na dotaz | Zadat poptávku | |
| 332 0 WHR67809 |
C00402314
481241218047 |
Knob white color | Na dotaz | Zadat poptávku | |
| 333 0 WHR67809 |
C00493512
481241318315 |
Switch | Na dotaz | Zadat poptávku | |
| 402 0 WHR67809 |
C00584421
481236038944 |
Compressor EM 45 HNR 220-240V. | Na dotaz | Zadat poptávku | |
| 402 1 WHR67809 |
C00584552
481241848753 |
Tray compressor | Na dotaz | Zadat poptávku | |
| 402 3 WHR67809 |
C00576151
481240418308 |
Base compressor.. | Na dotaz | Zadat poptávku | |
| 440 0 WHR67809 |
C00488668
481236138076 |
Motor fan 220V / 60H | Na dotaz | Zadat poptávku | |
| 440 1 WHR67809 |
C00485900
481246049647 |
Protect motor | Na dotaz | Zadat poptávku | |
| 440 2 WHR67809 |
C00517546
481245298304 |
Cover | Na dotaz | Zadat poptávku | |
| 440 3 WHR67809 |
C00486295
481252448006 |
Damping part | Na dotaz | Zadat poptávku | |
| 443 0 WHR67809 |
C00484748
481236118378 |
Fan | Na dotaz | Zadat poptávku | |
| 443 1 WHR67809 |
C00484016
481246049646 |
Support Motor | Na dotaz | Zadat poptávku | |
| 614 0 WHR67809 |
C00491161
481228028029 |
Relay EM45 HNR 220V | Na dotaz | Zadat poptávku | |
| 651 0 WHR67809 |
C00490082
481246098026 |
Reflector lamp | Na dotaz | Zadat poptávku | |
| 652 0 WHR67809 |
C00339579
481225528011 |
Holder lamp | Na dotaz | Zadat poptávku | |
| 652 1 WHR67809 |
C00574299
481213488025 |
Lamp. | Na dotaz | Zadat poptávku | |
| 652 2 WHR67809 |
C00482522
481225538009 |
Base,lamp | Na dotaz | Zadat poptávku | |
| 652 3 WHR67809 |
C00519053
481246098057 |
Protector | Na dotaz | Zadat poptávku | |
| 652 4 WHR67809 |
C00584681
481246049648 |
Cabinet. | Na dotaz | Zadat poptávku | |
| 740 0 WHR67809 |
C00574589
481251148337 |
Condenser. | Na dotaz | Zadat poptávku | |
| 740 1 WHR67809 |
C00482840
481240418443 |
Support condenser upper | Na dotaz | Zadat poptávku | |
| 740 2 WHR67809 |
C00330489
481246228394 |
Holder Condenser | Na dotaz | Zadat poptávku | |
| 745 0 WHR67809 |
C00486265
481251138229 |
Evaporator Assy | Na dotaz | Zadat poptávku | |
| 745 1 WHR67809 |
C00404957
481246418196 |
Drain strip | Na dotaz | Zadat poptávku | |
| 764 0 WHR67809 |
C00311590
481952648527 |
Dryer DRS15 With 3 ways valve | Na dotaz | Zadat poptávku | |
| 900 0 WHR67809 |
C00492124
481253578089 |
Clip | Na dotaz | Zadat poptávku | |
| 904 0 WHR67809 |
C00330537
481246228701 |
Cover WH | Na dotaz | Zadat poptávku | |
| 965 0 WHR67809 |
C00330243
481246048886 |
Cover | Na dotaz | Zadat poptávku | |
| 999 WHR67809 |
C00686786 | Circuit/Wiring Diagram WHP | Na dotaz | Zadat poptávku | |
